Summary of Contents for Toolex Industrial 595185
-
Page 2: Ec Declaration Of Conformity
Product : Scissor Lifting Table Type Designation /Trademark : 595185 Manufacturers Name : Toolex Industrial Manufacturers Address : PO Box 1012 Hamilton NSW 2303 Australia Refer to in this declaration conforms to the following directive(s): Machinery Directive 2006/42/EC The company named above will keep on file for review the following technical documentation: Operating and maintenance instructions •... - Page 3 Ⅰ.Configuration diagram II. Main technical parameters： Model 595185 Capacity 300/500 Max. lift height H Min. height of table h Table size 815×500×50 Handle height A Overall length B Foot pedal cycles to max. height ≤32/≤45 Wheel diameter D Working volume of oil cylinder Oil capacity Service weight 75/85...
-
Page 4: Operation Methods
13. When maintaining and repairing truck, stand bar should be used to support fork arm in order to prevent table from falling (there should be no goods on table), and guarantee the safety in maintenance and repairing. 14. Please operate strictly according to “notes (warning)”, otherwise it will bring damage to truck and human body. VI. - Page 5 See the principle diagram of the hydraulic system in the attached drawing (3) Page 4...
- Page 6 Working cylinder Oil pump One-way valve One-way valve Throttle valve Safety valve Unloading valce Principle specification Oil reservoir 1. The restriction chock and the constant pressure overflow valve leak oil at the same when no-load, the no-load vehicle descend faster, and it can meet the customers the demand。...
-
Page 7: Spare Parts Catalogue
Spare parts catalogue 1. Explosive drawing and parts list of handle 2. Explosive drawing and parts list of 595185 pump 3. Explosive drawing and parts list of 595185 assembly Page 6... - Page 8 Explosive Drawing and Parts List of Handle Drawing no. Description Qty. Remark Spring pin 6x30 GB879-86 Handle bar SPAⅢ.1.01 Knob SPⅢ.1.02 Nut M8 GB6172-86 Screw SPⅢ.0-01 Pull rod 1200(1020) Page 7...
- Page 9 Explosive Drawing of 595185 pump Page 8...
- Page 10 Parts List of 595185 pump Drawing no. Description Qty. Remark GB3452.1-86 0-ring 22.4×2.65 SP.8-11A Pump cylinder SP500(A) SP.8-11 Pump cylinder SP300(A) UHS18 Yx- seal ring 300KGS UHS14 Yx- seal ring 500KGS DH18 Dust ring 300KGS DH14 Dust ring 500KGS SP.8-10 Pump plunger 300KGS SP.8-10A...
- Page 11 Explosive drawing of 595185 assembly Page 10...
- Page 12 Parts List of 595185 assembly Drawing No. Description Qty. Remark SP .1-00 Handle bar GB5781-2000 Bolt M8×25 GB95-1985 Washer 8 GB93-1987 Washer 8 GB41-86 Nut M8 Universal Wheel 5″ SP.4-00 SPC.5-00 Frame SP.0-08 Shaft SP.0-04 Wheel 5” GB894.1-86 Retaining rng for axle 12 SP.0-11 Shaft SP.0-12...
