Medi Alarm Pro 4G Quick Start Manual

Medi Alarm Pro 4G - Quick Start Guide

Turning the Medi Alarm ON or OFF

Turn ON: Press and hold the Bottom Side Button for 2-3 seconds.
Turn OFF: Press and hold the Bottom Side Button for 4 seconds.
•
Turn ON outside and leave outside for 10 minutes.
•
The word "Medi Alarm" will appear on the screen followed by "GSM Init Now" until
it's finished powering on.
•
The date and time will display on the screen when it is ready.
The date is shown backwards as YYYY-MM-DD.

Power Saving Mode

Wake Up Screen: Press the Top Side Button for 1 second.
•
The screen will turn itself off after 60 seconds to save power.
•
The Medi Alarm is still ON when the screen is OFF. To wake up the screen press the
Top Side Button for 1 second until you see the date/time screen.

Recharging

Charge for at least 1 hour a day in the charger cradle.
•
Connect the large end of the cable to the power adaptor, the small end of the
cord to the charger cradle. A red light indicates it is plugged in.
•
A charging symbol should appear on the screen after a few seconds.
•
If the device is not charging, clean the gold circles on the back of the device.
Also check the gold pins on the charger cradle are sticking up.
•
If the device is OFF, turn it ON in the charging cradle.

SOS - Call Out

SOS Call: Press/hold the SOS button for 2-3 seconds.
•
The screen will show SOS and the device will beep once.
•
After about 10 seconds, the Medi Alarm will call the Contacts one by one until
someone answers and it will send a text message with the GPS location.
•
The User can cancel the SOS call out by pressing the SOS button for 2 seconds. The
screen will then display "SOS Cancelled"
•
If you have chosen Medi Alarm 24/7 Monitoring our friendly team will answer the
call and notify your emergency contacts or 000 if required.

Fall Detection - Call Out

If the device detects movement that may indicate a fall it will...
•
Display "MD" on the screen and beep 10 times.
•
During the 10 beeps, the User can cancel the call out by pressing the SOS button for
2 seconds. The screen will then display "MD Cancelled".
•
After the 10 beeps the device will call the Contacts one by one until someone
answers and it will send a text message with the GPS location.
•
If too many false alarms, call us, so we can adjust the sensitivity.
•
If you have chosen Medi Alarm 24/7 Monitoring our friendly team will answer the
call and notify your emergency contacts or 000 if required.
