Summary of Contents for EVA EVAstream & Piezo
- Page 1 Quick Start Installation Manual EVAstream & Piezo EVAstream & DMX EVA Tech B.V. De Velde 1 8064 PH Zwartsluis Nederland www.evastream.nl...
- Page 2 Safety warnings WARNING! Switch off all relevant live cables before starting installation. RISK OF ELECTRIC SHOCK OR INJURY. The EVAstream and its control accessories must be installed by a certified electrician in accordance with applicable local rules and regulations. Incorrect installation can cause electrical hazards. CAUTION! Carefully read the separately enclosed document “Safety instructions mounting &...
- Page 3 Motor Control Unit | DMX Ready Quick Start Installation Manual EVAstream V21.2...
- Page 4 Piezo Print | Settings Master mode: piezo control Slave mode: external master (EVO) control DMX in/out goes to EVAstream / UWL (underwater lighting) DMX input Rotary = dmx adress 1-511 PPM output 1-2 to EVAstream motor control Piezo/switch 4 = stop (reset) outside pool Piezo 1 + 3 is pauze Rotary (dmx) address 518 = 1 x piezo (1) control in 10% steps + (0, 30, 40, 50, 60, 70, 80, 90, 100) Rotary (dmx) address 601 = 2 x piezo (1+3) piezo 1 = speed +, piezo 3 = speed -, piezo 1+3 = on/standby.
