Summary of Contents for PG LifeLink Mark IV
- Page 1 PG L Mark IV Line Isolation Monitor Instruction Manual 02/2017 Revision 1.3...
- Page 2 This product is warranted against defects in materials and workmanship for a period of 2 years from date of purchase. At its option, PG LifeLink will either repair or replace at no charge any returned equipment that proves to be defective during this period, provided that no abuse or damage to the product has occurred, and unit has been properly installed and operated in accordance with this manual.
- Page 3 Mark IV Line Isolation Monitor Instruction Manual 1.Introduction The PG LifeLink Mark IV Line Isolation Monitor is designed to continuously monitor the impedance between the energized parts of an isolated power system and earth ground, and to display the resulting Total Hazard Current (THC). This is the predicted maximum possible current that could flow through an unintended path in the event of a worst-case second fault (a direct short) to ground elsewhere in the system.
- Page 4 If it cannot be immediately installed, store n a clean, dry, climate-controlled location, protected from dust, moisture, construction debris, or other contamination. The PG LifeLink Mark IV LIM is available in two voltage range models: 120V, and 208/240V. Verify that the nameplate of the LIM matches the voltage of the system in which it will be installed.
- Page 5 The LIM mounts using 4 holes in the corners of its front panel. In case of retrofits into existing panels, any additional brackets and harnesses needed are usually sup- plied when a “retrofit kit” is ordered from PG LifeLink for a specific application. Con- sult the factory for assistance.
- Page 6 To help expedite problem resolution, please perform all applicable tests as described in this section before contacting PG LifeLink Technical Support, and be prepared to report on the results.
- Page 7 Disconnect all remotes from the isolated power panel at the terminal board. 6.Maintenance and Service The Mark IV LIM contains no user-serviceable parts. If it requires internal service, contact PG LifeLink Technical Support (see back cover) for a Returned Materials Authorization.
- Page 8 Notes (wire color codes, etc.) PG L 167 Gap Way Erlanger, KY 41018 859-283-5900 800-287-4123 techsupport@pglifelink.com...
