Quick Start Guide
Mini Wireless Screen Sharing
Guide de démarrage rapide
Mini Partage d'Écran Sans Fil
GWAVRD
PART NO. Q1670

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GWAVRD Q1670 and is the answer not in the manual?

Questions and answers

Summary of Contents for IOGear GWAVRD Q1670

  • Page 1 Quick Start Guide Mini Wireless Screen Sharing Guide de démarrage rapide Mini Partage d'Écran Sans Fil GWAVRD PART NO. Q1670...
  • Page 2: Package Contents

    Package Contents 1 x GWAVRD 1 x Quick Start Guide 1 x Warranty Card System Requirements • Intel Core™ i5 2nd Gen ® • 4GB or more of system memory (RAM) • Windows ® • macOS 10.14 Mojave or later ®...
  • Page 3: Product Overview

    Product Overview USB-A power input connector* HDMI connector for connection to TV HDMI input port *Can be connected to USB-A connector on TV or wall plug. Please note that the wall plug adapter is not provided in the kit. Connection Diagram Source...
  • Page 4: Hardware Installation

    Hardware Installation 1. Plug the HDMI side of the GWAVRD to an HDMI input port on your TV. 2. Plug the USB-A male to a USB port on your TV. Some TV only use the USB port for firmware upgrade only, in this case you will need a separate wall power adapter (not included in the kit).
  • Page 5 Hardware Installation (continued) Look at the connection status below, if you are connected to the GWAVRD, the X will change to a ( 1 ) Connection Speeds May Vary 5. Open your browser on the connected device. Type 192.168.203.1 in the address bar and you will be taken to the router selection page.
  • Page 6 6. Choose your local network SSID and input the password. Click OK. Your IOGEARCast device will now be included in your network for access from anywhere in your network.
  • Page 7 7. When you are connected to your router, the name of your router will appear between the GWAVRD and the wireless router icon. NETGEAR78-5G ( 1 ) Connection Speeds May Vary 8. Once that is done you can reconnect to your own router on your PC or phone and you will be able to connect to the GWAVRD anytime it is turned on using Miracast or Airplay.
  • Page 8 9. Depending on your device, please follow the steps below: Windows 10+ – Hold down Windows key + P or go to Settings > Display and choose “Connect to a wireless display”. The GWAVRD will show up as IOGEARCast-xxxxxx, click on it and you will be able to cast your content to your display either in mirror mode or extend mode depending on how you set this up in your display settings.
  • Page 9 10. This is a 1 to 1 device and any new connections will need the connected device to be disconnected first before another device can be connected to the GWAVRD. *Please note that you only have to connect to your router using the browser only once.
  • Page 10: Limited Warranty

    Limited Warranty Warranty Information This product carries a 1 Year Limited Warranty. For the terms and conditions of this warranty, please go to https://www.iogear.com/support/warranty Register online at https://www.iogear.com/register Important Product Information Product Model _____________ Serial Number _____________...
  • Page 11 Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR https://iogear.custhelp.com support@iogear.com www.iogear.com...
  • Page 12: Compliance Information

    Compliance Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 13: Contenu Du Colis

    Contenu du colis 1 x GWAVRD 1 x guide de démarrage rapide 1 x carte de garantie Configuration Requise • Intel Core i5 2e génération • 4GB ou plus de mémoire système (RAM) • Windows ® • macOS 10.14 Mojave ou version ultérieure ®...
  • Page 14: Présentation Du Produit

    Présentation du Produit Connecteur d'entrée d'alimentation USB-A* Connecteur HDMI pour la connexion au port d'entrée HDMI du téléviseur *Peut être connecté au connecteur USB-A d'un téléviseur ou d'une prise murale. S'il te plaît notez que l'adaptateur de prise murale n'est pas fourni dans le kit.
  • Page 15: Installation Du Matériel

    Installation du Matériel 1. Branchez le GWAVRD sur un port d'entrée HDMI de votre téléviseur. 2. Branchez l'USB-A mâle sur un port USB de votre téléviseur. Certains téléviseurs n'utilisent le port USB que pour la mise à niveau du micrologiciel, dans ce cas, vous aurez besoin d'un adaptateur secteur mural séparé...
  • Page 16 Regardez l'état de la connexion ci-dessous, si vous êtes connecté au GWAVRD, le X deviendra un ( 1 ) Connection Speeds May Vary 5. Ouvrez votre navigateur sur l'appareil connecté. Tapez 192.168.203.1 dans la barre d'adresse et vous serez redirigé vers la page de sélection du routeur.
  • Page 17 6. Choisissez le SSID de votre réseau local et entrez le mot de passe. Cliquez sur OK. Votre appareil IOGEARCast sera désormais inclus dans votre réseau pour un accès depuis n'importe où dans votre réseau.
  • Page 18 7. Lorsque vous êtes connecté à votre routeur, le nom de votre routeur apparaîtra entre le GWAVRD et l'icône du routeur sans fil. ( 1 ) NETGEAR78-5G Connection Speeds May Vary 8. Une fois cela fait, vous pouvez vous reconnecter à votre propre routeur sur votre PC ou votre téléphone et vous pourrez vous connecter au GWAVRD à...
  • Page 19 9. En fonction de votre appareil, veuillez suivre les étapes ci-dessous. Windows 10+ – Maintenez la touche Windows + P ou allez dans Paramètres > Affichage et choisissez “Se connecter à un écran sans fil”. Le GWAVRD apparaîtra sous le nom IOGEARCast-xxxxxx, cliquez dessus et vous pourrez maintenant diffuser votre contenu sur votre écran en mode miroir ou en mode étendu, quelle que soit la configuration définie dans vos paramètres...
  • Page 20 iPhone - Selon le modèle de votre iPhone, balayez vers le haut ou vers le bas pour accéder à l'application Screen Mirroring. Sélectionnez Screen Mirroring. À partir de cet écran, choisissez l'appareil sur lequel vous souhaitez diffuser etl'écran de votre iPhone sera reflété...
  • Page 21: Garantie Limitée

    Renseignements sur la garantie Ce produit comporte une garantie limitée de 1 an. Pour connaître les modalités de cette garantie,veuillez aller à https://www.iogear.com/support/warranty Inscrivez-vous en ligne à https://www.iogear.com/register Renseignements importants sur le produit Modèle du produit ___________________ Numéro de série ___________________...
  • Page 22 Contact NOUS SOMMES LÀ POUR VOUS AIDER! BESOIN D'AIDE POUR LA CONFIGURATION DE CE PRODUIT? Assurez-vous de: 1. Visiter www.iogear.com pour plus d'information sur le produit 2. Visiter www.iogear.com/support pour obtenir de l'aide et un soutien technique en ligne IOGEAR https://iogear.custhelp.com...
  • Page 23 Déclaration de Conformité Información de Conformidad Recommandation en matière d’interférence de la Federal Communications Commission Cet appareil respecte les limites des caractéristiques d'immunité des appareils numériques définies pour la classe B, conformément au chapitre 15 de la réglementation de la FCC. La conformité...
