ASSEMBLY INSTRUCTION
BREED SOFA SET
WF191435
WF191437
PLEASE DO NOT RETURN PRODUCT TO THE STORE
If you have any problem or concerns, please feel free to contact our customer
service department. We will reply you as soon as possible.
E-Mail: csr@merax.com
Tel: 626-912-8886 Ext.100
Advertisement
Summary of Contents for Merax BREED SOFA SET WF191435
- Page 1 BREED SOFA SET WF191435 WF191437 PLEASE DO NOT RETURN PRODUCT TO THE STORE If you have any problem or concerns, please feel free to contact our customer service department. We will reply you as soon as possible. E-Mail: csr@merax.com Tel: 626-912-8886 Ext.100...
- Page 2 Notice: 1. 50% Tighten before fixing all screws, Allen wrench is recommended instead of an electric drill. 2. Place the item on a flat ground to adjust and make sure it remains stable. 3. Tighten up all screws with tools gradually. 4.
- Page 3 Part List Left Frame (1pc) Right Frame (1pc) Bench Left Back Frame (1pc) Bench Right Seat Frame (1pc) Bench Left Seat Frame (1pc) Bench Right Back Frame (1pc) Bench Right Front Frame (1pc) Bench Left Side Frame (1pc) Bench Left Front Frame (1pc) Bench Right Side Frame (1pc) Top Table (1pc) Table Front Frame (2pcs)
- Page 4 Part List Box Front Frame (1pc) Box Back Frame (1pc) Box Left Frame (1pc) Bench Seat Cushion (2pcs) Bench Back Cushion (4pcs) Box Right Frame (1pc) Cloth Bag (1pc) Glass Table (1pc)
- Page 5 Hardware list Bolt M6 x 25 mm (32 pcs) Bolt M6 x 25 mm ( 10 pcs) Bolt M6 x 30 mm (34 pcs) Bolt M6 x 40 mm (24 pcs) Plastic Feet (16 pcs) Hinges (2 pcs) Link rope (1pc) Allen key M4 (1 pc)
- Page 6 STEP 1 (Bench Left Assembly) Connect Left Frame (A) & Bench Left Back Frame (C) with Bolt (4) STEP 2 Connect part from STEP 1 & Bench Left Seat Frame (E) with Bolt (4)
- Page 7 STEP 3 Connect part from STEP 2 & Bench Left Side Frame (I) with Bolt (3) STEP 4 Connect part from STEP 3 & Bench Left Front Frame (G) with Bolt (3) (4)
- Page 8 STEP 5 Connect part from STEP 4 & Plastic Feet (5) with Bolt (1) STEP 6 Put on Bench Cushion (R), Back Cushion (S) to complete Bench...
- Page 9 STEP 7 (Bench Right Assembly) Connect Right Frame (B) & Bench Right Back Frame (D) with Bolt (4) STEP 8 Connect part from STEP 7 & Bench Right Seat Frame (F) with Bolt (4)
- Page 10 STEP 9 Connect part from STEP 8 & Bench Right Side Frame (J) with Bolt (3) STEP 10 Connect part from STEP 9 & Bench Right Front Frame (H) with Bolt (3) (4)
- Page 11 STEP 11 Connect part from STEP 10 & Plastic Feet (5) with Bolt (1) STEP 12 Put on Bench Cushion (R), Back Cushion (S) to complete Bench...
- Page 12 STEP 14 STEP 13 (Table Assembly) Connect Top Table (K) & Table Front Frame Connect part from STEP 13 & Table Front (L), Table Side Frame (M) with Bolt (3) Frame (L) with Bolt (3) STEP 15 STEP 16 Connect part from STEP 15 & Plastic Feet (5) Connect part from STEP 14 &...
- Page 13 STEP 18 (Box Assembly) STEP 17 Connect Front Box Frame (P) & Back Box Put on Glass Table (V) to complete Table Frame (Q), Box Left Frame (T) with Bolt (3) STEP 19 STEP 20 Connect part from STEP 18 & Bottom Box Connect part from STEP 19 &...
- Page 14 STEP 21 STEP 22 Connect part from STEP 20 & Plastic Feet (5) Connect part from STEP 21 & Top Box (N) with Bolt (1) with Hinges (6) & Bolt (2) STEP 22 Connect Top Box (N) & Box Right Frame (U) with Bolt (2), Link Rope (7)
- Page 15 STEP 23 Put on Cloth Bag (X) to complete Box...
