DAPAudio M1000 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Portable Data Terminal
Model: M1000
SHIN CHUAN COMPUTER CO., LTD.
6F-2, 268, LianCheng Rd., ZhongHe Dist, New Taipei City 23553,
Taiwan(R.O.C)
TEL:886-2-82278801. FAX:886-2-82278832.
http://www.sccltd.com.tw
NOV/07/2011 Ver:0.2

Advertisement

Table of Contents
loading

Summary of Contents for DAPAudio M1000

  • Page 1 User’s Manual Portable Data Terminal Model: M1000 SHIN CHUAN COMPUTER CO., LTD. 6F-2, 268, LianCheng Rd., ZhongHe Dist, New Taipei City 23553, Taiwan(R.O.C) TEL:886-2-82278801. FAX:886-2-82278832. http://www.sccltd.com.tw NOV/07/2011 Ver:0.2...
  • Page 2 • Microsoft Windows CE is a registered trademark of Microsoft Corporation in the United States and/or other countries. • Wi-Fi is a registered trademark of the Wi-Fi Alliance. • Bluetooth is a registered trademark of Bluetooth SIG, Inc. • All other Trade Names referred to are the Servicemark, Trademark or Registered Trademark of the respective manufacturers.

  • Page 3: Table Of Contents

    2.4. Handling the Device ............2-6 2.4.1 Starting the Device............2-6 2.4.2 Power on / off...............2-7 2.4.3 Calibration of the touch Screen........2-7 2.4.4 To mute the Sound for M1000........2-8 2.4.5 Using the Stylus ............2-8 2.4.6 Using the M1000 Keypad..........2-8 2.4.9 Using the Earphone ...........2-17 2.5 Navigating the Display............2-17...
  • Page 4 2.5.5 The Soft Keypad ............2-19 2.5.6 Setting Up Wireless LAN ...........2-19 2.5.7 Reading barcodes, 1D laser version......2-25 2.5.8 Installing the MicroSD Card ........2-25 2.5.9 Help ................2-26 2.6 Power management ............2-26 2.6.1 Suspend Mode............2-26 2.6.2 Resuming..............2-27 2.7 Resetting the Device ............2-27 2.7.1 Software (Warm) Reset..........2-27 2.7.2 Cold Reset ..............2-28 Chapter 3.
  • Page 5 3.3 Tap Start ................3-53 3.3.1 Security..............3-53 3.3.2 Bluetooth..............3-54 3.3.3 Boot Manager ............3-55 3.3.4 Brightness..............3-56 3.3.5 Device Power.............3-57 3.3.6 Fn Key Manager ............3-58 3.4 Taskbar and Start Menu .............3-59 Chapter 4. Communication ................4-1 4.1 Installing & Setting Up Microsoft ActiveSync ......4-1 4.1.1 Installing Microsoft ActiveSync on the Host PC....4-1 4.1.2 Connecting Device to Host PC ........4-1 4.2 Using ActiveSync ..............4-1...

  • Page 6: Chapter 1. Introduction

    Chapter 1. Introduction Congratulations on purchasing the M1000 Portable Data Terminal, a Microsoft Windows® CE Rugged Device. Its special combination of features makes it perfect for using in a wide range of applications. These features as: Intel® XScale PXA310 624 MHz 32 bits RISC Processor Windows®...

  • Page 7: User And Product Safety

    1.2 User and Product Safety Do not stare into the laser or LED beam directly or shine it into eyes. Never use strong pressure onto the screen or subject it to severe impact, as the LCD panel could become cracked and possibility cause personal injury.

  • Page 8: Battery Safety

    1.3 Battery Safety CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions. Lithium-ion battery packs might get hot, explode, ignite and/or cause serious injury if exploded by abusive using. Please follow the safety warnings listed as below: Do not throw the battery pack in fire.

  • Page 9: Ce Statement

    1.4 CE Statement This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: EN 60950-1: 2006 +A11:2009 +A1:2010 Safety of Information Technology Equipment EN 300 440-1 V1.6.1: 2010 Electromagnetic compatibility and Radio spectrum Matters (ERM);...
  • Page 10 EN 301 489-1 V1.8.1 (2008-04) Electromagnetic compatibility and Radio Spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements EN 301 489-17 V2.1.1 (2009-05) Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment; Part 17: Specific conditions for Broadband Data Transmission Systems EN 301 489-7 V1.3.1 (2005-11) Electromagnetic compatibility and Radio spectrum Matters (ERM);...
  • Page 11 some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. 0560 Česky [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se [Czech] základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
  • Page 12 [Lithuanian] reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in Nederlands overeenstemming is met de essentiële eisen en de andere relevante [Dutch] bepalingen van richtlijn 1999/5/EG. Malti Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] [Maltese] jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.

  • Page 13: Fcc Statement

    1.5 FCC Statement 1.5.1 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 14: Recycling & Disposal Instructions

    1.5 cm separation distance between the device and the user's body. Caution: SCC declares that M1000 ( FCC ID: TQ2-SC900PDT-BWG )is limited in CH1~CH11 for 2.4GHz by specified firmware controlled in U.S.A. The FCC ID of M1000 is TQ2-SC900PDT-BWG...

  • Page 15: Product Labeling

    1.8 Product Labeling The Device has several labels as shown in Figure 1-1 to 1-2. A. M1000 Figure 1-1 Product Labeling (Front side view) Label nr. Description LCD panel protection film Table 1-1 Front labeling 1-10 / 122...
  • Page 16 Figure 1-2 Product Labeling (Back side view) Label nr. Description Laser radiation warning label System and regulatory label Serial / Configuration number Warranty seal Windows CE .NET label FCC Statement Table 1-2 Rear labeling 1-11 / 122...

  • Page 17: System Specifications

    1.9 System Specifications The M1000 detailed specifications as follows. Unless otherwise noted, all the specifications are subject to change without prior notification. Table 1-3 System Specification M1000 Processor - Intel PXA310 624MHz 32 bits RISC CPU - 256MB Flash ROM...

  • Page 18: Environment Standard

    M1000 - Dimensions: Dimensions and L: 144 x 62 x 26.2~35.8 mm Weight - Weight: 240g with Standard Battery Pack(Approx.) Color - Gray - Optional: High-Capacity Li-Ion Battery Pack Peripherals and (3.7VDC/2760mAh) Accessories - Single Dock Software - Microsoft Windows 6.0 Professional 1.10 Environment Standard...

  • Page 19: Chapter 2. Getting Started

    2.1 Check the package Open the package and check all the parts are inside without shortage and damage: A. M1000 Figure 2-1 Inside the package 1. M1000 Terminal 2. Hand Strip 3. Stylus Cord. 4. Standard Battery Pack(3.7VDC/1840mAh) 5. Earphone 6.

  • Page 20: General View Of The Pdt

    2.2 General View of the PDT 2.2.1 M1000 general view Figure 2-2 M1000 front side view Figure 2-3 M1000 back side view 2-2 / 122...
  • Page 21 Table 2-1 Description of M1000 General View Scanner LED “Red” color Reading barcode Indicator “Green” color Successful reading Charge LED “Red” color Charging battery Indicator “Green” color Battery charged full 3 color LED “Blue” color Bluetooth Enable Indicator “Green” color...

  • Page 22: Charging The Battery Pack

    2.3 Charging the Battery Pack Before using the Device, perform the basic procedure of charging the battery pack through the following steps. 2.3.1 Installing the battery pack 1. Turn the locking latches (right and left) downwards and lift the battery cover away from the Device.

  • Page 23: Charging The Battery Pack With Cradle

    3. Lock the battery cover by inserting the bottom first, and then press the top in firmly. Turn the locking latches (right and left) upwards to secure the cover to the Device. Figure 2-6 Lock the battery cover 4. Charge time: For the first time to charge the battery pack needs approximately 6 hours.

  • Page 24: Handling The Device

    ◆ When charging the battery pack, the charge LED indicator on the Device turns on Red. ◆ After the battery pack is fully charged, the charge LED indicator turns to Green. CAUTION: Please do not remove the Battery pack too long from Device after you have already full-charged the Battery pack and backup battery pack and start to use the Device.

  • Page 25: Power On / Off

    2.4.2 Power on / off To turn on the Device Press the Power key briefly ( ). If the Device does not power on, perform the cold reset. See chapter 2.7.2. As the Device initializes its file system, it splash screen displays for about 30 seconds followed by calibration screen.

  • Page 26: To Mute The Sound For M1000

    2.4.4 To mute the Sound for M1000 To mute the sound, press the key first, and then press the key to turn off and turn on the sound. 2.4.5 Using the Stylus The stylus is located next to hand-strap on the right rear of the Device. The stylus function is same as the mouse on a PC.
  • Page 27 Alpha + Fn+ Alpha Main Function Fn + Main Function + Main Function Soft Keyboard Down Reserved Left Device Power Right Brightness Function change Escape Change to cap Change to letters Caps letters Backspace Mute Backspace Enter Del (Delete) Enter ＠...
  • Page 28 Table 2-3 Special Assembler Key Assembler Key Functionality Definition ”Alpha” + ”Fn” + ”Enter” Press “Alpha”, “Fn” and Warm Reset “Enter” buttons simultaneously. Press “Power”, “Fn” and +”Fn”+”Enter” Cold Reset “Enter” buttons simultaneously. Table 2-4 Definition of main Function Main Function Definition Main Barcode key activates the scan...
  • Page 29 Main Function Definition key is used in combination with other keys to type special characters and perform system functions. Function change Note: When continue press “Fn” key twice, the “Fn” key function will be lock and color change from White( ) to Yellow ( ).
  • Page 30 Main Function Definition Number key “3” Number key “4” Number key “5” Number key “6” Number key “7” Number key “8” Number key “9” Number key “0” ＊ ＊ key ＃ ＃ key 2.4.6.1 Special Function by “Fn” + Main Function The “Fn”...
  • Page 31 Fn + Main Definition Sequence Function You must press key, then press Backlight key to adjust Brightness. 1. The “TAB” function is to move the cursor to the next tab stop or the next control (on a form) 2. To do this function by pressing key first, and then pressing each time.
  • Page 32 Fn + Main Definition Sequence Function Enter a plus sign by pressing ＋ key, then pressing 1. It is to do “Paste” function. 2. To do this function by pressing Paste key first, and then pressing key each time. It is to do “€” function. To do this function by pressing Euro symbol key first, and then pressing...
  • Page 33 Fn + Main Definition Sequence Function 1. It displays the Start menu. 2. To do this function by pressing Start Menu key first, and then pressing key each time. Enter a slash by pressing ／ first, and then pressing key. 2.4.6.2 Alpha plane keys by “Alpha”...
  • Page 34 Table 2-6 Alpha + Numeric keys define Press the Keys Press the Keys enter enter ： ＼ ［ ］ ﹒ ， ； ＝ ％ Note:The key is not needed to key in if the character isn’t the first alpha character being keyed in. 2-16 / 122...

  • Page 35: Using The Earphone

    2.4.9 Using the Earphone Connect Earphone to PDT earphone jack connector. if you do want to record the voice, you have to use the packed Earphone. Figure 2-11 Earphone 2.5 Navigating the Display 2.5.1 Setting Time and Date In the Date/Time options, you can change the year, month, date, time, time zone, or select automatic adjust for Daylight Saving Time.

  • Page 36: Entering The Data

    There are several ways to enter data on the Device once in an application: Use the keypad to enter alpha-numeric characters, Refer to “2.4.6 Using the M1000 keypad”. Use the stylus on the touch screen. Select text in the same way you select the text on a PC. Use the stylus to...

  • Page 37: The Task Bar

    2.5.4 The Task Bar The Task bar at the bottom of the screen displays the icon, an icon for the active program, the current time, and system icons for utilities loaded in memory. The Task bar includes menu names, buttons, and the keyboard icon, which opens and closes the soft input panel (SIP).
  • Page 38 To initialize SCU: From the Start menu, select Programs Select the directory called Summit Inside the Summit directory are two items: a directory for the storage of security certificates and an SCU icon. To run SCU, double-click the SCU icon SCU has five tabs: Main, Profile, Status, and Diags, and Global.
  • Page 39 SCU: Indicates the version of SCU that is running on the device. About SCU: When tapped, supplies information on SCU that on a Windows application normally would appear under Help/About. Profile Tab Profile settings are radio and security settings that are stored in the registry as part of a configuration profile.
  • Page 40 -Delete: Delete the profile, provided that it is not the active profile. -Scan: Open a window that lists access points that are broadcasting their SSIDs. Each time you tap the Refresh button, you view an updated list of APs, with each row showing an AP’s SSID, its received signal strength indication (RSSI), and whether or not data encryption is in use (true or false).
  • Page 41 Status Tab The Status tab provides status information on the radio. Active profile Radio’s status: Down (not recognized), Disabled, Not Associated, Associated, or [EAP type] Authenticated Client info: Name, IP address, and MAC address AP info: Name, IP address, MAC address, beacon period, and DTIM interval Connection info: Channel, data rate, transmit power, signal strength, and signal quality...
  • Page 42 (Re)connect: Disable and enable the radio, apply or reapply the current profile, and attempt to associate and authenticate to the wireless LAN, logging all activity in the output area at the bottom. Release/Renew: Obtain a new IP address through DHCP release/renew, and log all activity in the output area at the bottom.

  • Page 43: Reading Barcodes, 1D Laser Version

    2.5.7 Reading barcodes, 1D laser version. To use the scanning function, complete the following steps: 1. If you have not already done so, remove the protective plastic film before using devices equipped with a 1D laser bar code reader. 2. Select Start > Setting > Control Panel > Barcode Controls; complete all configurations following all description of 3.2.1 BarCode Controls.

  • Page 44: Help

    Figure 2-19 Detach the battery cover from Device 2. Detach MicroSD Holder and Insert the MicroSD Card into the MicroSD compartment. Figure 2-20 Detach the SD Holder from Device 2.5.9 Help To tap “?” can get help information for each program. 2.6 Power management 2.6.1 Suspend Mode The Device will go into a suspend mode when it is idle for a period of time.

  • Page 45: Resuming

    Figure 2-21 Schemes Tab-Idle Figure 2-22 Schemes Tab-Suspend Suspending: The following conditions will suspend: Press <Power> key while the Device is on. The duration timer of item “Switch state to Suspend” expires, which indicates that there has been no use for a specified of time. The battery pack is completely discharged.

  • Page 46: Cold Reset

    After Warm Reset: The desktop appears with the application shortcuts on the screen. The custom settings in the registry are persistent. 2.7.2 Cold Reset 1) You can use Cold Reset to initiate device if WinCE.NET OS lock up or Warm Reset still can’t work 2) To perform Cold Reset, press “...

  • Page 47: Chapter 3. Setting

    Chapter 3. Setting 3.1 Introduction To view available options for Device setting, tap Start > Settings. Then, there are three items inside “Control Panel”, “Network and Dial-up” and “Taskbar and Start”. 3.2 Control Panel To view the Control Panel and settings you can modify by tapping Start > Settings >...
  • Page 48 3.2.1.1 “Scan” Tab Figure 3-2 Scan Tab Table 3-1 Basic Description Field Name Description Enable To Enable/Disable Barcode Engine Power. Power Default set to Enable. Enable To Enable/Disable Buzzer Power. Buzzer Default set to Enable. Vibration Default set to Disable. To Select Vibration type; “Disable”, “Short”, “2 Times”, “Long”.
  • Page 49 3.2.1.2 “Format” Tab Figure 3-3 Scan Tab Table 3-2 Basic Description Field Name Description Prefix Type the desired label prefix in this text box Suffix Type the desired label suffix in this text box Terminal None After showing barcode, do not action Char Enter After showing the barcode, jump to next...
  • Page 50 3.2.1.3 “Bar Codes” Tab: Select the barcode symbologies you plan to scan from the list. Tap to enable/disable the desired symbologies. Figure 3-4 Bar Codes Tab Table 3-3 Bar Codes Description Barcode Symbology Description Universal Product Code. The standard bar code type for retail products in the United States UPC + 2 Universal product code seen on almost all retail...
  • Page 51 Interleaved 2 of 5 Compact numeric code, widely used in industry, air cargo, other applications S-Code This symbology encodes like Interleaved 2 of 5 but encodes the last data character as Industrial 2 of 5. The number of data digits is therefore always an odd number Matrix 2 of 5 Used in miscellaneous industrial applications, and...
  • Page 52 3.2.1.4 “Settings” Tab: Figure 3-5 Settings Tab Table 3-4 Settings Description Field Name Description Barcode To select a type of barcode you wish to set After showing the barcode, jump to next row Transmit Leading Zero Whether send check digit by barcode Transmit Check Digit Barcode Symbologies List 3.2.1.4.1 UPC A...
  • Page 53 Table 3-5 Settings Description Field Name Description Barcode To select a type of barcode you wish to set After showing the barcode, jump to next row Transmit Leading Zero Transmit Check Digit Whether send check digit by barcode 3.2.1.4.2 UPC E Figure 3-7 UPC E Table 3-6 Settings Description Field Name...
  • Page 54 3.2.1.4.3 EAN Figure 3-8 EAN Table 3-7 Settings Description Field Name Description Barcode To select a type of barcode you wish to set Whether send check digit by barcode EAN 13 Transmit Check Digit EAN 8 Transmit Check Whether send check digit by barcode Digit EAN-13 label is verified for the correct format and Enable ISBN Translation...
  • Page 55 3.2.1.4.4 Code 39 Figure 3-9 Code 39 Table 3-8 Settings Description Field Name Description Barcode To select a type of barcode you wish to set Normal Code 39 The decoded data characters are transmitted without further translation Transmit Check Digit Whether send check digit by barcode ----- Minimum 1 Character...
  • Page 56 Table 3-9 Settings Description Field Name Description Barcode To select a type of barcode you wish to set The decoded data characters are transmitted Normal Codabar Only without further translation Transmit Check Digit Whether send check digit by barcode 3.2.1.4.6 Code 2 of 5 / S-Code Figure 3-11 Code 2 of 5 / S-Code Table 3-10 Settings Description Field Name...
  • Page 57 3.2.1.4.7 IATA Figure 3-12 IATA Table 3-11 Settings Description Field Name Description Barcode To select a type of barcode you wish to set Transmit Check Digit Whether send check digit by barcode 3.2.1.4.8 MSI / Plessey Figure 3-13 MSI / Plessey 3-11 / 122...
  • Page 58 Table 3-12 Settings Description Field Name Description Barcode To select a type of barcode you wish to set Check MOD 10 The character position CD2 is not transmitted Transmit Check Digit 1 Whether send check digit by barcode 3.2.1.4.9 Telepen Figure 3-14 Telepen Table 3-13 Settings Description Field Name...
  • Page 59 3.2.1.4.10 UK / Plessey Figure 3-15 UK / Plessey Table 3-14 Settings Description Field Name Description Barcode To select a type of barcode you wish to set Whether send check digit by barcode Transmit Check Digits 3.2.1.4.11 Code 128 Figure 3-16 Code 128 3-13 / 122...
  • Page 60 Table 3-15 Settings Description Field Name Description Barcode To select a type of barcode you wish to set The decoded data characters are translated to EAN 128 Only the EAN 128 format ----- Enable Concatenation 3.2.1.4.12 Code 93 Figure 3-17 Code 93 Table 3-16 Settings Description Field Name Description...
  • Page 61 3.2.1.4.13 Code 11 Figure 3-18 Code 11 Table 3-17 Settings Description Field Name Description Barcode To select a type of barcode you wish to set Check 1 Check Digit The check digits are not transmitted The check digits are not transmitted Check 2 Check Digits 3.2.1.4.14 Korean Postal Figure 3-19 Korean Postal...
  • Page 62 Table 3-18 Settings Description Field Name Description Barcode To select a type of barcode you wish to set The dash character '-' ( hex 2D ) is Transmitted Transmit Dash 3.2.1.4.15 RSS Figure 3-20 RSS Table 3-19 Settings Description Field Name Description Barcode To select a type of barcode you wish to set...
  • Page 63 3.2.1.5 “Others” Tab: Figure 3-21 Others Tab Figure 3-22 Set to Factory Default Figure 3-23 Barcode Firmware Version Table 3-20 Caption Description Button Caption Description Factory Default To set all Barcode parameters to factory default Firmware Version To get firmware version from Barcode engine 3.2.1.6 Barcode Setup A.

  • Page 64: Backup/Restore

    3.2.2 Backup/Restore Table 3-21 Backup/Restore ICON ITEM & FUNCTION 1. You can backup/restore system to/from flash disk or inserted memory card.(FlashDisk, or SD Card) (Figure 3-24) When you launch this AP, it must check backup file in FlashDisk first. And if you select other storage, it will check again.
  • Page 65 Figure 3-26 Backup OK Figure 3-27 Restore Start Figure 3-28 Restore OK-Warm Boot Now Figure 3-29 Restore Settings after Cold Boot 3-19 / 122...

  • Page 66: Bluetooth Device Properties

    3.2.3 Bluetooth Device Properties Note: Here are two ways to use Bluetooth Device. 1. Tap “Start” > “Programs” > “Bluetooth” > “Bluetooth Manager”. 2. Tap “Start” > “Settings” > “Control Panel” > “Bluetooth Device Properties”. Table 3-22 Bluetooth Device Properties ICON ITEM &...
  • Page 67 If want to use Virtual com, only SPP base profiles are supported.(i.e. Printer, Modem, and LAP).Switch to “Serial Port” tab, and will see the devices you had trusted or active. Select the device that you want to map a virtual com and which virtual com you want to use see Figure 3-38 Now COM6 has mapped for BT device see Figure 3-40 Figure 3-30 Bluetooth Device Properties...
  • Page 68 Figure 3-34 Bluetooth Error Windows Figure 3-35 Bluetooth Authenticate Windows Figure 3-36 Bluetooth Enter PIN Windows Figure 3-37 Bluetooth Manager Windows 3-22 / 122...
  • Page 69 Figure 3-38 Bluetooth SPP Manager Figure 3-39 Bluetooth Register COM Success Figure 3-40 Bluetooth Register COM6 Figure 3-41 Bluetooth File Sync Note: If the device to which the mobile computer is bonding does not appear in the list, ensure it is turned on, in discoverable mode, and within range (30 feet / 10 meters) of the mobile computer.

  • Page 70: Certificates

    Table 3-23 Bluetooth Icon Icon Description Unknown device icon Device is not defined Locked icon Device is locked and cannot be bonded to. Not locked icon Device is not locked and can be bonded to. Bluetooth device icon Bluetooth device Bonded device icon Bonded Bluetooth device Mobile device icon...
  • Page 71 To add a certificate or associated private key to the selected store, select “Import”(Figure 3-44, Figure 3-45) To view more details of the selected certificate, such as the expanded name or expiration date, choose “View” (Figure 3-46) To delete the selected certificate from the store, choose “Remove”...

  • Page 72: Date/Time

    Figure 3-46 Certificates-View Figure 3-47 Certificates-Help 3.2.5 Date/Time Table 3-25 Date/Time ICON ITEM & FUNCTION “Date/Time” Tab: (Figure 3-48) Please see the detail information of Chapter 2.5.1 Setting Time and Date Figure 3-48 Date/Time Windows Figure 3-49 Date/Time Windows 3-26 / 122...

  • Page 73: Device Information

    3.2.6 Device Information Provide Firmware version, Software version, Configuration No, Serial No, Flash ROM size, RAM size, WIFI MAC address, and Bluetooth ID Figure 3-50 Device Information 3.2.7 Dialing Properties Table 3-26 Dialing properties ICON ITEM & FUNCTION “Dialing Properties” Tab: (Figure 3-51) In the When dialing from list, select the “Location”...
  • Page 74 Notes: If you need to use character other than the ones listed here, use manual dialing. Hyphens and spaces in dialing strings are ignored. Some modems may not respond to the following characters, even though your device lets you add them to the dial string.

  • Page 75: Display Properties

    3.2.8 Display Properties Table 3-27 Display properties ICON ITEM & FUNCTION “Background” Tab: (Figure 3-55) From the “Image” list, select an image you want as the background of the desktop.(Figure 3-56) To locate an image in another folder, select “Browse”.(Figure 3-59) To have the image cover the entire background, select “...
  • Page 76 Figure 3-57 Display Properties Figure 3-58 Display Properties Figure 3-59 Display Properties Figure 3-60 Display Properties 3-30 / 122...

  • Page 77: Input Panel

    Figure 3-61 Display Properties Figure 3-62 Display Properties-Help 3.2.9 Input Panel Table 3-28 Display properties ICON ITEM & FUNCTION “Input panel” Tab: (Figure 3-63) Select the input method you want to change. To change the Soft Keyboard Options , tap “Option” (Figure 3-63) “Options”...

  • Page 78: Internet Options

    Figure 3-63 Input Panel Properties Figure 3-64 Input Panel Properties 3.2.10 Internet Options Table 3-29 Internet Options ICON ITEM & FUNCTION “General” Tab: (Figure 3-65) Type in the URL of desired start page and the desired search engine. You also change the Cache Size, clear the Cache and Clear the History “Connection”...
  • Page 79 Always ○ Hover ○ “Popups” Tab: (Figure 3-72) Modify the popups settings as desired. You can enable any of the following by tapping the checkbox Figure 3-65 Internet Settings-General Figure 3-66 Internet Settings-Connection Figure 3-67 Internet Settings-Security Figure 3-68 Internet Settings 3-33 / 122...
  • Page 80 Figure 3-69 Internet Settings-privacy Figure 3-70 Internet Settings Figure 3-71 Internet Settings-Advanced Figure 3-72 Internet Settings-Popups 3-34 / 122...

  • Page 81: Keyboard

    3.2.11 Keyboard Table 3-30 Keyboard ICON ITEM & FUNCTION “Repeat” Tab: (Figure 3-73) To change the amount of time between depressions before repetition starts, adjust the Repeat delay slider To change the repeat rate, adjust the Repeat rate slider. Test your new setting. Tap “...
  • Page 82 Select the modem you want use. Select “Configure” (Figure 3-78) Under “Connection Reference”, use the default settings provided. If you can’t connect using these settings, see your ISP or network administrator for specific information. If you want to always enter a phone number before connecting, Select “Manual Dial”.
  • Page 83 Select desired options. There may be additional settings that depend on the connection. To modify, select the icon and select the icon and select Advanced Settings… from the menu. Figure 3-75 Network and Dial-up Figure 3-76 Network and Dial-up Connections Connections Figure 3-77 Network and Dial-up Figure 3-78 Network and Dial-up...
  • Page 84 Figure 3-79 Network and Dial-up Figure 3-80 Network and Dial-up Connections Connections Figure 3-81 Network and Dial-up Figure 3-82 Network and Dial-up Connections Connections 3-38 / 122...
  • Page 85 Figure 3-83 Network and Dial-up Figure 3-84 Network and Dial-up Connections Connections Figure 3-85 Network and Dial-up Figure 3-86 Network and Dial-up Connections Connections 3-39 / 122...

  • Page 86: Owner

    3.2.13 Owner Table 3-32 Owner ICON ITEM & FUNCTION “Identification” Tab: (Figure 3-87) Fill in or edit the data as desired. To have this information displayed when you start your device, select “Display Owner Identification” at Power To set up identification for remote networks, see Setting up identification for remote networks.

  • Page 87: Password

    Figure 3-89 Owner Properties Figure 3-90 Owner Properties-Help 3.2.14 Password Table 3-33 Password ICON ITEM & FUNCTION “Password Setting” Tab: (Figure 3-91) Enter the password In the “Confirm password “box, enter the password again. To require the password on startup, select “Enable password protection at power- on“.

  • Page 88: Pc Connection

    3.2.15 PC Connection Table 3-34 PC Connection ICON ITEM & FUNCTION “PC Connection” Tab: (Figure 3-92) Select the first checkbox to enable direct connections to the desktop computer. (Figure 3-92) Tap the “Change Connection…” button to modify the connection method from USB To exit the “Change Connection”...

  • Page 89: Power

    3.2.16 Power Table 3-35 Power ICON ITEM & FUNCTION “Battery” Tab: (Figure 3-94) Provide change level indicators for Main battery and Backup battery. Provide remaining power capacity of main battery. If a “Main Batteries very Low” warning message shows, the remaining battery life is around 15 minutes to SC900 shuts down.(Figure 3-98) The Device will shutdown during the main batteries...
  • Page 90 Figure 3-94 Power Figure 3-95 Power Figure 3-96 Power Figure 3-97 Power 3-44 / 122...

  • Page 91: Regional Settings

    Figure 3-98 Power Figure 3-99 Power-Help 3.2.17 Regional Settings Table 3-36 Regional Settings ICON ITEM & FUNCTION “Region” Tab: (Figure 3-100) Select the desired location/language. Review the Appearance samples in the bottom half of the screen. Select the Tab at the top for any settings you wish to change, Options to modify include Number, Currency, Time, and Date.(Figure 3-102 ~ Figure 3-105) Figure 3-100 Regional Settings...
  • Page 92 Figure 3-102 Regional Settings Figure 3-103 Regional Settings Figure 3-104 Regional Settings Figure 3-105 Regional Settings 3-46 / 122...

  • Page 93: Remove Programs

    3.2.18 Remove Programs Table 3-37 Remove Programs ICON ITEM & FUNCTION “Remove Programs” Tab: (Figure 3-106) Only user installed programs can be removed. Select the program you wish to remove from the list and press “remove” button. Figure 3-106 Remove Programs Figure 3-107 Remove Programs 3.2.19 Storage Manager Table 3-38 Storage Manager...
  • Page 94 To save and exit the Storage Properties control panel, press “OK” from the control bar, or press the <Enter> key on the keypad. Caution: Dismounting or formatting the Flash Disk will erase all files and program stored in Flash Memory Figure 3-108 Storage Manager Figure 3-109 Storage Manager-New Figure 3-110 Storage Manager-Delete...

  • Page 95: Stylus

    3.2.20 Stylus Table 3-39 Stylus ICON ITEM & FUNCTION “Double-Tap” Tab: (Figure 3-112, Figure 3-113) Double-tap the checkerboard grip at a comfortable speed. Double-tap clapboard to test your settings The function is OK if the figures are changed from Figure 3-84 to Figure 3-85.

  • Page 96: System

    Figure 3-114 Stylus Properties Figure 3-115 Stylus Properties 3.2.21 System Table 3-40 System ICON ITEM & FUNCTION “General” Tab: (Figure 3-116) To show: Firmware information Information about Processor type, Memory size, Expansion card “Memory”: (Figure 3-117) Move the slider to adjust memory allocation. Default storage memory is normally is normally set to about 8MB with the reminder assigned to Program memory.
  • Page 97 “Copyrights” Tab: (Figure3-119) Refer to this tab for specific copyright data. As a user, you are responsible to read this statement. Figure 3-116 System Properties Figure 3-117 System Properties Figure 3-118 System Properties Figure 3-119 System Properties 3-51 / 122...

  • Page 98: Usb Function Driver Properties

    3.2.22 USB Function Driver Properties Table 3-41 USB Function Driver Properties ICON ITEM & FUNCTION “USB Function Driver Properties” Tab: (Figure 3-120) The section allow users to set USB Function, such as USB Serial, USB RNDIS, USB Mass-Storage.(Figure 3-121) Note: when select any USB function, please warm boot device to affect USB function Figure 3-120 USB Function Driver Figure 3-121 USB Function Driver...

  • Page 99: Tap Start

    Figure 3-122 Volume & Sound Figure 3-123 Volume & Sound 3.3 Tap Start The Device has some new functions at “Start” menu, Refer to this section for use. 3.3.1 Security Tap “Start” > “Security” to use Security Functions. Figure 3-124 Start Tab Figure 3-125 Security Tab 3-53 / 122...

  • Page 100: Bluetooth

    Figure 3-126 Security-User mode Figure 3-127 Security-Application disabled 3.3.2 Bluetooth Tap “Start” > “Programs” > “Bluetooth” to use Bluetooth Functions. Figure 3-128 Bluetooth Figure 3-129 Bluetooth Manager 3-54 / 122...

  • Page 101: Boot Manager

    Figure 3-130 Bluetooth-Inquiry Running Figure 3-131 Bluetooth-Devices 3.3.3 Boot Manager Table 3-43 Boot Manager ICON ITEM & FUNCTION “Boot Manager” Tab: (Figure 3-132) You can Enable/Disable Bluetooth or Wi-Fi power after Cold Boot, Warm Boot or Suspend/Resume Figure 3-132 Boot Manager Figure 3-133 Boot Manager 3-55 / 122...

  • Page 102: Brightness

    3.3.4 Brightness Table 3-44 Brightness ICON ITEM & FUNCTION LCD Brightness: (Figure 3-134) Set the LCD brightness by adjusting the slider from low to high Amounts 11 steps: 0%, 10%, 20%, 30%, 40%, 50%, 60%, 70%, 80%, 90%, 100% LCD Brightness The table has Never, 10 seconds, 20 Timeout seconds, 30 seconds, 40 seconds,1...

  • Page 103: Device Power

    Figure 3-136 Keypad Backlight Setting 3.3.5 Device Power Table 3-45 Device Power ICON ITEM & FUNCTION “Device Power” Tab: (Figure 3-137) You can Enable/Disable Bluetooth or Wi-Fi power Figure 3-137 Device Power Figure 3-138 Device Power 3-57 / 122...

  • Page 104: Fn Key Manager

    3.3.6 Fn Key Manager Table 3-46 Fn-Key ICON ITEM & FUNCTION Fn-Key Setting: (Figure 3-139) Fn Key The Application Program of default setting SW Keyboard Reserved Device Power Backlight To assign your favorite application program to Hot Keys. Choose one of Hot Keys from pull-down list.(Figure 3-139) To tap “Browse…”...

  • Page 105: Taskbar And Start Menu

    Figure 3-141 Fn-Key Settings Figure 3-142 Fn-Key Settings 3.4 Taskbar and Start Menu Table 3-47 Taskbar and Start menu ICON ITEM & FUNCTION “General” Tab: (Figure 3-144) Taskbar and Start In this tab, You can change the position of the Taskbar and Menu Start menu Is always on top or not...
  • Page 106 Figure 3-143 Taskbar and Start Menu Figure 3-144 Taskbar and Start Menu- General Figure 3-145 Taskbar and Start Menu- Figure 3-146 Taskbar and Start Menu- Advanced Expand Control Panel 3-60 / 122...

  • Page 107: Chapter 4. Communication

    Chapter 4. Communication 4.1 Installing & Setting Up Microsoft ActiveSync 4.1.1 Installing Microsoft ActiveSync on the Host PC Microsoft ActiveSync is a file transfer tool to synchronize the files on a PC with the files on your Device. To install Microsoft ActiveSync, complete the following steps on the PC: 1.

  • Page 108: Activesync File Synchronization

    Transferring Files: To transfer files, complete the following steps on the host PC: Insert Micro USB cable to Device and connect to PC. After you have established a connection with Device, tap the “Explore” button at the top of the ActiveSync window (or select Explore from the File menu).

  • Page 109: Networking

    4.3 Networking Please see the 3.2.13 Owner, Table 3-31 Owner on page 3-61 for setting up the network ID. And see the 2.5.6 Setting Up Wireless LAN RF to setup the 802.11a/b/g Wireless LAN for RF connecting. 4-3 / 122...

  • Page 110: Chapter 5. Software Applications

    Chapter 5. Software Applications 5.1 Introduction You can switch to any software program by tapping the Start Menu. 5.2 Software Applications 5.2.1 Internet Explorer With Internet Explorer, you can view Web or intranet Web pages on your device. You will need to use a modem or WLAN to connect to an Internet server provider (ISP) or network.
  • Page 111 5.2.1.3 Navigation Control Internet Explorer uses sliding menus for application and navigation control. Tap and drag the sliding menus to the left or right to see the hidden menu items and toolbars. To achieve more screen real estate in Internet Explorer, you can hide the Status bar and View menu.
  • Page 112 5.2.1.9 Add and view Favorites Go to the page you want add Select Favorites > Add To Favorites. If necessary, locate the folder you want. Confirm or change the name. To view your favorite Web sites, select Favorites and the Web site you want to view.

  • Page 113: Microsoft Wordpad

    from the Internet or Intranet without using cached memory. Select File > Save As Specify a folder location and give the file name. 5.2.1.17 Copy a Web page to a document Select all or part of the Web page you want to copy. Select Edit >...
  • Page 114 Select Edit > Find Enter the text you want to find. For a paragraph, enter ^p. For a tab stop, enter ^t. Select the search options you want. To continue searching, select Edit > Find > Next. Replace text To replace text in one part of document, select that part. Otherwise, the whole document is searched.
  • Page 115 Select Set As Default To confirm that your changes will be applied to subsequent documents you create, select Yes. Note: To apply the default font and stylus to selected text, select Apply Default. Select a different font Select the text you want to change. To select all text, select Edit > Select All.
  • Page 116 To move the Restore button, drag the bar on the left side. Display or hide scroll bars Select View > Horizontal Scroll Bar or Vertical Scroll Bar. Zoom in or out Select View > Zoom, and select the desired percentage. Note: For Custom, enter the exact percentage and select OK.
  • Page 117 5.2.2.8 Converting Documents About document conversion If an e-mail program is installed on your device and you receive an attached Word document or template created in Word version 6.0 or later, WordPad will convert the file on your device. To view the document, simply open the attachment in your e-mail program or open the file in the WordPad.
  • Page 118 Tabs, alignment, bullets, indentation, simple numbered lists, and paragraph spacing are retailed and displayed in WordPad. Pictures Pictures are removed during conversion. Table of Contents Table of Contents text and some formatting are preserved. However, any text set at right-aligned tab stops may wrap to the next line. Index Index text and some formatting are preserved.

  • Page 119: Windows Explorer

    In the Remote Connection window, type your user name, password, and domain(if required), and then select OK. Figure 5-2 Remote Connected 5.2.3.2 Disconnecting Without Ending a Session In the Remote Connection window, select Start > Shutdown. Select Disconnect > OK. Note: If you previously disconnected from a Terminal Server without ending the session, the Terminal Server will continue to execute any running processes and Remote Connection can later reconnect to this same...
  • Page 120 To go to the next folder (which you have just viewed), select Go > Forward. Figure 5-3 Windows Explorer Use the Go menu To quickly access the My Documents folder, select Go > My Documents To see all of the folders you have accessed, select Go > History. Double-tap a folder to return to it.

  • Page 121: Flash Disk

    To organize your favorites, select Favorites > Organize Favorites. Transfer a file using infrared To send a file, select it, line up the infrared ports, and select File > Send To > Infrared Recipient. To receive a file, line up the infrared ports, and select File > Receive. 5.2.4.4.

  • Page 122: Flashdisk Size

    Figure 5-4 FlashDisk 5.3.3 FlashDisk Size The size of the FlashDisk will vary, depending on the size of system firmware. Inside the FlashDisk directory, tap File > Properties. The FlashDisk Properties dialog: The number following Free is the amount of memory currently available on your device.
