- Page 1 HUGO User Manual SafeGuard Power Solutions, LLC. Rev 1.3 www.safeguardpowersolutions.com...
-
Page 2: Table Of Contents
OPERATIONS ............................... 14 STORAGE AND TRANSPORTATION ......................15 MAINTENANCE AND TROUBLESHOOTING ....................15 Maintenance ........................... 15 Troubleshooting ..........................16 TECHNICAL SUPPORT ..........................17 REGISTER YOUR HUGO ..........................17 TECHNICAL SPECIFICATIONS ........................18 P A G E | 1 SAFEGUARD POWER SOLUTIONS 855.484.6797... - Page 3 It is prohibited to connect any appliance or electrical load other than those for which this product is intended. NOTE: Throughout this document the HUGO-X1R (Uninterruptible Power Supply) may also be referred to as "UPS". P A G E | 2 SAFEGUARD POWER SOLUTIONS 855.484.6797...
-
Page 4: Precautions And General Guidelines
• Save all warnings and instructions for future reference. HUGO recommends the UPS be used with all installed safety features. Customer assumes all liability for injury that could result from improper use of this UPS and responsibility for all necessary training to ensure safe operation of this UPS. -
Page 5: Electrical Safety Practices
HUGO USER MANUAL REV 1.3 ELECTRICAL SAFETY PRACTICES In the event of a malfunction or breakdown, grounding provides a path of least resistance GROUNDING: for electric current which reduces the risk of electrical shock. Improper connection of the equipment grounding conductor can result in a risk of electric shock. -
Page 6: Electrical Safety Practices
HUGO USER MANUAL REV 1.3 ELECTRICAL SAFETY PRACTICES WARNING ONLY OPERATE THE UPS IN A CLEAN ENVIRONMENT. DO NOT EXPOSE THE UPS INTERIOR TO RAIN OR WET CONDITIONS. WATER ENTERING A UPS WILL INCREASE THE RISK OF ELECTRIC SHOCK. KEEP AWAY FROM LIVE CIRCUITS •... -
Page 7: Introduction
REV 1.3 INTRODUCTION The new and improved HUGO-X1R is a 350W interruptible power supply (UPS) that is designed to support gas tankless water heaters, direct vent space heaters, vent free space heaters, boilers, furnaces, or any other gas-powered appliances. The UPS can also be used to charge mobile devices such as mobile phones, tablets, laptops, modems, and routers. -
Page 8: Working Principle
HUGO USER MANUAL REV 1.3 WORKING PRINCIPLE When the utility power is normal, the UPS will transfer the utility power to downstream application. During a power outage or when the utility power is below 92v or above 138v, the UPS will transfer to inverter mode. -
Page 9: Led Display
HUGO USER MANUAL REV 1.3 • LED DISPLAY • INSTALLATION Ensure that the ON/OFF switch is in the “OFF” position during installation. The UPS can store a significant amount of power for an extended period. AC/DC voltage may be present at the output terminals even when the input terminals are 1. - Page 10 ¾” plywood panels only due to the heavy weight of the unit (45 lbs). SPS is not liable for any installation errors such as improper use of mounting material and/or mounting methods.
- Page 11 7. Double check wiring to ensure the connection is correct, close and lock the side panel as shown below. 8. Finally, connect HUGO’s power cord with the main power outlet. NOTE: HUGO’s rated input and output is 115 volts, can be fitted to any circuit breaker rated 15A. Ensure all connects are correct and that the input and output power cord is properly grounded.
-
Page 12: Flow Sensor Installation
HUGO USER MANUAL REV 1.3 At any time, the UPS detects overload or under/over voltage as indicated by the LED display or chirping alarm, it will attempt delay restarts. Once such issue is resolved, i.e., battery charge is normal or load is under 350w, the UPS will automatically restart and remove any fault indicators. -
Page 13: Flow Installation
MUST unplug the “Temp.Flow” port as shown below in order for HUGO to function properly. With this setup, HUGO will provide AC output automatically and continuously whenever there is a power loss and operate in battery mode; when power restores, city power will automatically recharge HUGO and pass-thru city power to downstream appliances. -
Page 14: Hardwiring Instruction
Place wire cap or insulation tape over the removed wires to ensure no conductors are exposed if • touched accidentally. h) Feed your appliance’s power cord from the outside of HUGO’s wiring box to get inside the HUGO unit, as shown below: P A G E | 13 SAFEGUARD POWER SOLUTIONS 855.484.6797... -
Page 15: Operations
At this time, the “INV” LED light will be steady green. Once a power outage is detected, HUGO will first chirp once to alert user HUGO is in inverter mode. The chirp will continue once every 30 seconds and will auto shutoff after 5 minutes. -
Page 16: Storage And Transportation
HUGO will auto reset. Refer to “Protection – Overload or Short Circuit Protection” in section 13 below. When city power is restored after a power outage, HUGO will start charging itself and reset to utility power mode after 10 minutes. This time delay will allow power grid to become steady to •... -
Page 17: Troubleshooting
Though no necessary, but it is strongly recommended to install any 3 party surge protection on the wall outlet where HUGO is plugged in. This added protection will also • prevent any HUGO board burnouts when city power is unstable. -
Page 18: Technical Support
HUGO USER MANUAL REV 1.3 SafeGuard Power Solutions, LLC. TECHNICAL SUPPORT Email: support@sps-us.net Phone: 855.484.6797 (M-F, 9-5 pst) REGISTER YOUR HUGO URL: https://safeguardpowersolutions.com/register-your-product/ DATE OF PURCHASE: _____________________________________________ POINT OF SALE: _____________________________________________ ORDER NUMBER: _____________________________________________ MODEL: _____________________________________________ SERIAL NUMBER: _____________________________________________ INSTALLER:... -
Page 19: Technical Specifications
HUGO USER MANUAL REV 1.3 TECHNICAL SPECIFICATIONS Model No. HUGO-X1R AC Voltage 92-138V Frequency 50 Hz/60Hz ±10% Input P.F. (VA/W) = 0.6 500VA/350W Voltage 113-117V (at Battery Mode) Utility power mode: Output frequency is the same as input. Output Frequency Battery mode: 50/60Hz ±0.1...
