- Page 1 ID Tech EasyMag Quick Start More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time *Free ground shipping to the continental USa on orders over $100.
- Page 2 EASYMAG Magnetic Stripe Reader USB/RS-232 Interface Quickstart Manual ID TECH 10721 Walker Street Cypress, California 90630 (714) 761-6368 www.id-tech.net 80003510-001 Rev. A R02/05 #468 EASYMAG Magnetic Stripe Reader USB/RS-232 Interface Quickstart Manual ID TECH 10721 Walker Street Cypress, California 90630 (714) 761-6368 www.id-tech.net 80003510-001...
- Page 3 DATA EDITING The EasyMag has a data editing feature incorporated into its firmware. This feature allows the data read from the magnetic stripe to be sent to the host in the exact format expected by the host software, eliminating the need for modifications to the application software. Full data editing instructions are contained in the ID TECH EasyMag RS-232 User’s Manual (P/N: 80003506-001).
- Page 4 TROUBLESHOOTING AGENCY APPROVED The EasyMag reader is easy to install and use. Most problems Specifications for subpart B of part 15 of FCC rule for a Class A encountered can be attributed to: computing device. • Incorrect Interface Cabling LIMITED WARRANTY •...
- Page 5 where: SS1(start sentinel track 1) = % SPECIFICATIONS SS2(start sentinel track 2) = ; SS3(start sentinel track 3) = ; for ISO, ! for CDL, % Power Requirements: Low-power CMOS power supplied by the host for AAMVA computer via the USB port. ES(end sentinel all tracks) = ? Operating Current: About 70mA for decoded magnetic stripe (three...
- Page 6 OPERATION DESCRIPTION The EasyMag magnetic stripe reader is easy to operate. Just fol- The EasyMag™ compact magnetic stripe reader can read 1, 2, low these simple steps: or 3 tracks of magnetic stripe information. In addition, it has full data editing capabilities. 1.
- Page 7 Open HyperTerminal or any similar communications program. HOST CONNECTIONS (Remember to have the properties set to the proper COM PORT NUMBER and all the communication parameters set to match The EasyMag reader is connected to the host computer via a those of the reader.) Input data will display on the HyperTermi- USB input port.
