Monument Grills 98523 Assembly & Operating Instructions

Natural gas grill conversion kit
Hide thumbs

Advertisement

Quick Links

Download this manual
ASSEMBLY & OPERATING INSTRUCTIONS
Model Parts-------------------------------------------------------------2
Natural Gas Conversion ---------------------------------------------3
Gas Leak Checking---------------------------------------------------12
Product Registration Card-------------------------------------------13
Warranty
One-Year Full Warranty on Part
If this part fails due to defective material or workmanship within
one year from the date of purchase, call 1-888-980-4933 to
arrange for a free repair (or replacement if repair proves
impossible)
Model NO.98523
Natural Gas Grill Conversion Kit

Table of Contents

C043100-A2

Advertisement

loading
Need help?

Need help?

Do you have a question about the 98523 and is the answer not in the manual?

Questions and answers

Summary of Contents for Monument Grills 98523

  • Page 1: Table Of Contents

    ASSEMBLY & OPERATING INSTRUCTIONS Model NO.98523 Natural Gas Grill Conversion Kit Table of Contents Model Parts-------------------------------------------------------------2 Natural Gas Conversion ---------------------------------------------3 Natural Gas Conversion For Model 41847NG --- -----------4-7 Natural Gas Conversion For Model 77352NG --------------8-11 Gas Leak Checking---------------------------------------------------12 Product Registration Card-------------------------------------------13...

  • Page 2: Model Parts

    Model 98523 Parts NG Hose+Quick Connector NG Regulator A02120849 A02120848 Slot Screwdriver Orifice Sockets A02120843 A02120844 Reminder: Please keep the main burner brass LP orifices ,Side Burner Orifice and original LP regulator. just in case you wish to change back from NG to Propane.

  • Page 3: Natural Gas Conversion

    Natural Gas Conversion WARNING! FAILURE TO HEED THESE WARNINGS COULD RESULT IN A FIRE OR EXPLOSION THAT COULD CAUSE SERIOUS BODILY INJURY, DEATH OR PROPERTY DAMAGE. Natural Gas Conversion must be performed by a QUALIFIED GAS TECHNICIAN ONLY. The QUALIFIED GAS TECHNICIAN should ensure compliance of local codes, including but not limited to, requirements and installation of grill regulator.

  • Page 4: Natural Gas Conversion For Model 41847Ng

    GAS CONVERSION FOR MODEL 41847NG 1. Turn off the main gas supply valve. 2. Disconnect LP gas fuel tank (if present). 3. Turn off all burner control valves. 4. Remove the LP gas fuel tank (if present) from the grill cart. 5.
  • Page 5 Make Gas Connection- FOR MODEL 41847NG 1.Pass the NG hose to grill cart through the back panel 2.Connect the brass connector on one end of the 10 ft (3.0m) PVC flexible gas supply hose to the Natural gas pressure regulator 3.Connect the quick connector on the other end of the 10 ft (3.0 m) PVC flexible gas supply hose to the rigid Natural gas supply pipe.
  • Page 6 Change Grill Main Burner Valve Orifices- FOR MODEL 41847NG 1. Remove the grates and flame tamers. 2. Push back the Clamp Spring which hold the burner in place,the clamp spring will drop off to grease tray or grill cart 3.Remove the burner from the grill by lifting the burner out 4:Use a 6 mm socket and wrench or 6 mm nut driver to remove the LP brass orifice from the end of gas valve.
  • Page 7 Change the Side Burner Orifice- - FOR MODEL 41847NG The NG Side Burrne Orifice is packed in grill with individual bag marked for NG gas conversion only. Removee the LP Side Burner Orifice,and install the NG Side Burner Orifice Reminder: Please keep the LP Side Burner Orifice.

  • Page 8: Natural Gas Conversion For Model 77352Ng

    GAS CONVERSIONS- FOR MODEL 77352NG 1. Turn off the main gas supply valve. 2. Disconnect LP gas fuel tank (if present). 3. Turn off all burner control valves. 4. Remove the LP gas fuel tank (if present) from the grill cart. 5.
  • Page 9 Make Gas Connection- FOR MODEL 77352NG 1.Pass the NG hose to grill cart through the back panel 2.Connect the brass connector on one end of the 10 ft (3.0m) PVC flexible gas supply hose to the Natural gas pressure regulator 3.Connect the quick connector on the other end of the 10 ft (3.0 m) PVC flexible gas supply hose to the rigid Natural gas supply pipe.
  • Page 10 Change Grill Main Burner Valve Orifices- FOR MODEL 77352NG 1. Remove the grates and flame tamers. 2. Push back the Clamp Spring which hold the burner in place,the clamp spring will drop off to grease tray or grill cart 3.Remove the burner from the grill by lifting the burner out 4:Use a 6 mm socket and wrench or 6 mm nut driver to remove the LP brass orifice from the end of gas valve.
  • Page 11 Change the Side Burner Orifice- FOR MODEL 77352NG The NG Side Burrne Orifice is packed in grill with individual bag marked for NG gas conversion only. Remove the LP Side Burner Orifice,and install the NG Side Burner Orifice Reminder: Please keep the LP Side Burner Orifice. Just in case you want to change back from NG to Propane.

  • Page 12: Gas Leak Checking

    Procedures for gas leaks checking soap 50 % 50 %...

  • Page 13: Product Registration Card

    WWW.MONUMENTGRILLS.COM Product Registration Card It is simple! Complete and mail your Product Registration Card with the Copy of the Receipt today! Last name: ______________ First Name: _______________ Address: _______________City: _________ State: _______ Zip: ____________ Phone: __________ Email: ______________ Place of purchase: ___________ Model Number: ___________...
