Summary of Contents for Massive DSP-1
- Page 1 60W x 4 Sound Quality DSP Digital Signal Processor Built-In 4 CH Amplifier 31 Band EQ CSR 5.0 Bluetooth...
- Page 2 Audio customers are accustomed to, incorporating the latest in small format technology. Not only do you get a high performance, high quality product, but you also are saving a lot of space. The same proven quality of Massive Audio lives on in the new DSP-1.
- Page 3 Massive Audio™ DSP -1 Features Eight (8) fully configurable output channels capable of 4V rms (12.5V pp) RCA output. Eight (8) summing input channels, compatible with Low-Level & High-Level input types. Bluetooth Audio Streaming with Codec for audiophile audio quality.
- Page 4 AMPLIFIER POWER& PANEL LAYOUT High level input High level output (speaker input) (speaker output) Rear Right Rear Left Front Right Front Left Front Left Front Right Rear Left Rear Right Power supply cortrol High level input + 12V (auxiliary input) Output control Sources signals indicator light.
- Page 5 AMPLIFIER POWER& PANEL LAYOUT Front channel full frequency(RCA)output. Subuoofer signal (RCA)output AUX signal (RCA)input Rear channel signal output.
-
Page 6: Installation Flowchart
/black black black INSTALLATION FLOW CHART Install proper harness for Remove head unit from Disconnect wiring harness your vehicle dash from head unit Locate harness for the Pull through DSP-1 wiring Reconnect wiring harness vehicle harness to head unit... - Page 7 Connect DSP-1 harness to Pull through DSP-1 wiring headunit wiring harness harness to installation location COMPUTER TUNING PC INTERFACE sound effect patterns & modes 1) Sound field on the column 2) Sound field on the dashboard 3) Sound field on the side doors...
- Page 8 COMPUTER TUNING PC INTERFACE SOUND PATTERN ADJUSTMENTS Subwoofer Bass: -60~80Hz Increase Subwoofer Bass: +60~80Hz Upper Bass: -125Hz Increase Upper Bass: +125Hz Mid-Range: -400~500Hz Increase Mid-Range: +200~400Hz Mid to High Freq. -1250~200Hz Increase High Freq. Tones: +1KHz Vocal Adjustment: -3KHz Increase Upper Vocals: +3KHz Enhance Vocal Thickness: +4~8KHz High freq.
-
Page 9: Important Installation Notes
Massive Audio™ dealer for best installation set up. The DSP-1 requires the wiring harness that is included with the DSP-1, we do not recommend using different wiring harnesses as you risk damage to the DSP-1. TROUBLE SHOOTING... - Page 10 PARAMETER...
