Page 1 FB Blowers...
Page 2: Manufacturer Declaration
MANUFACTURER DECLARATION MOD..............................SERIAL NUMBER ......................YEAR ............................... The pump should not be operated until verification can be provided that the installation conforms to directive 2006/42/CE and any current revisions. Always be sure that the installation of the pump conforms to all applicable installation and operational requirements pertaining to the country and region for which its use is intended.
Page 4 ----- 4 HOLES ¢N ¢s - j· ¢S...
Page 5: Working Principle
WORkING PRINCIPLE This is a three lobe positive displacement pump and can work as an exhauster and a blower. The gas enters the pump through the suction port at a certain pressure and temperature. It goes out through the exhaust port at another pressure and temperature.
Page 6: General Information
Owners, operators and installers must adhere to all instructions provided in this manual. FRUITLAND will not be responsable for damages due to the use of spare parts which are not original parts supplied by or approved by FRUITLAND.
Page 7: Installation
Only qualified and trained personnel who are familiar with the FRUITLAND products should work on, repair or operate the pump. Original parts supplied by or approved by FRUITLAND must only be used for repair and main-tenance. Failure to comply with the instructions provided in this manual, may lead to the following dangers: - Increased temperature rise beyond the safe operating temperature of the pump and as a burning hazard.
Page 8: Vacuum Mode
PIPING TO AND FROM THE PUMP Using a thick walled pipe reduces the ambient noise effect. Clean the inside of the pipes prior to installation to prevent foreign debris from getting inside the pump and causing damage. Don’t create short radius curves. Pipes should be seperately supported, not by the pump.
Page 9: Pressure Mode
PRESSURE MODE Set the adjustment starting for the lower preload and increase it by tightening the regulation nuts up to the desired pressure. COUPLING ALIGNMENT Correct alignment of the pump coupling is absolutely necessary. - Measure the alignment with proper instrumentation - Keep the correct distance between the two coupling faces (see supplier instructions)
Page 10: Base Frame
V-BELT DRIVE TENSIONING h (mm) = t/100 x 1,5 INSTRUCTIONS FOR TRUCk INSTALLATION OF FB VACUUM PUMPS BASE FRAME Please follow these instructions when you install the pump on a truck chassis: First mode The pump has to be installed on a steel frame with machined base to ensure the flatness with the pump base.
Page 11 ( use clogged filter gauge ). Different filtration systems are used depending on the material being moved. Be sure to contact FRUITLAND for the correct filter application.
Page 12 DRIVES The pump is designed to be suitable for all types of drives.. The pump speed should not exceed 3.400 RPM. Couplings and shafts must be perfectly aligned. Always use the proper tools and equipment to install the coupling or sheaves so as not to damage them. Use the correct V-belts designed for the application.
Page 13 STARTING ROTATION AND AIRFLOW DIRECTION The rotation is usually CCR (counter clock-wise rotation) and the flow is as shown below For CR (clock-wise rotation) please specify upon placing an order. Warning! Do not install the pump inclined because this will change the correct oil level in the sumps.
Page 14 STARTING Check the transmission alignment and belt tension Check that the pump shaft rotates by hand and in the correct direction Check that the pump is secure and installed correctly Check that the inside of the pipes have been well cleaned Check that all the pipe connections have been tightened and sealed Check the relief valve set up Open all the pipe valves...
Page 15: Troubleshooting
Before the pump is stopped, run it for a few minutes without pressure or vacuum inside and with valves opened; in this way no humidity condensation will remain inside. With cold temperature this condensation could create ice and problems when the pump is re-started. a small valve (3/8”) may be added to the bottom of the pump to discharge possible condensation.
Page 16 PROBLEM CAUSES SOLUTIONS High discharge Pipes diameter to small Change the pipes pressure Air capacity to high Reduce the RPM Discharge pipe obstructed Remove the obstruction No air flow Speed to low Check speed with data sheet Wrong rotation Change rotation if wrong Pipe obstruction Check piping, valves, silencers for obstruction...
Page 17: Maintenance
Excessive power Speed to high Check speed with rating Pressure to high Check inlet vacuum and discharge pressure with rating Impellers rubbing Check if there is contact Knocking Out of time Check timing Excessive differential pressure Reduce pressure. Check relief valve To high discharge temp Re-set if necessary Worn gears...
Page 18 Pressure reliefe valve Warning FRUITLAND will not be liable for damages or injuries caused by the use of non original spare parts and accessories. FRUITLAND will not be liable for damages or injuries caused by failure to comply with the instructions...
Page 20 PARTS LIST ITEM CODE PART DESCRIPTION NOTES CPO.30017 HOUSING ROT.30021 DRIVE ROTOR ROT.30022 DRIVEN ROTOR ING.21010 GEAR CTR.30005 FRONT COVER FLN.30035 FRONT HEAD PLATE BLA.20023 WEAR BUSH FLN.30036 REAR HEAD PLATE FLN.20039 RETAINER FLANGE CTO.50014 BEARING CTR.30006 REAR COVER CTO.50013 BEARING ATN.80010 SEAL RING...
