K5 TACK KETTLE

OPERATOR'S INSTRUCTION MANUAL

Keep this Manual with the Tack Kettle at all times.

This will allow new users to read it before operating machine.

It is the Tack Kettle owner's responsibility to ensure that all

workers using this machine are thoroughly trained. Provide

workers with this Operator's Manual and make sure they

understand its contents. Read it to them if necessary. Letting

poorly trained workers use this machine can result in property or

machine damage and/or serious injury or death to personnel.

This machine was designed for the sole purpose of heating and

applying Asphalt Tack grade material. Attempting to heat and

apply any other material in this machine can cause machine

damage, unsatisfactory results and in the case of higher

temperature material, serious injury to workers.

2601 Niagara Lane · Plymouth, MN 55447 · (763) 557-1982 · (800) 328-3874 · Fax (763) 557-1971

P/N 161215

Rev D 6/15/2021

Table of Contents

Need help?

Do you have a question about the K5 and is the answer not in the manual?

Questions and answers

Summary of Contents for CIMLINE K5

Page 1 K5 TACK KETTLE OPERATOR’S INSTRUCTION MANUAL Keep this Manual with the Tack Kettle at all times. This will allow new users to read it before operating machine. It is the Tack Kettle owner’s responsibility to ensure that all workers using this machine are thoroughly trained. Provide workers with this Operator’s Manual and make sure they...
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS ................4 TOWING ......................5 OPERATOR PREPARATION ................6 EQUIPMENT AND WORKSITE PREPARATION ..........6 COLD START LOADING ................. 7 ATTACHING / CHECKING LP TANK ............... 7 LIGHTING BURNERS ..................8 ENIGNE OPERATION ................... 10 SPRAYING MATERIAL ..................
Page 4: Safety Precautions
Close the kettle manhole. Fill the fuel tank with a funnel. Wipe up all spills with a clean cloth; put fuel away in a safe place. Restart engine and burners. Make sure safety chains and hitch are securely attached. The Cimline Tack Kettle meets all federal requirements for brakes, lights and minimum stopping distances. Check local requirements to ensure conformance to local standards.
Page 5: Towing
Check that the tires on the kettle have to proper pressure for the load and lug nuts are tight. The tail lights and brakes are standard equipment on Cimline kettles. Test them periodically to make sure they are in working order. Also be aware of the minimum stopping distance regula- tions where the kettle is being towed.
Page 6: Operator Preparation
OPERATOR PREPARATION READ INSTRUCTIONS THOROUGHLY. WARNING! AN UNINFORMED OR UNTRAINED OPERATOR CAN SUBJECT HIMSELF AND OTHERS TO SEVERE DANGER! WARNING! NEVER ALLOW AN UNTRAINED PERSON TO OPERATE THIS KETTLE! SERIOUS INJURY MAY RESULT FROM THEIR ACTIONS WARNING! WEARING IMPROPER OR INADEQUATE CLOTHING NOT SPECIFIED BELOW CAN CAUSE SERIOUS INJURY IN CASE MATERIAL SPLASHES OR IS SPRAYED ON OR AT THE OPERATOR.
Page 7: Cold Start Loading
COLD START LOADING Check the material you are going to heat and heat according to material manufacturers’ recommendation. Check the residue in the kettle to make sure it’s the same material you are using. Never mix materials of different types, grades or from manufacturers. Maintain a clean work area free of flammable materials and trip hazards.
Page 8: Lighting Burners
MAIN TANK VALVE BALL VALVE ON REGULATOR LIGHTING BURNER(S) WARNING! NEVER LIGHT BURNER WITHOUT ASPHALT COMPLETELY COVERING FLUES. UNCOVERED FLUES GET TOO HOT AND CAN CAUSE A FIRE OR FLASH. SERIOUS INJURY CAN RESULT. Be sure the Ball Valve attached to the Regulator is CLOSED Open the LP Tank Valve slowly to wide open.
Page 10: Enigne Operation
ENGINE OPERATION STARTING ENGINE: Turn the fuel valve to the “ON” position. Move the choke lever to the “CLOSE” position. NOTE: The choke may not be needed if the engine is warm or the air temperature is high. Move the throttle lever slightly to the left. Turn the engine switch to the “ON”...
Page 12: Spraying Material
SPRAYING MATERIAL (TO BE DONE ONLY BY TRAINED PERSONNEL) WARNING! DO NOT START ENGINE WITHOUT ALL HOSES AND FITTINGS SECURELY INSTALLED. DOING SO MAY CAUSE SERIOUS INJURY AND BURNS! Before Starting Engine: Drain solvent left-over in Pump/Plumbing from the previous cleaning. This will prevent the left- over solvent from being pumped into the Tank of new Material.
Page 13: Installing Optional Spray Bar Attachment
To make sure all left-over solvent from the previous cleaning is out of Hose and Spray Wand, hold tip of Spray Wand over a container and SLOWLY open Ball Valve on Wand to flush any solvent from Hose and Wand. Spray until an uninterrupted flow of material comes out of Wand. Close the Wand valve.
Page 15: Using Optional Spray Bar Attachment
SHUTTNG DOWN LP BURNER To shut down for an extended period, close the Main Valve on LP tank. This will allow the gas in the line to bleed out. The burners may run for a minute until the gas is purged. Close the Ball Valve attached to regulator.
Page 16: General Maintainence
GENERAL MAINTAINANCE Grease the pump twice a day; once at noon when the entire system is hot, and once at shut down at the end of the day. Use hi-temp grease. It is highly recommended that the engine oil be changed daily. Because of the heat involved with this application, oil breaks down much quicker than ordinary engine uses.
Page 17: Parts List
COMPONENT LIST Service/Replacement Parts: Engine: ......................... 110484 Pump: ........................... 200615 Pump Coupling: ......................110159 Pump Coupling Guard: ....................422353 Burner-Complete: ......................405374 Lighter Wand: ....................... 405376 Regulator Assembly: ....................405375 Large LP Hose (to Burner): ................... 171993 Small LP Hose (to Lighter Wand): ................171994 Tank Lid Gasket (set of 4): ...................
Page 20: Notes
This space is intentionally left blank. ------------------------------------------------------------------------------------------------------------------------------------------- To replace any Warning Decals on your Tack Kettle (300793), simply tear off the bottom half of this page and mail or fax to Cimline for FREE REPLACEMENTS. Address: Fax: 800-820-3268 Cimline Inc.
