Assembly instruction for EZ HANG C-FRAME
Assembly
Parts:
a. X-Base of frame. Sits on floor longer legs pointing
toward the back shorter toward the front.
b. Lower crescent section of frame has a "stem"
c. Upper crescent section of frame, chair hangs from this
section from loop on top.
d. 2 additional side support brackets for base
e. Hard ware pack- 6 equal size bolts used to connect extra
side legs. 2 equal sized bolts to connect upper and lower
crescent. 2 unequal sized bolts to connect lower crescent
to base of frame.
1. Insert "stem" of lower crescent section of frame (b) into the
hole of X section (base) (a). Align hole of (a) & (b). Tilting the
frame forward can assist in correctly aligning holes. Connect
the two sections, (a) & (b) using the LONGER BOLT in the
upper hole. This bolt DOES NOT go all the way through as if
you were going to put a nut on the end of it. It butts up against
inner wall of stem of lower crescent section (b). Insert shorter
bolt in second hole below first bolt. You will only see metal
or the stem of section (b). This bolt butts up against outer
wall of stem of section (b).
Advertisement
Table of Contents
Summary of Contents for EZ Hang Chairs C-FRAME
- Page 1 Assembly instruction for EZ HANG C-FRAME Assembly Parts: a. X-Base of frame. Sits on floor longer legs pointing toward the back shorter toward the front. b. Lower crescent section of frame has a “stem” c. Upper crescent section of frame, chair hangs from this section from loop on top.
- Page 2 Always exit frame front to back and NOT sideways. USE CAUTION. Disclaimer Please note: EZ HANG CHAIRS and all agents or representatives thereof cannot assume responsibility for special, indirect, or consequential damages or contingent liability for use of this product in a manner not expressly intended by the manufacturer.
