MaxR-7202 Mini PCI User's Manual

1. Product Overview

The MaxR-7202 series PCI adapter cards contain an Atheros AR9220 chip

for IEEE 802.11a/b/g/n Wireless LAN applications. The mini PCI adapter

cards support key security features like Wi-Fi Protected Access (WPA),

WPA2, WEP and 802.1x.

The mini PCI card package contains the following item(s):

1 x Wireless Mini PCI Adapter

Shut down the power of the platform

Align the PCI adapter with the Mini PCI socket on the platform

Adjust and push down the PCI adapter gently until the metal locking

levers on the Mini PCI socket is latched. (Please take note that the PCI

adapter can only fit in one direction due to the keyed notch. Wrong

orientation will cause improper installation and may damage the Mini

PCI socket)

Connect the antenna(s) on the mini PCI module

Reboot on the platform

Install drivers if necessary

802.11b/g/n: 2412 ~ 2472 MHz

802.11an: 5180 ~ 5240MHz, 5725 ~ 5850MHz

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the

following measures:

Arada Systems, Inc.

4633 Old Ironsides Drive, Suite 415, Santa Clara, CA95054, USA
