AV Link 100.596UK User Manual

An amazing and compact Bluetooth device that will open a new world of wireless audio enjoyment both at home or on
the move. Simply connect using the audio cable provided to your TV, projector or other audio device and stream
wirelessly to Bluetooth headphones, speakers or sound-bars. Alternatively connect to a set of traditional headphones,
amplifier or in-car entertainment system and you can then pair with your smartphone, tablet or other Bluetooth devices.
With Multi-point support for shared listening, a 10m transmission/reception range and in-built rechargeable battery
providing up to 8 hours playback from a single charge, this handy little device really is your perfect Bluetooth partner!
• Make any device with a 3.5mm or RCA audio connection Bluetooth compatible
• Improved design that's compact and easier to use
• Transmitter will connect Bluetooth headphones, speakers or sound-bars to LED TV's and projectors
• Receiver will connect smartphones, tablets and MP3 players to headphones, amplifiers or car audio systems
• Multi-point Bluetooth capability allows you to connect to 2 devices at the same time, ideal for shared listening
• Wireless Bluetooth range of up to 10m
• Transmits audio for up to 8 hours on a single charge
• Receives audio for up to 6 hours on a single charge

Technical Specifications

Bluetooth version
Bluetooth profile
Bluetooth range
Operating time
Charge time
Battery
Dimensions
Weight

Overview

www.avsl.com
Bluetooth 2-in-1 Transmitter & Receiver
v4.2 with multipoint support
APTX, A2DP, AVRCP
Up to 10m (in clear line of sight)
Up to 8 hours (transmit), 6 hours (receive)
2 hours
200mAh
42 x 42 x 10mm
20g

Powering on/off:

Press and hold the Multifunction button (2) until the LED light (3)
goes blue. To power off, press and hold the Mulitifunction button
again until the LED light goes red, indicating the unit is power down
mode.

Pairing with your device in Transmission mode:

Insert the 3.5mm audio lead provided into the input/output socket
(1) on the back of the unit and the other end into the piece of
equipment you wish to send the audio from (i.e the headphone
socket on a TV, projector, stereo system or MP3 player). Set the
TX/RX switch to transmitter mode (5) and press and hold the
Multifunction button until the LED blinks blue quickly, this is to
indicate the unit is now in Bluetooth transmission pairing mode. Set
your Bluetooth headphones, speakers or sound-bar to pairing mode
and wait for the devices to connect. Please be aware that due to the
different protocols of some devices the connection time can be a few
minutes. If after this time you are still unsuccessful, turn off both
devices and try again. Once connected successfully, a voice message
can be heard and the LED on the unit blinks blue intermittently.
BTTR2
Item ref: 100.596UK
User Manual
100.596UK
