The MAST is a rapidly-deployable cellular antenna solution, designed in a rugged, rolling case for easy transportation.
The MAST kit includes marine-grade directional and omni-directional antennas that securely mount to a sturdy,
adjustable-height, tripod base. With its rugged design, portability, and ease of deployment, the MAST is an excellent
external tripod antenna solution for temporary deployments.
2.
10.
13.
1.
1a.
DH Wireless Solutions
ASSEMBLY GUIDE
3a.
3.
Enhanced view of
extension mechanism
(in collapsed position)
6.
6a.
9.
12.
11.
Deployment instructions on next page.

Components

1. Tripod
a. Tripod Leg Spikes
2. Omni-directional antenna
3. Directional antenna
a. Directional antenna mount
4. 30' Cable Extension (Omni Directional Antenna)
5. 50' Cable Extension (Directional Antenna)
6. Antenna Mount
a. Antenna Mount Retention Knob
7. Tether Ring Disc
8. Tie Down Cords with Tether hooks - 3 (in accessory bag)
9. Antenna Column Retention Knob
10. Antenna Column
11. Elevating Column Retention Knob
12. Elevating Column Crank
13. Tripod Elevating Column
14. Tie Down Stakes - 4 (in accessory bag)
15. Reusable Beaded Cable Ties – 3 (in accessory bag)
8.
14.
15.
4.
|
877.524.0430
|
7.
5.
www.portablessupport.com
