- Page 1 TECHNICAL INFORMATION MANUAL Revision 0.1 – 25 November 2021 R1210I trID RAIN RFID Smart Tray Reader...
-
Page 2: Scope Of Manual
All you need to start using your reader in a few clicks! Scope of Manual The goal of this manual is to provide the basic information to work with the trID R1210I RAIN RFID Smart Tray Reader. Change Document Record... - Page 3 Federal Communications Commission (FCC) Notice (Preliminary) This device was tested and found to comply with the limits set forth in Part 15 of the FCC Rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
-
Page 4: Table Of Contents
Bottom panel ..................................7 Charging ..................................8 USB connector ................................8 Ordering Options ..................................8 Technical Specifications ..............................9 Technical Specifications Table..............................9 Technical Drawings .................................10 Regulatory Compliance ..............................12 FCC Compliance ..................................12 RoHS EU Directive ...................................12 INDEX - trID R1210I - Technical Information Manual... - Page 5 Fig. 1.3: Bottom Panel ..................................7 Fig. 2.1: trID R1210I Technical Drawings – 3D view ........................10 Fig. 2.2: trID R1210I Technical Drawings – Front panel view ......................10 Fig. 2.3: trID R1210I Technical Drawings – Back panel view ......................11 List of Tables Tab.
-
Page 6: Introduction
INTRODUCTION 1 INTRODUCTION Description The trID (Model R1210I) is a slim RAIN RFID reader of the easy2read product line with integrated antenna © for short range applications. The reader hosts an internal rechargeable battery and can operate both in wired mode, using a USB cable, or in wireless mode through the Bluetooth ®... -
Page 7: Front Panel
Front panel The trID R1210I front panel houses the following buttons and icon (see figure below): Fig. 1.2: Front Panel Bottom panel Fig. 1.3: Bottom Panel Name Description Reset A Hardware Reset can be achieved via the Reset hole Press the button to switch on the reader, press for at least 2 seconds to switch it Power button Indicates the Bluetooth connection (see §... -
Page 8: Charging
USB connector A USB Type C socket connector is located in the bottom side of the trID R1210I (see § Fig. 1.3: Bottom Panel page 7) and can be used to connect the reader to an USB host port or to an AC/DC battery charger. -
Page 9: Technical Specifications
Warning: The RF settings must match the operating country/region to comply with local laws and regulations. The usage of the reader in different countries/regions from the one in which the device has been sold is not allowed. TECHNICAL SPECIFICATIONS – trID R1210I - Technical Information Manual... -
Page 10: Technical Drawings
Technical Drawings The following drawings show the R1210I trID from different points of view. All dimensions are in millimeters. Fig. 2.1: trID R1210I Technical Drawings – 3D view Fig. 2.2: trID R1210I Technical Drawings – Front panel view TECHNICAL SPECIFICATIONS - trID R1210I - Technical Information Manual... -
Page 11: Fig. 2.3: Trid R1210I Technical Drawings - Back Panel View
Fig. 2.3: trID R1210I Technical Drawings – Back panel view TECHNICAL SPECIFICATIONS - trID R1210I - Technical Information Manual... -
Page 12: Regulatory Compliance
RoHS EU Directive The trID R1210I Reader is compliant with the EU Directive 2015/863/EU on the Restriction of the Use of certain Hazardous Substances in Electrical and Electronic Equipment (RoHS3). REGULATORY COMPLIANCE – trID R1210I - Technical Information Manual...
