- Page 1 46-SERIES 4610 POULTRY HOUSE WALL CLEANER OPERATOR’S MANUAL THIS MANUAL TO ACCOMPANY MACHINE PART NO. 46-OM-02 PRINTING DATE: NOV 2008...
- Page 2 WARRANTY POLICY KELLEY MANUFACTURING COMPANY (KMC) warrants that all goods sold to the original purchaser of any KMC product shall be free of any defects in material and workmanship if used under normal operating conditions. warranty period begins on the date of purchase by the retail customer. For non-commercial users the warranty ends twelve (12) months thereafter.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TO THE PURCHASER ·······················································································2 Retail Customers Responsibility Under The KMC Warranty ··································3 SAFETY PROCEDURES····················································································3 POULTRY HOUSE WALL CLEANER BASIC FEATURES ·······································4 ASSEMBLY INSTRUCTIONS ·············································································5 MACHINE SETUP Attaching To Tractor ·················································································5 Wall Gauging Tire Adjustment ····································································6 Plastic Wall Follower ·················································································7 Curb Deflector ·························································································7 Auger Rotation ························································································7 Checking Poultry House For Obstructions ·····················································7... -
Page 4: To The Purchaser
TO THE PURCHASER This KMC Poultry House Wall Cleaner has been carefully designed and manufac- tured to give years of dependable service. In order to operate it efficiently and maintain if properly, please read the instructions within this manual thoroughly. While reading the manual through, you will notice that it is divided into sections which clearly explain the assembly and operations of each components of this machine. -
Page 5: Retail Customers Responsibility Under The Kmc Warranty
Retail Customers Responsibility Under The KMC Warranty The retail customer’s responsibilities are: 1. To read the Operator’s Manual and operate the Poultry House Wall Cleaner in accordance with instructions given in the manual 2. To inspect the Poultry House Wall Cleaner daily, lubricate as specified and repair or replace parts as needed, especially when continued use would cause damage or excess wear to other parts. -
Page 6: Poultry House Wall Cleaner Basic Features
POULTRY HOUSE WALL CLEANER BASIC FEATURES Throughout this manual we will be discussing various features and components of the KMC Poultry House Cleaner. References to various components for adjustments, settings, performance, and lubrication are made. The following diagram will help in identifying these components. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS The Poultry House Wall Cleaner is shipped in two pieces; the pivot frame and the blade as- sembly. Assembling the Wall Cleaner is accomplished by bolting the two together using a 1” x 5 1/2” long pivot bolt (and locknut) and a 5/8” x 5 1/2” grade 2 bolt for the blade pivot lock down bolt (with lockwasher and nut). -
Page 8: Wall Gauging Tire Adjustment
NOTE: Operation of the POULTRY HOUSE WALL CLEANER places substantial lateral (sideways) force on the cleaner. Make sure tractor hitch stabilizing bars are properly installed to minimize lateral movement of the wall cleaner. DANGER ROTATING AUGER: ALL PERSONS SHOULD STAY CLEAR OF ROTATING AUGER. -
Page 9: Plastic Wall Follower
Plastic Wall Follower PLASTIC WALL FOLLOWER TO BE USED IN HOUSES WITH INSIDE WOOD POST EXTENDING FROM WALLS. THE CURB DEFLEC- TOR WILL BE RE- M O V E D W H E N RUNNING WITH 4 X 4 POSTS. ONLY WITH WIDE CONCRETE FOOT-... -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS The KMC Poultry House Wall Cleaner is made up of 4 main components: a frame, a main blade, a rear gauge wheel, and an attached augering system. An optional curb deflec- tor attaches on the right end of the cleaner for houses with flat curbs coming off the wall. Please remove this attachment if it is not required in your poultry house. -
Page 11: Operating Speed
Operating Speed The auger rotational speed should be set to keep material sufficiently cleaned out from in front of the blade. The auger speed is adjusted by varying the tractor engine RPM or ad- justing the flow control lever found on some tractors. The Wall Cleaner should be operated at a ground speed of 3/4 miles per hour or slower. -
Page 12: Maintenance
MAINTENANCE Cleaning Machine The environment that the Wall Cleaner is used in can be highly corrosive to steel com- ponents. Therefore, the Wall Cleaner should be washed off after each use. When washing the Wall Cleaner with a high pressure washer, do not get water stream too close to the bear- ings on the Wall Cleaner. -
Page 13: Lubrication
LUBRICATION All bearing used on the Wall Cleaner are sealed and require no lubrication. Do not lubricate (grease or oil) the tube on the sliding blade. Lubricating this tube will attract material and cause build up on the tube resulting in improper operation of the slide blade. TRANSPORTATION When transporting the wall cleaner, be aware that on the right side of the tractor, the Wall Cleaner blade extends beyond the tractor tires. - Page 15 The following is a list of serial numbers issued to our machines at the beginning of each year. To determine when a unit was made, find the range within which the particular serial number falls. It would have been produced between January 1 to December 31 of that year. YEAR SERIAL NUMBERS 1985...
- Page 16 DEPENDABLE EQUIPMENT FOR PROGRESSIVE FARMIMG Visit us at www.kelleymfg.com MADE IN AMERICA KELLEY MANUFACTURING CO. 80 Vernon Drive / Zip 31794 P.O. Drawer 1467 / Zip 31793 Tifton, GA Tel: 229-382-9393 Toll Free: 1-800-444-5449 Fax: 229-382-5259 Email Address: info@kelleymfg.com...
