WM7000 MARINE CD RECEIVER I MODEL 15004484
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WM7000 and is the answer not in the manual?

Questions and answers

Related Manuals for West Marine WM7000

Summary of Contents for West Marine WM7000

  • Page 1 All manuals and user guides at all-guides.com WM7000 MARINE CD RECEIVER I MODEL 15004484 Owner’s Manual...

  • Page 2: Before You Start

    All manuals and user guides at all-guides.com PREPARATION Please read entire manual before installation. Before You Start Getting Started OPTIONAL REAR REMOVAL MOUNTING SUPPORT KEYS HEAD UNIT MOUNTING SLEEVE WM7000 1-866-382-5476...

  • Page 3: Wiring Diagram

    All manuals and user guides at all-guides.com WIRING DIAGRAM When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The WM7000 uses one 10 amp ATM fuse located in-line. WM7000 1-866-382-5476...

  • Page 4: Control Locations - Receiver

    All manuals and user guides at all-guides.com CONTROL LOCATIONS — RECEIVER Mute Menu WM7000 1-866-382-5476...

  • Page 5: Control Locations - Remote

    All manuals and user guides at all-guides.com CONTROL LOCATIONS — REMOTE WM7000 1-866-382-5476...

  • Page 6: General Operation

    All manuals and user guides at all-guides.com GENERAL OPERATION Faceplate Removal Press OPEN Power On/Off Press unit off. Source Press SOURCE SOURCE volume knob Auxiliary Input SOURCE Volume Display Press DISP Reset Press RESET Set the Clock 12/24-hour Clock WM7000 1-866-382-5476...
  • Page 7 Bass Level volume knob Bass Frequency volume knob Middle Level volume knob Middle Frequency volume knob Treble Level volume knob Treble Frequency volume knob Balance volume knob Fader Subwoofer volume knob Subwoofer Level volume knob volume knob Subwoofer Frequency WM7000 1-866-382-5476...
  • Page 8 GENERAL OPERATION — GENERAL SETUP MENU Menu Function Options Action Tuner Frequency Spacing Auto Station Press SELECT Store Local/Distance Tuning volume knob SELECT Set the Clock CLOCK Clock Mode ONCE Scrolling Option iPod Control Beep Con rmation Programmable Turn On Volume WM7000 1-866-382-5476...
  • Page 9 Rotate the volume knob to adjust the contrast settings of the display screen from 0 to 50. Contrast Brightness Rotate the volume knob to adjust the brightness settings of the display screen from 0 to 50. Demo Rotate the volume knob to to enable (ON) or disable (OFF) the demonstration mode. WM7000 1-866-382-5476...

  • Page 10: Am/Fm Tuner Operation

    All manuals and user guides at all-guides.com AM/FM TUNER OPERATION Manual Tuning Press TUNE or TUNE Seek Tuning Press TUNE or TUNE Band Press BAND Storing Station (F)unction Presets volume knob SELECT Recalling Station P+ or P- Presets band. WM7000 1-866-382-5476...
  • Page 11 CD OPERATION Insert CD Press OPEN Eject CD EJECT Track Select Press TRACK TRACK TRACK Fast Forward/ TRACK or TRACK Reverse Pause Press Press Repeat Press (F)unction Repeat Random Press (F)unction Random Preview Press (F)unction Preview CD-R/CD-RW Compatibility WM7000 1-866-382-5476...

  • Page 12: Mp3/Wma Operation

    All manuals and user guides at all-guides.com MP3/WMA OPERATION Playing MP3/WMA Files Displaying Information Press DISP Repeat Press (F)unction volume knob SELECT volume knob Random Press (F)unction volume knob SELECT volume knob Preview Press (F)unction volume knob SELECT volume knob Note: WM7000 1-866-382-5476...
  • Page 13 GO BACK Playing a Song SELECT Press SELECT to begin Press Press Folder 1 Folder 2 Folder 3 Folder 4 Folder 5 Folder 6 Folder 7 SELECT BACK Files Files Files Files Files Files Files Turn the volume knob WM7000 1-866-382-5476...
  • Page 14 MP3/WMA OPERATION — FILE/FOLDER COMPATIBILITY AND SUPPORT — CD Type Specification Compatible File Types WMA lossless WMA Pro Incompatible File Types WAV lossless Recording Format Compatibility Multi session Sampling Frequency Rate Compatibility Transfer Bit Rate Compatibility Character Support ID3 Tag Support File/Folder Limit WM7000 1-866-382-5476...
  • Page 15 Sampling Frequency Rate Compatibility Transfer Bit Rate Compatibility Character Support ID3 Tag Support File/Folder Limit Note: For devices with more than the maximum number of files/folders, some files will be ingnored and may not function properly. USB File System WM7000 1-866-382-5476...

  • Page 16: Ipod Operation

    GO BACK See the below table for a list of the search menu navigation options. Navigation Search Item Menu Playlist Menu Songs Menu Artists Albums Artists Menu Albums Albums Menu Podcase Full/Manual Control manual modes. Important: Note: mode. WM7000 1-866-382-5476...
  • Page 17 All manuals and user guides at all-guides.com IPOD OPERATION Song Select Press to return to Fast Forward and Reverse Pause Press Press Repeat Press (F)unction volume knob to Random Press (F)unction volume knob to random order. Preview Press (F)unction volume knob to Character Support WM7000 1-866-382-5476...

  • Page 18: Bluetooth Operation

    All manuals and user guides at all-guides.com BLUETOOTH® OPERATION Pairing a Device Preparation Pairing a New Device The device name is “WM7000” The Bluetooth passcode “1234” Note: Pairing Additional Devices Connecting a Paired Device SELECT SELECT or Note: Disconnecting a Device...

  • Page 19: Making A Phone Call

    This function may not be supported by your phone. Redialing the last number mode. Press or SELECT This function may not be supported by your phone. Receiving and Ending Phone Calls Receiving a Phone Call Note: Note: Ending a Phone Call Streaming Audio Operation continues… WM7000 1-866-382-5476...
  • Page 20 All manuals and user guides at all-guides.com BLUETOOTH ® OPERATION Streaming Audio Operation (continued) to be disabled. Note: Bluetooth Reset SOURCE MUTE Compatibility Note: Bluetooth Setup Menu Options Function Options Action Bluetooth Auto Connect Auto Answer set to FRONT Speaker Output WM7000 1-866-382-5476...

  • Page 21: Pandora Operation

    USB Connection Changing Stations 1. Press SELECT volume knob SELECT volume knob 4. Press SELECT Note: Shuffle Press SELECT Shuf e Skipping Tracks Press Play/Pause Press Press Thumbs Up Press Thumbs Down Press Device Compatibility Data Charges Note: WM7000 1-866-382-5476...

  • Page 22: Troubleshooting

    (no power) Unit has power (but no sound) Unit blows fuses Excessive skipping Press EJECT or RESET Press EJECT or RESET NO FILE appears on display Press EJECT Unit will not accept a disc NO SUPPORT appears on display WM7000 1-866-382-5476...

  • Page 23: Specifications

    30Hz – 2.2kHz General 4 – 8 ohms 4 Volts RMS 7" x 7" x 2" (178 x 178 x 50 mm) Bluetooth Profiles ® Design and specifications subject to change without notice. CEA-2006 Power Standard Speci cations WM7000 1-866-382-5476...

  • Page 24: Fcc Compliance

    All manuals and user guides at all-guides.com FCC COMPLIANCE Warning: Note: WM7000 1-866-382-5476...
  • Page 25 (the “Limited Warranty Term”). The warranty period is not extended if we repair or replace a warranted product or any parts. West Marine reserves the right to change the availability of limited warranties, at its discretion, but any changes will not be retroactive and will only apply to subsequent purchases.
  • Page 26 All manuals and user guides at all-guides.com NOTES WM7000 1-866-382-5476...
  • Page 27 All manuals and user guides at all-guides.com NOTES WM7000 1-866-382-5476...
  • Page 28 All manuals and user guides at all-guides.com ® Front and Rear Inputs...
