Connecting the Display

Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.

Connecting the stand base

1
.
Place the monitor with its front facing downward on a cushion or soft cloth.
2
.
Rotate the Stand Body as shown in figure
1
3
.
Assemble the Stand Base(Front, Rear) into the Stand Body in the correct direction.
4
.
Once assembled take the monitor up carefully and face the front side
Warning
The tape and locking pin may only be removed from those monitors equipped with a standing base
when the base is pulled up.
Otherwise, you may be injured by the protruding sections of the stand.
1
.
Stand Base
Stand Body
A3
