acus One Forstreet 10 Quick Start Manual

ACUS Artesia BT-1
A
1. Make sure that the amplifier is powered off and connect the ACUS Artesia BT-1
Bluetooth Receiver to mini-USB AUX IN connector.
2. Turn the amplifier on. The ACUS Artesia BT-1 Bluetooth Receiver blue LED
indicator lamp should flash quickly. This lasts for about 5 seconds. Then it will
flash again every 7 seconds until it matches (or pair) successfully with another
Bluetooth device.
3. After it has matched successfully, find ACUS Artesia BT-1 as an option on your
Bluetooth Device's Settings and then select it to connect.
4. When the blue LED Indicator lamp on the ACUS Artesia BT-1 Bluetooth
Receiver is ON steady with no flashing, then the two devices have been
successfully connected.
ACUS Artesia LS-1 -
TRRS ADAPTER for your live streaming
LEFT
RIGHT
GND
MIC
3 1
CABLE NOT INCLUDED
B
1. 3.5 mm Right-Angle Stereo Plug:
connect to AUX IN Input.
2. 3-Pole XLR Female Connector:
connect to DIRECT OUT output.
3. 3.5 mm TRRS Jack Connector: connect to
recording /reproduction device used for your Live
Streaming with a 3.5mm TRRS Plug to Plug cable
(not included).
Suggestions : for obtaining better configuration is very
important to have a moderate volume to the amplifier DIRECT OUT output.
If the amplifier is equipped with the attenuation switch (labeled with -10dB)
push this switch for a very easy and fast signal level matching.
If the amplifier is not equipped with this switch, for best configuration please
reduce all channel volume more than half and then regulate the amplifier
master volume for obtaining the right sound to the speaker.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
8. Do not install near any heat sources as radiator, heat registers, stoves
or other apparatus (including amplifiers)) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Use only with the cart, stand, tripod, braket or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
11. Refer all servicing to qualified personnel. Servicing
is required when the apparatus has been damaged in
any way, such as power-supply cordor plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or
has been dropped.
12. Do not cover the dissipation heat sink. Leave space around the
amplifier to ensure a good ventilation.
13. The apparatus shall not be exposed to dripping or spashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
14. No naked flame sources, such as lighted candles,should be placed
on theapparatus.
2
15. Remove the battery during transportation.
Frequency Response: 40Hz - 20kHz
Max Power Out: 120W
System Format: 2 way Amp
Woofer Power: 100W
Tweeter Power: 20W
Construction: Brich Plywood Cabinet
Weight: 11 kg
Dimensions (WxHxD) 302x425x310 mm
N.B.
For more information you can download the complete
manual from the company web site.
is a product entirely
designed and produced in Italy
by
ACUS SOUND ENGINEERING SRL
Via Cupa Madonna di Varano, 8 - 62019 Recanati (MC) - Italy
Tel. +39 071 9793109
www.acus-sound.it - info@acus-sound.it
