Model No. PFSB61531
Serial No.
The serial number is on a sign
behind the access panel. Write the
serial number in the space above.
Access
Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The technicians on our customer
hot line will provide immediate
assistance, free of charge.
1-877-897-7493
CUSTOMER HOT LINE:
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USERʼS MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Pro-Form ECLIPSE
Summary of Contents for Pro-Form ECLIPSE
- Page 1 USERʼS MANUAL Model No. PFSB61531 Serial No. The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
Table of Contents Posting the Warning Sign ..............2 Important Safety Instructions . -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10. - Page 4 20. DANGER—Risk of electric shock. Keep all physician before using the hydrotherapy spa. electrical appliances such as radios, tele- Pregnant women should not use the spa if phones, televisions, and lights at least five the water temperature is above 100°F; the feet away from the water.
- Page 5 35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.
-
Page 6: Before You Begin
Congratulations for selecting the new PROFORM ® using the hydrotherapy spa If you have questions ECLIPSE hydrotherapy spa. The innovative ECLIPSE spa allows you to enjoy all the benefits of hydrothera- after reading the manual, please call our Customer py in the comfort and privacy of your home. -
Page 7: Choosing A Location For The Hydrotherapy Spa
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa. -
Page 8: Assembly
Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • One phillips screwdriver • Place all parts in a cleared area and remove the packing materials from the spa shell. Do not dis- A wire connector is provided on the electronics pose of the packing materials until assembly is pack of the spa to connect a minimum No. - Page 9 3. Locate the three pillows. Each pillow can be Pillow attached to the spa shell in a high position or a low position. To determine the high and low positions, Pillow Pillow attach one pillow to the spa shell, note its position, remove it, turn it 180°, and then re-attach it.
-
Page 10: Using The Hydrotherapy Spa
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat five adults. the GFCI “test” button. The spa should shut off. Press The spa holds 295 gallons of water and offers a heat- the “reset” button. The spa should resume normal ing system (80°F to 104°F), a filtration system, and operation. -
Page 11: Spa Shell Diagram
Spa Shell Diagram H. The skimmer cleans the surface of the water. Refer to the diagram above. The function of each component is explained below. I. The temperature probe monitors water temperature. A. The four adjustable, directional jets can be pivot- J. -
Page 12: Using The Controls
Using the Controls Console Waterfall knob Display Air Control L Air Control M Temperature Light Temperature Up Button Button Button Down Button Air Controls: Determine the amount of air flowing Refer to the diagram above. The function of each control is explained below: through the spa jets during operation. -
Page 13: Maintenance
Maintenance MAINTAINING THE SPA COVER The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to properly maintain your spa. The spa cover should be cleaned monthly. To clean the spa cover, use water and a non-abrasive cleaner MAINTENANCE SCHEDULE on the entire cover. - Page 14 WATER CHEMISTRY ATTACHING AND REMOVING ACCESS PANEL CAUTION: The chemicals used to maintain the pH To locate the access panel, refer to the drawing balance of the water and to sanitize the water can below. Turn off the power to the spa. To remove the be dangerous.
- Page 15 WINTER USE AND CARE To drain the hydrotherapy spa, follow the steps below: 1. Using the console, adjust the temperature to the The hydrotherapy spa is designed for year-round use. lowest setting. If you decide to store the spa for the winter, store it in 2.
-
Page 16: Troubleshooting
Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1. - Page 17 10. SYMPTOM: THE SPA JET UNIT CONTINUES 12. SYMPTOM: THE CONSOLE DISPLAYS THE TO RUN AFTER IT HAS BEEN SHUT OFF WORDS “COOL” OR “ICE” a. The spa jets are controlled with the jet button. If a. This is a normal function of the spa; no action the button is pressed once, the spa jets will run is necessary.
-
Page 18: Part List
Part List—Model No. PFSB61531 R0703A Key No. Qty. Description Key No. Qty. Description Thermometer Fitting Cover Ring Access Panel Nozzle Housing Face Ring Nozzle Retainer Ring Small Rotator 1/4” Washer Short Panel Rotator Pivot Ring Light Cover, Red #10 x 2” Sheet Metal Screw Light Cover, Blue Filter Cover 1/4”... -
Page 19: Exploded Drawing
Exploded Drawing—Model No. PFSB61531 R0703A... -
Page 20: Ordering Replacement Parts
• The MODEL NUMBER of the product (PFSB61531) • The NAME of the product (PROFORM ECLIPSE hydrotherapy spa) ® • The SERIAL NUMBER of the product (see the front cover of this manual) •...
