- Page 1 MOPIC 3D System User Manual MOPIC's 3D System delivers an absolute immersive experience through MOPIC's precise eye-tracking technology best suited for a single user. Please refer to User Manual for instructions and optimal immersive experience mopic3d.com...
-
Page 2: Table Of Contents
Items and Accessories Connections Connecting Cables Connecting Power Supplies How to Use Proper eye-tracking operations and the optimal distance between MOPIC 3D Monitor and the user Main Ways to Enjoy MOPIC 3D System Basic Troubleshooting To Adjust 3D Settings To confirm 3D Box settings To confirm 3D Monitor settings ... -
Page 3: Prior To Use
If the front screen including the attached film gets damaged or removed, 3D immersive experience may become hindered or impossible ● If cables are used that are not supported or tested by MOPIC, the monitor may fail to work or exhibit static ●... -
Page 4: Connections
Connections Connecting Cables As the diagram below shows, please connect the PC or Mac to 3D Monitor, and RGB Cam to 3D Box. * Illustrations in the manual may look different from actual items and accessories as they become obsolete for improvements... -
Page 5: Connecting Power Supplies
* Illustrations in the manual may look different from actual items and accessories as they become obsolete for improvements. 3D Monitor 1. Connect the Monitor power cable to the DC 19V terminal on the back of the Monitor 2. Connect the Monitor power cable to the power socket ●... -
Page 6: How To Use
Too close Too far The user can enjoy the most optimal immersive experience when the distance between MOPIC 3D Monitor and the user is about 60 cm (24 inches) apart. The user's head and shoulder should fall within the dotted orange boundaries on the screen, as the pictures below show. -
Page 7: Main Ways To Enjoy Mopic 3D System
1. Insert the USB flash drive that contains contents (mp4 files only) into the USB 3.0 terminal. 2. Click and generate 3D contents on the application main screen. Pressing the F1 button on the box will play the first contents and the rest will follow in sequence ※ Limitations... - Page 8 Full side-by-side Half side-by-side Side-by-side 3D contents refer to the normal display divided into two halves, a left view and a right view, each occupying one-half of the original display area. Each view displays the contents from a slightly different perspective, corresponding to the left and right eye of the viewer.
- Page 9 NORMAL ↔ BLACK Convert between Normal and Noiseless* images DEPTH Push out 3D contents farther LOOP ON ↔ LOOP OFF Repeat selected 3D file of the entire 3D contents HSBS ↔ FSBS Convert between Half Side-By-Side / Full Side-By-Side CAMERA PLAY↔CAMERA HOLD Turn on and off eye-tracking Hide buttons on the screen...
- Page 10 3. By viewing in full screen mode, you can enjoy the 3D contents from your PC or Mac ※Attention ● 3D contents in the PC or Mac must be in half or full SBS (Side By Side), though the file format can be free ● 3D contents must be in full screen mode Buttons on 3D Box...
- Page 11 Buttons on Mplayer3D Screen Mplayer3D screen buttons appear after a click on the middle section of the bottom of the screen. Button Description 3D ↔ 2D Convert between 2D and 3D contents NORMAL ↔ BLACK* Convert between Normal and Noiseless* images DEPTH Push out 3D contents farther HSBS ↔ FSBS...
-
Page 12: Basic Troubleshooting
Basic Troubleshooting To Adjust 3D Settings The product has been pre-adjusted. Please adjust 3D settings that cater to the most optimal 3D immersive experience 1. Click on 3D Settings Click on ( ) to reset the 3D settings 2. Angle Move the cursor to the left or right until the black line becomes parallel to the red line *The red line does not need to be placed right in the middle of the black lines, as long as they are in parallel... -
Page 13: To Confirm 3D Box Settings
*The alignment bar is divided into three zones, blue (60), yellow (65), and red (70) that help measure and deliver the most optimal 3D immersive experience. Please ensure to move the cursor from far left to far right across all three zones multiple times to find the most optimal alignment point, as you will find at least three optimal points across the three zones. -
Page 14: To Confirm 3D Monitor Settings
Click on the JOG button on the back of the Monitor for a few seconds > Upward Arrow Key > Display Settings ● brightness 70 / contrast 75 / sharpness 68 *Note:The product has been pre-adjusted at optimal 3D monitor settings. Please refrain from adjusting the monitor setting as it may deliver poor quality 3D immersive experience For further details, please visit our FAQ page... -
Page 15: Specifications
Specifications 3D System Specifications MODEL NO. U28A750 MAKER MOPIC CO., LTD. Components 3D Monitor, 3D Box (Mplayer3D), RGB Camera Dimensions 28inch (653*376*50 mm) Product weight 4.7kg Resolution 3840*2160 (4K) 3D Monitor Screen Horizontal Orientation Aspect Ratio 16:09 Android 7 2x USB2.0 Host, 1x USB3.0 Host, 1x USB Type-C...
