Summary of Contents for THORLABS QTH10
- Page 1 QTH10(/M) Quartz Tungsten-Halogen Lamp User Guide...
-
Page 2: Table Of Contents
QTH10(/M) Quartz Tungsten-Halogen Lamp Table of Contents Chapter 1 Warning Symbol Definitions .................... 1 Chapter 2 Safety ............................ 2 Chapter 3 Description ........................... 3 3.1. Product Overview ......................3 3.2. Mechanical Description ....................3 3.3. Power Supply ........................3 3.4. Bulb Alignment and Replacement ................. 3 ... -
Page 3: Chapter 1 Warning Symbol Definitions
QTH10(/M) Quartz Tungsten-Halogen Lamp Chapter 1: Warning Symbol Definitions Chapter 1 Warning Symbol Definitions Below is a list of warning symbols you may encounter in this manual or on your device. Symbol Description Direct Current Alternating Current Both Direct and Alternating Current... -
Page 4: Chapter 2 Safety
WARNING Handle with care during use, as impact will severely shorten lamp life. WARNING If the lamp is used with a bulb not purchased from Thorlabs, Thorlabs is not responsible for any adverse effects from radiation exposure. Page 2 TTN016327-D02... -
Page 5: Chapter 3 Description
Mechanical Description The QTH10(/M) has a 10 W, 12 V quartz tungsten-halogen bulb in the middle, an ACL5040U condensing lens on one end, and an SM2-threaded end cap on the other end. The housing is compatible with our TR series posts. -
Page 6: Chapter 4 Specifications
QTH10(/M) Quartz Tungsten-Halogen Lamp Chapter 4: Specifications Chapter 4 Specifications Specifications Ushio Bulb Manufacturer Base G4 2-Pin Bulb Type Quartz Tungsten-Halogen Bulb Optical Output Power 50 mW (Typical) Color Temperature 2800 K Rated Life (Hours) 2000 Bulb Voltage 12 V... -
Page 7: Chapter 5 Mechanical Drawing
QTH10(/M) Quartz Tungsten-Halogen Lamp Chapter 5: Mechanical Drawing Chapter 5 Mechanical Drawing 2.69" (68.4 mm) 1.02" 0.67" Lens Assembly with Ø1.90" (17.0 mm) (26.0 mm) ACL5040U Condenser Lens (48.3 mm) SM2- Quartz Tungsten- Threaded Halogen Bulb 2.80" End Cap (71.1 mm) (Nominal) SM2 (2.035"-40) -
Page 8: Chapter 6 Regulatory
Waste Treatment is Your Own Responsibility If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. -
Page 9: Chapter 7 Thorlabs Worldwide Contacts
QTH10(/M) Quartz Tungsten-Halogen Lamp Chapter 7: Thorlabs Worldwide Contacts Chapter 7 Thorlabs Worldwide Contacts USA, Canada, and South America UK and Ireland Thorlabs, Inc. Thorlabs Ltd. 56 Sparta Avenue 1 Saint Thomas Place Newton, NJ 07860 Ely CB7 4EX Great Britain... - Page 10 www.thorlabs.com...
