Summary of Contents for Creone KeEYBOX KEYRACK KEYWIN5

  • Page 1 Installation guide KEYWIN5...
  • Page 2 Creone delivers Keyboxes and Valueboxes to 25 countries in Eu- rope, North America and Central America. Its manufacturing division and headquarters are located in Tranas, Sweden. For more information about Creone and our products, visit www.creone.com. KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...
  • Page 3 Introduction DELIVERY MOUNTING KEYBOX CONFIGURATION MENU WIRING DIAGRAMS KeyControl Strips KeyBox 9500EC Creone RFID reader External reader External alarm KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...
  • Page 4 Delivery...
  • Page 5 Thank you for choosing Creone! We hope that your new Creone product will make your daily key ma- The system should always be installed by an trained Creone dealer. nagement work easier, faster and more secure than before. Read If you have any questions, please feel free to contact us and we will these instructions carefully before you install the system.
  • Page 6 Mounting KeyBox...
  • Page 7 FOLLOW THE INSTRUCTIONS TO GET STARTED: To open the cabinet, use the key provided to open the service door. There you will find an emergency release to open the door of the cabinet. KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...
  • Page 8 Install the cabinet in the selected location. Follow the diagram below. 9400 SC (mm) 9500 SC (mm) : 746 KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...
  • Page 9 Enter IP number/Netmask Gateway. Choose Reboot at the bottom of the menu and confirm. The cabinet will now reboot and when this has taken place confi- guration is complete. KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...

  • Page 10: Configuration Menu

    Configuration Menu...
  • Page 11 Use the up and down arrows to find the correct reader, and confirm the reader using #. To install your RFID reader, see the wiring diagram on page 17 in these instruc- tions. KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...
  • Page 12 Then exit the menu and open the cabinet with the admin code (default 301042#). When you close the door, all keys will return to locked. KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...

  • Page 13: Wiring Diagrams

    Wiring Diagrams...
  • Page 14 Data + Data - 12-15 V Explanation of circuit board parts Battery backup cable SIMCOM Strip cable – First strip in your system (see more on next Connection for RFID reader (see page 15) page) External alarm, 15 V (see page 16) Strip cable –...
  • Page 15 Keycontrol strips Below you can find the wiring diagram for the KeyControl strips below, the system will not start up. Then you must turn off the in your system. Please note that the strip cable from the bottom power, connect the cables as specified below and turn on power to position on the PCB should be connected to the left position on the the unit again.
  • Page 16 Go to “Reboot” and confirm. When the cabinet has started up, the expansion cabinet is ready to use. Connect the solenoid cable and alarm cable according to picture below. Alarm contact Solenoid cable Solenoid cable Alarm contact KeyWin 5 manual, Version 1.0.0. All and copyright reserved by Creone AB...

  • Page 17: Rfid Reader

    RFID reader Data + Data - 12-15 V If the RFID reader not is connected from the factory, follow the instructions below Mount the RFID reader on the service door of the cabinet. swipe your card in front of the reader. If everything is cor- Connect the four cables according to the diagram above.
  • Page 18 External reader Connect the external card reader on 3 and 6. To connect an external card reader/unit, follow the instructions below: Mount the device on or next to the cabinet and connect change to “LOCKED”. The user must now access the the unit according the diagram above on 3 and 6.

  • Page 19: External Alarm

    External Alarm When connecting your KeyBox to an external alarm, you can make another system for increased security. Naturally, these alarms are sure that alarm signals generated by opening the KeyBox without a also registered in KeyWIn5 software. correct PIN and when taking an intellipin without access are sent to Data + Data - 12-15 V...
