Components:
Tools Required:
10mm spanner
Diagonal
Bracing
'Long Horizontal'
x 6
•
Layout the four legs.
•
Join each pair together with the 'short side' sections.
•
Attach the other side frame in a similar manner.
Trays x 15
Nuts,
Bolts,
Caps.
Legs
'Short Side'
x 4
x 6
MAXI
Please read ALL before you begin.
•
Tip your nuts, bolts and caps into one of the seed
trays.
•
Throughout initial assembly
the nuts and bolts need only
be finger tight. The
structure will be squared out
on a level floor later on.
•
In this model the nuts need
to face away from the
frame.
•
Place one of the sides on the floor and attach the
'long horizontal' sections.
•
The structure should now be lifted onto its legs. It
will be unstable at this stage due to the
un-tightened nuts and bolts so it is a good idea to
lean it up against a wall.
Aluminium Seed Tray unit.
INSTRUCTIONS
PTO
Advertisement
Table of Contents
Related Manuals for The Greenhouse People MAXI
Summary of Contents for The Greenhouse People MAXI
- Page 1 MAXI Aluminium Seed Tray unit. INSTRUCTIONS Please read ALL before you begin. Components: Trays x 15 Tools Required: • Tip your nuts, bolts and caps into one of the seed 10mm spanner Nuts, trays. Bolts, • Throughout initial assembly Diagonal Caps.
- Page 2 Check that the frame is square, diagonal measurements should be equal. Adjust If necessary. • Push the 'black caps' onto each nut. If you would like a brochure containing our extensive product range then please contact us at, ‘The Greenhouse People’, Unit 9B Blythe Park, Cresswell Lane, Cresswell, Stoke—On—Trent. Staffs. ST11 9RD.
