TV Wall Mount Instruction

Manual

V1.0

Model: EBMT5

Thank you for choosing this product! We strive to provide you with the

best quality products and services in the industry. Should you have any

issues, please don't hesitate to contact at JKO2YU@outlook.com (US/CA)

Need help?

Do you have a question about the EBMT5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ergo Tab EBMT5

Page 1 TV Wall Mount Instruction Manual V1.0 Model: EBMT5 Thank you for choosing this product! We strive to provide you with the best quality products and services in the industry. Should you have any issues, please don't hesitate to contact at JKO2YU@outlook.com (US/CA)
Page 2 IMPORTANT SAFETY INFORMATION Please carefully read all instructions before attempting installation. If you do not understand the instructions or have any concerns or questions, please contact our customer service at JKO2YU@outlook.com CAUTION: Avoid potential personal injuries and property damage! • Do not use this product for any purpose that is not explicitly speciﬁed in this manual.
Page 3 Tools Needed (Not lncluded) Stud Finder Tape Measure Pencil Drill Philips Screwdriver 5/32in. (4mm) 3/8in. (10mm) Hammer 3/8in. (10mm) 5/16 in. (8mm) Wood Drill Concrete Drill Socket Wrench Wrench Supplied Parts and Hardware Warning: This product contains small items that could be a choking hazard if swallowed.
Page 4 TV Bolts (Only one bolt size ﬁts your TV.) Note: The bolts are shown in accordance with the actual size M6x15mm M6x35mm M8x25mm M8x50mm M4x30mm Supplied Parts and Hardware for Step 2 Bubble Level Wall Plate Note: The lag screw is shown in accordance with the actual size Lag Screw ST6.3x60 mm Washer...
Page 5 Step 1 Secure the TV Brackets to TV Select TV Bolts Only one bolt size ﬁts your TV. Bolt length: Verify adequate thread engagement with bolts or bolts/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will not hold the TV. -Too long will damage the TV.
Page 6 Option B (For Round Back TV) D2/E2/F (If needed) B1/B2/C1 Alternate Note: Keep Spacer the arrow up Setups Option C (For TV with A “Bump”) Spacers may be necessary for 2 holes ONLY. D1/E1/F D2/E2/F C2 (If needed) (If needed) C1/B1 B1/B2/C1 needed)
Page 7 Step 2 Attach the Wall Plate [01] to Wall For wood stud installation, follow STEP 2A For concrete installation, follow STEP 2B Step 2A Wood Stud Option WARNING: Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A1]. Tighten the lag screws [A1] only until the washers [A2] are pulled ﬁrmly against the wall plate [01].
Page 8 2A-2 Position the wall plate at your desired height and line up the holes with your stud center line. Level the wall plate and mark the holes. 2A-3 Drill 4 pilot holes using a 5/32 in.(4mm) diameter drill bit. Make sure the depth is not less than 2 23/64 in.(60mm).
Page 9 Step 2B Solid Concrete or Concrete Block Option WARNING: Avoid potential personal injury or property damage! DO NOT over-tighten the lag screws [A1]. Tighten the lag screws [A1] only until the washers [A2] are pulled ﬁrmly against the wall plate [01]. Ensure the wall plate is securely fastened to the wall before continuing to the next step.
Page 10 2B-3 Use the hammer to knock Install wall plate using lag anchors [A3] into the wall. screws [A1] and washers [A2]. Be sure the anchors [A3] Tighten the lag screws [A1] are seated ﬂush with the only until the washers [A2] are concrete surface.
Page 11 Step 4 Tilt Adjustment 1. Loosen the both tilt nuts [S] slightly. 2. Adjust TV to your desired tilt angle. 3. Retighten both tilt nuts [S] to ﬁx the tilt angle. Note: Please do not over-loosen the nuts to prevent the TV from falling down.
Page 12 Thank you again choosing this product! All of us do appreciate your product purchase. We hope that you are as happy with your product as we designing and manufacturing it for you. We strive to provide you with the best quality products and services in the industry. If you have any JKO2YU@outlook.com (US/CA) questions please don't hesitate to contact us at...
