Summary of Contents for Keylite Solar Blind
- Page 1 Keylite Blinds Solar Blind Installation...
- Page 2 Check all the components have been supplied Screws (x6) Side Rails (x2) Cassette (x1) Remote control Installation Brackets (x2) Tools Required Check out our installation video on the Keylite website. www.youtube.com/watch?v=itUOxIfmdJo WARNING DO NOT OPERATE REMOTE CONTROL UNTIL THE BLIND HAS BEEN FULLY INSTALLED.
- Page 3 Instructions Remove backing from installation bracket. Position installation bracket and fix with screw. Repeat previous steps 1 and 2 for the right hand side.
- Page 4 Align cassette with installation bracket and push cassette tight to frame. Rotate handle and screw into position. Repeat step 5 for right hand side.
- Page 5 Untie the belts and ensure they are not twisted. Slide tensioner into side rail and slide down the rail as shown (do not click into foot). Insert handle end into side rail and slide into bottom of cassette.
- Page 6 Push the side rail to the bottom of sash and screw into position. Repeat steps 8, 9 & 10 for right hand side. Pull blind to remove slack from belts.
- Page 7 Push tensioners until they click into place. Installation is complete. Use remote control to operate blind.
- Page 8 Blind Operation Blind Operation SINGLE CHANNEL REMOTE CONTROL PAIRING THE REMOTE When using a multichannel remote the channel number the user wishes to use must be selected first on the remote before pairing. OPERATION – Your blind will arrive with the top and bottom stop limits factory set. Open the blind cassette by pressing the 2 buttons on either end of the Close the blind: press and hold the down button on the remote control for cassette to release and rotate forward.
