IRON MAN HELMET
This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive 2012/19/EU in order to be recycled or dismantled to
minimize its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous for the environment and human health due
to the presence of hazardous substances.
CHARGE BEFORE USE
Maintenance
• Place unit on a level surface away
from sources of direct sunlight or
excessive heat.
• Protect your furniture when placing
your unit on natural wood and
lacquered finish. A cloth or other
protective material should be placed
between it and the furniture.
• Clean your unit with a soft cloth
moistened only with mild soap and
water. Stronger cleaning agents can
damage the surface of the unit.
Controls
Front View
Bluetooth Button
LED LED
When not in use, slide Power Switch to the OFF position to save battery power.
Charging the Unit
CHARGE UNIT BEFORE USE
1. Connect the micro USB plug to the micro USB charging port on the
back of the unit.
Charge via USB AC adaptor, computer USB port, or other powered USB port
USB Adaptor
(not included)
OR
Computer
connected to
working outlet
Computer USB port
2. Connect the standard USB plug end of the cable to a power USB
port on a computer or other USB charging device. For first time use,
charge unit for about 8 hours.
3. The Power/Charging/Pairing Indicator Light on the back of the unit
glows red steadily while the unit is charging and turns OFF once the
unit is fully charged. If unit is not powered on when micro USB plug
is connected, the red light glows steadily to indicate unit is charging.
ViB72IM-ONLINEIB-ENG-042921-A
What's Included
Vi-B72IM Speaker
USB charging cable
Back View
Speaker
USB Charging Port
ON/OFF Switch
USB
charging cable
1:2 SCALE SPEAKER
Pairing Your Device
Pairing is the set-up process to introduce your Bluetooth-capable device
to the Vi-B72IM. Once your device is paired, the Vi-B72IM can recognize
it and you can play your audio through it.
1. Make sure your Bluetooth device is fully charged. Turn on
your Bluetooth device and make it "discoverable" by turning
on Bluetooth mode (check in Options or Settings).
2. Slide the Power ON/OFF Switch to ON to turn on the
Vi-B72IM. The first time the unit is powered on, it will enter
auto-pairing mode and attempt to connect to a Bluetooth
device (if so, skip to step 4). Otherwise, follow step 3 to
begin pairing.
3. Press and hold the
The Vi-B72IM will beep and the Power/Charging/Pairing
Indicator LED on the back of the unit will flash red and blue.
4. "iHome B72 IM" should appear in your device's Bluetooth menu. If
"Not Paired", "Not Connected" or similar message appears, select
"iHome B72 IM" to connect it. If prompted for a passcode, enter
"1234" on your device's keypad.
5. If pairing is successful, a tone will sound and the blue LED will glow
solid, indicating the Vi-B72IM is ready to play music. There should
also be an indication on your device. Once the Vi-B72IM is paired
to a device, it will attempt to autolink when the device is within range
(about 30 feet).
Pairing with a Different Device
When the speaker is ON, it will automatically link with the previously
paired Bluetooth device as long as that device is still within range
(approx. 30 feet). So to pair with a different device you must press and
hold the Bluetooth Pairing Button for 3 seconds to re-enter pairing mode.
Playing Audio Via Bluetooth
1. Slide the ON/OFF Switch to the ON position to listen to audio
streamed wirelessly from your paired iPad, iPhone, iPod or other
Bluetooth device.
The Power/Charging/Pairing Indicator LED on the unit will flash blue
and a tone will sound as the unit searches for a previously paired
device, and then turn solid blue once a previously paired device is
detected.
2. Use the controls on your Bluetooth device to play or pause audio,
navigate tracks and control volume.
3. When done listening, slide the ON/OFF Switch to the OFF position
to conserve the battery.
Troubleshooting
Unit doesn't respond (no power):
• Make sure unit is completely charged.
• Check that all connections are correct and properly plugged in.
• Make sure your device is properly paired with the Vi-B72IM.
• Make sure the ON/OFF Switch is not in the OFF position.
• The rechargeable battery in your speaker can be replaced only by
eKids Consumer Repair Department.
Unit doesn't respond (locked up/ "frozen")
If the unit does not respond, try resetting it. Press and hold the
Bluetooth Pairing button for 9 seconds. Note that doing so will clear
settings, and any Bluetooth devices will need to be re-paired.
Trouble pairing device with Vi-B72IM
Bluetooth implementation varies depending on your device's hardware
and operating system. Please see our website for updates on pairing.
• When you power ON the speaker, it will automatically link with the
last previously paired Bluetooth device if the device is still within
range (approx. 30 feet). To pair with a different device you must turn
off Bluetooth capability on the already paired device, or take it out
of range.
• If your device does not auto-link when within range, re-pair the
device. To do so, first delete the Vi-B72IM from your Bluetooth
devices menu.
For further information and to see the latest instructions, visit www.ekids.com
Model: Vi-B72IM
Bluetooth Pairing button for 3 seconds.
