EtiamPro ECAMIP801 Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECAMIP801 and is the answer not in the manual?

Questions and answers

Summary of Contents for EtiamPro ECAMIP801

  • Page 2: Regulatory Information

    ECAMIP801·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Safety Instruction

    ECAMIP801·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death.
  • Page 4 ECAMIP801·Quick Start Guide Cautions Fire Prevention No naked flame sources, such as lighted candles, should be placed on the equipment. The serial port of the equipment is used for debugging only. Hot Surface CAUTION: Hot parts! Burned fingers when handling the parts.
  • Page 5 ECAMIP801·Quick Start Guide Maintenance If the product does not work properly, please contact your dealer or the nearest service center. We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. A few device components (e.g., electrolytic capacitor) require regular replacement. The average lifespan varies, so periodic checking is recommended.
  • Page 6 ECAMIP801·Quick Start Guide 1 Appearance Lens Microphone Status indicator Speaker Name Description • Solid red: camera starting up. Status indicator • Slow-flashing red: Wi-Fi connection failed. • Fast-flashing red: camera exception (e.g. microSD card error). • Fast-flashing blue: camera ready for Wi-Fi connection.
  • Page 7 ECAMIP801·Quick Start Guide Power input RJ-45 self-adaptive Ethernet port Memory card slot RESET Silicone gasket Name Description Power input Micro USB for power supply, 5 VDC. Plug the power cable into the power input interface to power on the camera.

  • Page 8: Installation

    ECAMIP801·Quick Start Guide 2 Installation 2.1 Install the Memory Card 1. Adjust the tilting position of the camera to expose the removable cover. Removable cover 2. Open the cover to expose the memory card slot and insert the memory card.

  • Page 9: Install The Camera

    ECAMIP801·Quick Start Guide 2.2 Install the Camera 1. Take out the drill template from the package. Paste it to the desired mounting place. 2. Drill two screw holes according to the drill template if you sue expansion screws. 3. Take out the adapter from the package. Align the screw holes and fix the adapter.

  • Page 10: Adjust The Surveillance Angle

    ECAMIP801·Quick Start Guide 4. Fix the adapter into the camera bottom and rotate the camera base clockwise to get it fixed. 2.3 Adjust the Surveillance Angle 1. Rotate the camera body to adjust the panning position. 2. Move the dome drive upwards or downwards to adjust the tilting position.

  • Page 11: Operation

    ECAMIP801·Quick Start Guide 3 Operation 3.1 Power On the Camera Connect the camera to the power adapter with the micro-USB cable and then plug the power adapter into the power outlet. When the blue light flashes, the camera is powered on. You can set the Wi-Fi connection.

  • Page 12: Live View

    ECAMIP801·Quick Start Guide 3.3 Add the Camera to Your Guarding Vision Account NOTE: Start the adding process only when the indicator flashes blue. 1. Connect your mobile phone to a Wi-Fi (5G Wi-Fi is not supported yet). 2. Log into the Guarding Vision app.

  • Page 13: Alarm Notification

    ECAMIP801·Quick Start Guide 4.2 Recording 1. Check the memory card status by tapping on the Storage Status in the Device Settings interface. 2. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event-triggered video in the camera such as motion detection.
  • Page 14 Made in PRC Imported by Velleman Group nv Legen Heirweg 33, 9890 Gavere, Belgium www.velleman.eu...
