Summary of Contents for Vanco HD4KTEST
- Page 1 Handheld 4K HDMI® Tester Vanco Part Number: HD4KTEST Technical Support www.vanco1.com • techsupport@vanco1.com • 800-626-6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters. -
Page 3: Package Contents
1080p resolutions, with 16 combinations to help replicate and resolve common issues in the field. Includes a durable and reusable carrying case, the HD4KTEST is a great tool to bring to any job site resulting in less time troubleshooting issues out in the field. -
Page 4: Specifications
SPECIFICATIONS Connections .............. (1) HDMI Input, (1) HDMI Output Video Output ............. 4K@60Hz, 4:4:4; 4K@60Hz, 4:2:0; 4K@30Hz, 4:4:4; 1080p@60Hz Video Input ..............Up to 4K@60hz, 4:4:4 Audio Output ............. PCM/Stereo Audio Input ..............PCM/Stereo Dimension (W*H*D) ........... 3.4” x .87” x .75” (95x22x19 mm) Weight .............. -
Page 5: Panel Descriptions
HDMI source is sending HDCP 2.2, red when it is HDCP 1.4, or off when no HDCP is present 5. POWER: Micro USB port for power, the HD4KTEST must be connected to power when it is used as a... -
Page 6: Connect And Operate
Connect the HDMI output of the HD4KTEST to an HDMI display Adjust the dip switches on the HD4KTEST to the capabilities of the display or the resolution and settings you wish to test (see Dip Switch Table Settings) NOTE: The example above has all dip switches in the down or “0”... - Page 7 Display Emulator (to test a source and/or cabling): Connect HDMI INPUT of the HD4KTEST to an HDMI source Power on the source Connect the provided micro-USB cable to the HD4KTEST for power (optional) Signal LED HD4KTEST LEDs Green Signal Generator...
- Page 8 Dipswitch Setting HDCP Color 0000 0100 HDCP 2.2 1000 1100 0001 0101 HDCP 1.4 Green 1001 1101 0010 0110 Blue 1010 1110 0011 0111 Checkered (Black and White) 1011 1111 1 = ON/UP 0 = OFF/DOWN www.vanco1.com...
- Page 9 The HD4KTEST has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment, the HD4KTEST should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
-
Page 10: Limited Warranty
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco regarding warranty repair or replacement. -
Page 11: Liability Statement
TECHNICAL SUPPORT In case of problems, please contact Vanco Technical Support by dialing 1-800-626-6445. You can also email technical support issues to techsupport@vanco1.com. When calling, please have the Model Number, Serial Number (affixed to the bottom of the unit) and Invoice available for reference during the call. - Page 12 Vanco® International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
