Summary of Contents for Overview EVD204AN
- Page 1 Dual Monitor Desk Mount EVD204AN customerservice@everviewmount.com...
- Page 2 WARNING! WARNING! SEVERE PERSONAL INJURY AND PROPERTY DAMAGE CAN RESULT FROM IMPROPER INSTALLATION OR ASSEMBLY. READ THE FOLLOWING WARNINGS BEFORE BEGINNING. If you do not understand the instructions or have any concerns or questions, please contact a qualified installer. Do not install or assemble if the product or hardware is damaged or missing. Not all parts and hardware included must be used.
- Page 3 Supplied Hardware M4X12MM M4X30MM A(8PCS) B(8PCS) C(8PCS) D1(1PCS) D2(1PCS) allen wrench 5x5 allen wrench 4x4 M6X12MM M8X10MM M6X8MM E1(1PCS) E2(2PCS) E3(2PCS) F1(1PCS) F2(1PCS) (1PCS)
- Page 4 Step 1A Install the Base (C Clamp Mount) tighten Step1 Step2 table top thickness:0-10CM(0-3.9in) tighten...
- Page 5 Step 1B Install the Base (Grommet Mount) table top thickness: 0-8CM(0-3.15in) Step 2 Assemble Arms...
- Page 6 tighten Step 3 Attach VESA Plates to the Back of Monitors...
- Page 7 Step 4 Hang the Monitor to the Mount vertically adjustable Cable management To level the monitors, and turn the bolt with the Allen key (F2) to raise or lower 2x Cable tie the monitor.
- Page 8 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us. Email：customerservice@everviewmount.com...
