EVX ZOOTER S3 USER INSTRUCTIONS
EVx : ZOOTER S3 Electric Scooter
Owner's User Manual
This User manual is applicable to the following models:
EVM model number
A product proudly supplied to you by EVM Solutions (Pty) Ltd

EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130

info@evx.co.za

PRODUCT CODE
2022-1.75/1.56- 0-
2022
WHITE
2022-1.75/1.56- 0-
2022
RED
          Support : 07 28 42 42 82
DESCRIPTION /MODEL
S3 SCOOTER :1.75KW /
60V26Ah (1,560Wh) Lithium
battery (Portable);
S3 SCOOTER :1.75KW /
60V26Ah (1,560Wh) Lithium
battery (Portable);
Document Number: 200-2022-301-3


COLOUR
WHITE
RED
 www.evx.co.za

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZOOSTER S3 and is the answer not in the manual?

Questions and answers

Summary of Contents for EVX ZOOSTER S3

  • Page 1     EVX ZOOTER S3 USER INSTRUCTIONS EVx : ZOOTER S3 Electric Scooter Owner’s User Manual This User manual is applicable to the following models: EVM model number PRODUCT CODE DESCRIPTION /MODEL COLOUR S3 SCOOTER :1.75KW / 2022-1.75/1.56- 0- 2022...
  • Page 2 Our products combine the latest innovations in Battery Electric Technology to offer low cost of ownership to our customers. The EVx team is constantly searching for new solutions to challenge the current status quo, breaking down barriers to technology and offer unique solutions to our customers mobility requirements.

  • Page 3: Warranty And Safety Information

    Be sure you are familiar with the positions and functions of all the controls and instruments provided on you EVx e-Scooter. If you have any doubts, contact us by sending us an email at info@evx.co.za Be assured we will be there for your support to ensure you will enjoy a long-lasting experience with your e-Scooter.
  • Page 4   3.GETTING TO KNOW YOUR e-SCOOTER         EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 5 Indicates right turn intention Park Indicator 12  Vehicle in Park mode Recovery Indicator 13  Indicates “limp home” mode in case of Failure Warning (7)   Ride Mode  Economy 1  Cruising 2  Sport 3    EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 6 Detail of Instrument Panel       EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 7 “P” is cancelled. ④ Recover button When the instrument panel indicates a failure warning on the Motor/Controller/Brakes/Accelerator, press this button, to ride slowly to the nearest service center for repairs.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 8 (2) seconds, and the e-Scooter will be in the “Powered” state without key. ④ Search key Press this switch within 50m, your e-Scooter will emit a sound to enable you to find your e-Scooter with ease.     EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...

  • Page 9: Charging The Battery

    3.PREPERATION FOR FIRST USE Charging the Battery The EVx e-Scooter’s comes with a high-capacity Lithium Ion rechargeable battery. The battery needs to be fully charged before your first use. The intelligent charger that came with your e-Scooter will control the battery pack charging and will automatically end charging when the battery is fully charged.
  • Page 10 Do not place anything over the charger or cover its body while it is charging. The charger can become warm during charging. Do not use the charger in wet areas or in rain. Do not drop the charger or subject to high vibration. Note: If your battery is low, you should first charge it to a proper state before driving   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 11 FIGURE 3 : BATTERY COMPARTMENT In Figure 3 : ① Indicate Battery Connector ② Indicate Isolator Switch ③ Indicate Battery Lock For your own safety, turn off the battery isolator switch ② prior to cleaning, long term storage, or removing the battery pack STEP 2 Switch the Isolator switch ②to OFF. Figure 4: Battery Isolator Switch, on and off position shown in position ②in Figure 3   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 12 FIGURE 5: BATTERY CABLE CONNECTOR AND LOCK CAP STEP 4 Unlock the Battery by inserting the e-Scooter key in the battery lock ③ shown in Figure 3. Turn the key anti clockwise to unlock the battery case. FIGURE 6: BATTERY UNLOCK/LOCK   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 13   Charging the battery out of the e‐Scooter. Remove the battery from your e-Scooter as described in the section above. Position the battery and the Charger in a safe dry place, out of reach of children FIGURE 8 : CHARGER CONNECTED TO THE BATTERY   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 14  When the charger is charging the battery, the indicator LED will blink green When the charger is complete, the charger will stop blinking and will just be GREEN.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 15 Storage conditions: ambient temperature: 20 to 35 °C, humidity < 65% RH;  When storing the charger, please disconnect it from the battery.  Regular maintenance can enhance the service life and driving safety of the e-Scooter.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 16 Preparing and testing before you take the e‐Scooter to ride. If you are not an experienced e-Scooter, or have only recently obtained a e-Scooter driver’s   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 17  Whether the rear mirrors are clean. Adjust them to the appropriate angle.  Whether the brake fluid is sufficient, and whether the brake levers and brake system work normally. For any abnormality or operational concern, please contact local Customer Service Center.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 18 If the Throttle is rotated the e-Scooter will start moving. ( If the side stand is retracted) Fig 11a Fig 11b Fig 11c Figure 11 : Park mode and switching to drive mode To start driving. The e-Scooter is now in READY mode and will start moving if the Throttle is rotated. Be careful not to rotate the Throttle if you are not ready to start driving.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 19 Note: If you omit to release the side stand –the e-Scooter will not start to drive as a switch on the side stand monitor if the stand had been retracted or not. Figure 13: Side stand engaged   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 20 Changing the Power Mode The power mode lever (shifter) is located on the right side of the handlebar when seated (See figure 12).   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 21 Figure 15 b Power mode setting displayed Figure 15: Adjusting the power modes The power mode shifting system is fully automatic- there is no need to reduce speed or adjust your throttle when changing the power modes up or down.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 22 After a few rides, you will get a sense of the electric e-Scooter’s range capability. Expect lower range when driving in windy conditions and in a hilly terrain. Factors that will decrease range: • Rapid accelerations using the motor • Uphill riding   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...

  • Page 23: Maintenance And Care

    The battery’s capacity will be temporarily reduced in cold environments. We recommend removing the battery and store the battery in a sheltered place if the e-Scooter is not in use and has to be kept outdoors for long periods.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 24 The Fluid level should be above the mark indicated in figure 17b.To fill the fluid up – remove the two screws shown in Figure 17 a, remove the lid and top up the fluid. Use only DOT 3 or Dot 4 certified brake fluid.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 25 ■TIPS: Please switch off the isolator switch before cleaning. Do not use strong water jet to directly wash it, so as to avoid the fault of mechanical parts caused by being damped.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 26 Repair handlebar or handlebar lock Steering handlebar failure or lock move. failure Re connect the main plug to battery. The controller plug is loose. Change controller Controller failure.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...

  • Page 27: Safety Information

    Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots. Perform a basic check each time before riding, so as to confirm the operational readiness of   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 28 • Do not jump with the electric e-Scooter. (This e-Scooter is not for extreme sports) • The motor can get hot, do not touch the body of the motor after riding.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...
  • Page 29 Seat S3  SP009LN  Battery Charger  SP010LN  Rear Mirror (RH) S3  SP011LN  Rear Mirror (LH) S3  SP012LN  Indicator Left Front S3  SP013LN  Indicator Right Front S3  SP014LN  Indicator Left Back S3  SP015LN  Indicator Right Back S3  SP016LN  Side Stand S3  SP017LN  Please contact your agent or EVx support for spare parts not listed above.   EVM Solutions (Pty) Ltd 210 Main Street, Somerset West, Western Cape, South Africa, 7130     info@evx.co.za            Support : 07 28 42 42 82          www.evx.co.za  Document Number: 200-2022-301-3...

  • Page 30: Repair Or Service

    Before you store your e-Scooter, we recommend you clean your e-Scooter and wipe off all dirt. EVx recommends that you store your e-Scooter indoors if possible, out of rain, dust or harsh direct sun. If you have to store the e-Scooter outdoors, we recommend you use a suitable cover.
  • Page 31 Be sure to understand and follow all local laws & regulations and to have maintenance/repairs done by an authorized EVx dealer. Don’t use/ride any EVx product in ways unintended by the manufacturer and don’t exceed the weight limit of any product.

  • Page 32: Warranty Period

    Warranty Exclusions: The intent of this warranty is to ensure that the BUYER of any new PRODUCTS sold by EVX or any EVX product sold by an authorized EVX dealer will receive a quality product, free of manufacturing flaws. This warranty should not be...

  • Page 33: Warranty Claims Process

    EVx will not pay for return shipping on any damaged or defective product or component. EVx will not cover any damage that may occur during shipping if the owner sets up their own shipping option or if the e- Scooter is shipped using a freight forwarder or similar service.
