Summary of Contents for Mayer Magnum Series
- Page 1 46 Bottles Wine Cooler MMWC46MAG...
-
Page 2: Table Of Contents
Contents Environmental note Important safety information 4–5 Dimensions Description of the appliance Control panel Description of the product features Using your wine cabinet 9-15 Before switching on Switching on the appliance and setting the temperature Changing between Fahrenheit and Celsius The humidity control box ACTIVE CHARCOAL FILTER Loading the wine cabinet... -
Page 3: Environmental Note
Environmental note Note: behind the appliance to prevent misuse. This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). -
Page 4: Important Safety Information
Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Retailer where you purchased your unit from. - Page 5 Child safety o Packaging material should be kept away from children. o Children should not be allowed to touch the controls or play with the appliance. General safety o Do not pull on the power supply cable to remove the plug from your mains supply socket.
-
Page 6: Dimensions
Dimensions of appliance Height: 820 - 860 mm Width: 595 mm Depth: 570 mm that you will require. o Gross capacity: 145 litres o Net capacity: 138 litres o Bottle capacity: 46 x 0.75 litre Bordeaux style wine bottles o Noise level: 41 dB o Electronic push button control operation o LED display o Celsius and Fahrenheit switch... -
Page 7: Description Of The Appliance
IMPORTANT: When you install your appliance it is important to bear in mind its climatic rating. rating plate will indicate the ambient temperature range that your appliance will function correctly within. Model number ……………………………………………… Serial number ……………………………………………… Date of purchase …………………………………………….. Description of the appliance 1. -
Page 8: Control Panel
Control panel The control panel is located in the middle of the appliance. 1. Light ON/OFF control button 4. Lower zone display 2. Zone selection button 5. Temperature plus button 3. Upper zone display 6. Temperature minus button This icon indicates that the control panel is for the upper cooling zone. This icon indicates that the control panel is for the lower cooling zone. -
Page 9: Using Your Wine Cabinet
The wine cabinet shelves The wooden shelves are fully adjustable to suit various wine bottle shapes and sizes. To prevent damaging the door gasket, make sure the door is fully open when pulling shelves out of the rail compartment. For easy access to the bottles stored, pull the shelves out approximately 1/3. Using your wine cabinet Before switching on After delivery, wait for eight hours before connecting the appliance to your mains... -
Page 10: Switching On The Appliance And Setting The Temperature
Switching on the appliance and setting the temperature To switch the appliance on, press the light ON/OFF control button (1) and the zone selection button (2) simultaneously for 5 seconds. The temperature for each zone will need to be set individually. The temperature settings for both zones are adjustable within the range of 5°C - 22°C / 40°F - 72°F. -
Page 11: Changing Between Fahrenheit And Celsius
Changing between Fahrenheit and Celsius You can select whether the temperature displays show Celsius or Fahrenheit. To alter what the temperature displays are showing, press the light ON/OFF control button (1) for 5 seconds. You cannot change the display if you are in the process of adjusting the temperature of a cooling zone. -
Page 12: Loading The Wine Cabinet
Loading the wine cabinet IMPORTANT: Your appliance is ideally suited to store 0.75 litre Bordeaux style wine bottles. Whilst it can store larger bottles, you must make sure that they do not prevent the door from shutting properly. Always check that you can close the door without it fouling on a wine bottle, before shutting it. -
Page 13: Storing Your Wines
Storing your wines Type of wine Temperature(Celsius) Temperature(Fahrenheit) Red wine (*) 15.5 – 18.5°C 59.9 – 65.3°F White wine (**) 10 - 15°C 50 – 59°F Sparkling 7.2 – 9.5°C 45 – 49.1°F wines/champagne Rose wine 9.5 – 10.5°C 49.1 – 50.9°F Vintage wine 13°C 55°F... -
Page 14: Wine Storage Problems
IMPORTANT! Mayer is not responsible or liable for any spoilage or damage to wines. Warranty only applies to the wine cooler and not to the content of the wine cooler. - Page 15 Oxidisation- when wine has been opened and left for longer than a day; it tends to either drink the wine on the same day it was opened or to use a vacuum device specially designed for removing oxygen from opened wine bottles. If you use such a device, the wine should still be consumed shortly afterwards.
-
Page 16: Cleaning And Maintenance
Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCON- NECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT. Do not clean the appliance by pouring water onto it or spraying water over it. The interior of the wine cabinet should be cleaned periodically, using a solution of bicarbonate of soda and lukewarm water. -
Page 17: Removing The Shelves For Cleaning
Removing the shelves for cleaning To remove any of the shelves from the rail compartment, move the shelf to the position where the notch of wooden shelf is exactly under the plastic post and lift the wooden shelf. Please ensure these are replaced when the shelf is put back. Make sure the shelves are fully engaged before loading any bottle into the cabinet. -
Page 18: Power Failure
Power failure temperature of your appliance if you minimize the number of times the door is opened. steps to protect the contents. must wait 3 to 5 minutes before restarting the wine cabinet. If you attempt to restart before this time delay, the wine cabinet will not turn on. Vacation time Short holidays: Leave the wine cabinet in operation for holidays of less than three weeks. -
Page 19: Electrical Connection
Electrical connection YOUR WINE CABINET IS INTENDED FOR FITTED AND PERMANENT INSTALLA- TION. registered on the E.W.R.B. web site and who will comply with the AS/NZS 3000 Wiring Regulations and local regulations. o Your wine cabinet comes supplied with a 10 amp moulded lead with an AS/NZS 3112 approved plug. -
Page 20: Positioning
Positioning o It is advisable that your appliance is only installed in a location where the ambient on the rating plate of your appliance. Your appliance may not function correctly if the ambient temperature falls outside of the following ranges. Appropriate ambient temperature +10 to +32 degrees centigrade +16 to +32 degrees centigrade... -
Page 21: Built-In Installation
Built-in installation Your wine cabinet can be used as a freestanding or a built in unit. The clearances shown in the above drawing should be followed for both types of installation. In particular the depth dimension must be observed. IMPORTANT: The vent at the base of the appliance is for ventilation. Nothing should be placed in front of this vent;... -
Page 22: Installing The Handle
Built-in installation Remove the door gasket on the side you wish to install the handle. You can see two designated holes for handle installation. Install the handle tightly as shown in the diagram above with the two screws, lock Replace the door gasket. -
Page 23: Reversing The Door Of Your Wine Cabinet
Reversing the door of your wine cabinet This appliance has the capability of the door opening from either the left or right hand side. Any parts that you remove from the appliance whilst reversing the door, should be retained for later use. 1. - Page 24 4. Install the upper left hinge on the left side of the unit. 5. Turn the door 180° and re-install it to the unit. 6. Check that the door is aligned horizontally and vertically and that the seals are IMPORTANT: Check that the door opens and shuts correctly, without fouling, after you have completed the door reversal process.
- Page 25 After the door has been reversed, you should check the door seal of the wine cabinet. The seal should not be creased or crushed; otherwise there will be a gap between it and the inside of the door. o The seal must adhere properly all the way around the door. o If the seal is not adhering to the cabinet properly, then you should either:- a) Use a warm damp cloth and manipulate the seal until it does adhere to the cabinet properly, all the way around the door.
-
Page 26: Troubleshooting
Troubleshooting IMPORTANT: If your wine cabinet appears not to be operating properly, before contacting Customer Services, please refer to the checklist below. PROBLEM POSSIBLE CAUSE Appliance does not operate Not plugged in. The circuit breaker has tripped or the fuse has blown. Temperature inside the appliance The temperature controls are set too warm. - Page 27 IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact Customer Services using the contact details on the following page. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guaran- liable for the cost of the call out charge.
- Page 28 Warranty & Customer Service e-Warranty Registration at https://www.mayer.sg SCAN FOR MAYER MARKETING PTE LTD Download Mayer App via Customer Service Hotline: 6542-8383 [Mon,Wed & Fri: 9:00am to 6:00pm] [Tue & Thurs: 9:00am to 8:00pm] [Sat: 9:00am to 3pm] Closed: Sunday & Public Holidays...
Need help?
Do you have a question about the Magnum Series and is the answer not in the manual?
Questions and answers
I have dual zone magnum series. The temperature indicator shows 21degC for the zones despite I tried to change it
