Steel Core 33002 Manual

3" mini multi purpose bench grinder and polisher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3" MINI MULTI PURPOSE BENCH
GRINDER AND POLISHER
This product can expose you to chemicals including
LEAD/CADMIUM/DEHP, which is known to the State
of California to cause cancer and birth defects or
other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
WARNING
*Actual product may vary slightly
33002
12/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 33002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Steel Core 33002

  • Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 33002 12/2017 or e-mail customerservice@focus-ontools.com...

  • Page 2: Specifications

    SPECIFICATIONS Electrical Rating 120VAC / 60Hz / 0.4A Motor No Load Speed 3,600 RPM Arbor Size 1/2" 226002 Mounting holes 3/16" ASSEMBLY ATTACH EYESHIELD 1. Attach Spark Guard (16) above Grinding Wheel using two Screw, Spring Washer and Flat Washer Assemblies (1). Do not tighten Screws. 2.
  • Page 3 MOUNTING Grinder/Buffer securely on a stable work surface or stand using four 3/16″ bolts (sold separately). Mounting Holes (2 more holes on other end) FUNCTIONS Buffing Wheel Shield Grinding Wheel Left ON/OFF Right Switch Work Rest Work Rest customerservice@focus-ontools.com 1-800-348-5004...

  • Page 4: Tool Set Up

    TOOL SET UP TO PREVENT SERIOUS INJURY FROM ACC IDENTAL OPERATION: Turn the Power Switch of the tool off and unplug the tool from its electrical outlet before performing any procedure in this section. Installing a Grinding Wheel INSTALLING A GRINDING WHEEL 1.

  • Page 5: Workpiece And Work Area Set Up

    INSTALLING A BUFFING WHEEL 1. Loosen Screws on Buffing Wheel cover. Screws Twist Grinding Wheel Cover counterclockwise to remove. 2. Hold onto wheel to stop wheel from turning. Turn Nut clockwise to remove. Buffing 3. Remove Outer Flange. Wheel Cover Keep Wheel Bushing (5) and Inner Flange (7) in position on Spindle.

  • Page 6: Cleaning, Maintenance, And Lubrication

    BUFFING 1. Apply the desired polishing compound (coarse or fine) onto the Buffing Wheel. 2. Make sure Switch is in OFF-position, then plug in the tool. 3. Turn on the tool. 4. Using two hands, firmly hold the workpiece and gently move it into contact with the Buffing Wheel.

  • Page 7: Accessory Storage And Handling

    ACCESSORY STORAGE AND HANDLING 1. Handle accessories carefully to prevent dropping or bumping. Do not use wheels that have been dropped or bumped. 2. Store accessories in shelves, racks, boxes, or drawers. Keep storage area dry and above freezing. Any grinding wheels exposed to humidity or freezing temperatures must not be used.

  • Page 8: Parts List

    PARTS LIST Part Description Qty. Part Description Qty. Part Description Qty. Screw, Spring Washer, and Flat Washer Wing Bolt Flat Washer Assembly Buffing Wheel Cover Spark Guard Power Cord Hex Nut Right Work Rest Wire Clamp Outer Flange Eyeshield Base Wheel Bushing Lock Nut Capacitor...
