DO NOT use this unless you have reviewed & understand this procedure.
Safety glasses must be worn at all
times in work areas.
Steel cap boots must be worn at all
times in work areas.
PORTABOOM® must not be operated unless it is in a safe condition for use.
PRE-OPERATIONAL SAFETY CHECKS
1.
Ensure that the PORTABOOM® PRE-START inspection checklist is completed prior to utilisation,
PORTABOOM® must be in a safe and working condition prior to use.
2.
Faulty equipment must not be used. Immediately report suspect equipment to your Supervisor.
PORTABOOM® SITE OPERATIONAL INSTRUCTIONS
One operator operating one PORTABOOM®:
1. Park vehicle / trailer used to transport PORTABOOM® at setup location on as close to level
ground as possible.
2. Unload PORTABOOM® Tower using safe manual handling techniques including straight
back and bending at the knees.
3. Must be inside an existing TTM worksite.
4. Must be positioned so they are clear of any moving or operating plant and/or machinery.
5. Must not undertake any other task or work activity whilst in control of the PORTABOOM
units.
6. It is recommended that the PORTABOOM® operator is not further than 75mtrs from the
PORTABOOM® Tower.
7. Must have a visual of 120m on the approach to the PORTABOOM® Tower you are
operating.
8. Must be ready and in position to invoke manual or STOP/SLOW operation if required.
This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with
other references – This SOP remains the property of Traffic and Access Solutions Pty Ltd – PORTABOOM® brand and designs
are registered trademarks of Traffic & Access Solutions Pty Ltd ABN 162 894 975
Gloves must be worn at all times when
handling equipment.
Hard hat must be worn at all times
while working.
Advertisement
Summary of Contents for Vanguard PORTABOOM 49-PB
- Page 1 DO NOT use this unless you have reviewed & understand this procedure. Gloves must be worn at all times when Safety glasses must be worn at all handling equipment. times in work areas. Steel cap boots must be worn at all Hard hat must be worn at all times times in work areas.
- Page 2 One operator operating multiple PORTABOOM®S: 1. Must be inside an existing TTM worksite. 2. Must be positioned so they are clear of any moving or operating plant and/or machinery. 3. Must not undertake any other task or work activity whilst in control of the PORTABOOM units.
-
Page 3: Potential Hazards
GENERAL • Ensure all persons, hands and limbs are clear from crush / drop zones at all times. • Ensure equipment is loaded and unloaded as specified in this procedure and all items are secure prior to driving. HOUSE-KEEPING • Switch off equipment. - Page 4 PORTABOOM® SET UP Step Instruction Diagram Once arriving to site, review Traffic Management Diagram (TMD) and identify required positions of PORTABOOM® unit(s) on site. “MANUAL TRAFFIC CONTROL” TA2/TA21 sign is to be placed in accordance with dimension “C” sign spacing. Diagram F2.14a is based on diagram F2.14 TWO-WAY TWO-LANE ROAD, single lane alternating flow which has been modified to...
- Page 5 Prior to commencement of PORTABOOM® setup, an assessment of overhead hazards must be conducted. If overhead hazards have been identified where a PORTABOOM® needs to be positioned, the Site Traffic Management Supervisor (STMS) in consultation with the PORTABOOM® Operator may be able to reposition the PORTABOOM®...
- Page 6 Prior to setup, assess weather conditions by checking an approved or trusted weather radar for current and forecasted weather conditions. If the current or forecasted weather advises of strong winds exceeding 50kph (kilometers per hour) then add weight to the Stability Legs using sandbags when setting up PORTABOOM®s as per steps 34, 35, 36 and Note 1: It is mandatory to remain diligent and...
- Page 7 PORTABOOM® Tower Setup Process As per steps 2 and 3, identify potential hazards prior to positioning PORTABOOM® i.e. Look for low lying power lines, tree branches, street lights, road signage which the PORTABOOM® Boom Arm may come in contact with in its setup and operation. (PORTABOOM®...
- Page 8 Prior to installation make sure there are appropriate TTM controls in place for the protection of the installer(s). Position PORTABOOM® Tower in the shoulder/kerb for set up. Ensuring the shaft is facing the footpath Once in position enable PORTABOOM® Tower brakes by pushing down on brake pedals at the bottom of the PORTABOOM®...
- Page 9 Remove Boom Arm from carry bag. Position the Boom Arm at approx. 45 degrees to the Tower. This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with other references – This SOP remains the property of Traffic and Access Solutions Pty Ltd – PORTABOOM® brand and designs are registered trademarks of Traffic &...
- Page 10 Align the Boom Arm billet tabs (indicated by arrows). With the channels on the shaft (indicated by arrows). Position the Boom Arm square onto the shaft and align the billet tabs with the channels on the shaft. This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with other references –...
- Page 11 Once aligned connect Boom Arm to Tower by pushing firmly. Once connected manually reposition the Boom Arm to a vertical position. This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with other references –...
- Page 12 Then holding firmly pull the Boom Arm towards you. Lock Boom Arm into place using the locking mechanism on the Tower. Using the key provided align the cut out on the key with the red dot on the lock and open up the small compartment panel.
- Page 13 Turn power “ON” (Green LED will illuminate). Press “RED PUSH BUTTON” to move the Boom Arm into a horizontal position. When the Boom Arm is horizontal proceed to the next step. This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with other references –...
- Page 14 Loosen the two (2) Boom Arm tightening screws. Extend the Boom Arm to the span required, ensuring that the end of the Boom Arm is at least 500mm from the center line of the road. Once the correct span is established hand tighten using the two (2) Boom Arm tightening screws.
- Page 15 Attach “STOP” sign using the buckles straps to secure the sign, ensuring that one buckle is on the fixed Boom Arm and the other buckle is on the extension. This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with other references –...
- Page 16 Check manual operation of the unit (UP, DOWN, STOP) using the “RED PUSH BUTTON” in the small compartment panel. Check the operation of both remote controls (UP, DOWN, STOP) using the 2x ONE button remote controls provided. Note: All remotes are labelled (front and back) with a unit number to match the Tower unit number.
- Page 17 Disable Brakes. Ensure PORTABOOM® Boom Arm is Vertical. Reposition PORTABOOM® Tower into “LIVE” Operational Position. This SOP does not necessarily cover all possible hazards associated with the plant and should be used in conjunction with other references – This SOP remains the property of Traffic and Access Solutions Pty Ltd – PORTABOOM® brand and designs are registered trademarks of Traffic &...
- Page 18 Enables brakes. Secure stability legs by first unwinding the wing nut to maximum. Placing one hand on the wing nut bolt and the other hand at the base of the leg pull up slightly and then slide leg into fixing position ensuring the rubber stopper is firmly on the ground.
- Page 19 Once in position tighten the wing nut to secure leg into position Stability Leg Setup complete. Leave PORTABOOM® in an upright operational position until you are ready to commence controlling traffic. Ensure approved TTM as per the approved TMP is installed in accordance with the selected PORTABOOM®...
- Page 20 In the event of windy or forecasted windy conditions sand bags MUST be applied to all four PORTABOOM® legs for additional stability. Take hooks out of the side pocket of the carry bag. Fix sandbag hooks to all 4 stability legs by placing the hook through the hole at the back of the stability leg.
- Page 21 NOTE • Once all PORTABOOM® units are setup, tested and ready for operation, position yourself in a safe area clear of any moving or operating plant and/or machinery that will allow you to operate the PORTABOOM® units ensuring you adhere to all line of sight and operational distances and radius.
- Page 22 PORTABOOM® PACK UP INSTRUCTIONS Ensure Tower is turned on. Remove sandbags from stability legs and stow on vehicle (if applicable). Remove sand bag hooks from stability legs and stow in the side pocket of the carry bag (if applicable). Remove the unit number magnet from the Tower and put magnet and remote control in the side pocket of the carry bag.
