TOUCHLESS THERMOMETER

User Manual

Table of Contents

Need help?

Do you have a question about the 005-018 and is the answer not in the manual?

Questions and answers

Summary of Contents for Medic Therapeutics 005-018

Page 1 TOUCHLESS THERMOMETER User Manual...
Page 2 INTRODUCTION Thank you for purchasing this Touchless Thermometer. It has been carefully developed for accurate, safe and fast temperature measurements. Please read these instructions carefully before using this product and keep the instructions and the thermometer in a safe place. PACKAGE CONTENTS Name Quantity...
Page 3: Table Of Contents
TABLE CONTENTS WARNINGS AND PRECAUTIONS Product Description Overview Structure Operating principle Indications for use Features Product Structure Display description How to use your thermometer Take your forehead temperature Take room/object temperature After a measurement Read your temperature Switching between mute and un-mute Checking 35 sets of memory data °C/°F conversion Temperature compensation adjustment...
Page 4: Warnings And Precautions
WARNINGS AND PRECAUTIONS • Keep out of reach of children under 12 years. • Never immerse the thermometer into water or other liquids (not waterproof). For cleaning and disinfecting please follow the instructions in the “Care and cleaning” section. • Never use the thermometer for purposes other than those it has been intended for.
Page 5: Product Description
• Do not use the thermometer on newborns for continuous temperature monitoring purposes. • Do not take a measurement while or immediately after nursing a baby. • Patients should not drink, eat, or be physically active before/while taking the measurement. PRODUCT DESCRIPTION Overview Infrared Thermometer measures the body temperature based on the...
Page 6: Structure
WARNINGS AND PRECAUTIONS Structure The thermometer consists of a shell, an LCD, a measure button, a beeper, an infrared temperature sensor, and a Microprocessor. Operating principle The infrared temperature sensor collects infrared energy emitted by the skin surface. After being focused by a lens, the energy is converted into a temperature reading by the thermopiles and measurement circuits.
Page 7: Features
FEATURES • Non-Contact Design, Safe and more hygienic to use. • Quick measurement, less than 1 second. • Accurate and reliable. • Easy operation, one button design. • Multi-functional, can measure forehead, room, liquids, and object temperature. • 35 sets of memories, easy to recall. •...
Page 8: Display Description
DISPLAY DESCRIPTION Temperature value Object temperature mode Forehead temperature mode Fahrenheit / Celsius degrees Battery level Memory recall Mute /Un-mute HOW TO USE YOUR THERMOMETER When using the thermometer for the first time, please load the batteries. Take your forehead temperature Press the Measure button to power on.
Page 9: Take Room/Object Temperature
If the eyebrow area is covered with hair, sweat or dirt, please clean the area beforehand to improve the reading accuracy. Always check if the lens is clean. Always make sure the user and the thermometer will have been in the same room prior to the measurement.
Page 10: Read Your Temperature
READING YOUR TEMPERATURE T indicates a temperature reading in forehead mode. 1. I f 89.6°F ≤ T ≤ 99.2°F (32°C ≤ T ≤ 37.3°C), the green light will last for 12 seconds, with one long beep. 2. I f 99.3°F ≤ T ≤ 100.3°F (37.4°C ≤ T ≤ 37.9°C), the orange light will last for 12 seconds, with 3 short beeps, and the value in LCD flickers, which is a warning that you may have a light fever. 3. I f 100.4°F ≤ T ≤ 109.2°F (38°C ≤ T ≤ 42.9°C), the red light will last for 12 seconds, with 5 short beeps, and the value in LCD flickers, which is a warning that you may have a high fever.
Page 11: To Turn Off
TO TURN OFF The unit will shut down automatically after 10 seconds of no use. Or you can long press the Measure button for 6 seconds to turn the device off. CAUTION 1. All memory records will be lost when you uninstall/reinstall the batteries.
Page 12: Care And Cleaning
7. In the following situations it is recommended that 3-5 temperatures in the same location be taken and the highest one taken as the reading: • Newborn infants in the first 100 days. • Children under three years of age with a compromised immune system and for whom the presence or absence of fever is critical.
Page 13: Error And Troubleshooting
ERROR AND TROUBLESHOOTING Error Type Possible Cause Description & Solution Failed to power on The battery level is Replace with a new too low battery Polarities of the Ensure the batteries batteries are reversed are in the right position The thermometer is Contact dealer damaged The reading is too low...
Page 14 The ambient 3 short beeps and red temperature is not in backlit for 3 seconds. range Take a measurement under an ambient temperature between 50.0°F (10°C) and 104°F (40°C) Memory Error 3 short beeps and red backlit for 3 seconds. Contact dealer In forehead mode, T >...
Page 15: Specifications
SPECIFICATIONS Product name Infrared thermometer Power supply DC1.5Vx2 Forehead: 32.0°C-42.9°C (89.6°F—109.2°F) Measurement range Object: 0°C-100°C(32°F-212°F) Forehead mode ±0.2°C/±0.4°F Accuracy (Laboratory) Object mode ±1.0°C/1.8°F Display resolution 0.1°C/°F Measuring distance 0-3cm Automatic shutdown 10s±1s Memory 35 groups of measured temperature Temperature: 10°C-40°C (50°F-104°F)/ Operational conditions Humidity: 15-95%RH, non-condensing Atmospheric pressure: 86-106 kPa...
Page 16: Symbols
SYMBOLS Symbol Description Type BF applied part Information about a manufacturer Please read the instructions carefully Waste electrical materials should be sent to a dedicated collection point for recycling Serial number Batch number IMPORTANT Inaccurate reading or thermometer damage may occur if the thermometer is not correctly used.
Page 17: Emc Information
EMC INFORMATION Guidance and manufacturer’s declaration-electromagnetic emissions The infrared thermometer is intended for using in the electromagnetic environment specified below. The customer or the user of the infrared thermometer should assure that it is used in such an environment Emissions test Compliance Electromagnetic environment-guidance...
Page 18 Guidance and manufacturer’s declaration-electromagnetic immunity The infrared thermometer is intended for use in the electromagnetic environment specified below. The customer or the user of the infrared thermometer should assure that it is used in such an environment. Immunity test IEC60601 test Compliance Electromagnetic level...
Page 19 Power 3A/m 3A/m Power frequency frequency magnetic fields (50/60Hz) should be at levels magnetic field characteristic of a IEC 61000- typical location in a typical commercial or hospital environment NOTE UT is the a.c. mains voltage prior to application of the test level. Guidance and manufacturer *s declaration-electromagnetic immunity The infrared thermometer is intended for use in the electromagnetic environment specified below.
Page 20 IEC 6100043 3V/m 80kHz 3V/m d=1.2P80MHz to 800MHz to 2.5GHz d=2.3P 800MHz to2.5MHz Here P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer and dis the recommended separation distance in meters (m). Field strengths form fixed RF transmitters, as determined by an electromagnetic site...
Page 21 Recommended separation distances between portable and mobile RF communications equipment and the infrared thermometer The infrared thermometer is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the infrared thermometer can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the infrared thermometer as recommended below,...
Page 22: Warranty And After-Sale Service
Further, it does not cover damage caused by accident, impact, negligence, or normal wear and tear. Should you discover your Medic Therapeutics product is not functioning properly, please send your device to our repair center for evaluation.
