M/C Mounting Kit, Type-1 RHD
Montagesatz HBZ, Typ-1 RHD
Fi tti n g In s tr u c ti o n s
Features:
- easy mounting
- precision made alloy adapter ring
www.csp-shop.de
info@csp-shop.de
M o n ta g e a n l e i tu n g
Besonderheiten:
- Sehr einfache Montage
- CNC gefräßter Adapterring aus Aluminium
1
Version: 08-21
© by CSP Products
