Wuhan Huazhong Numerical Control HNC-18M Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CENTURY STAR MILLING CNC SYSTEM
HNC-18/19M OPERATOR'S MANUAL
V2.01
Wuhan Huazhong Numerical Control Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HNC-18M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wuhan Huazhong Numerical Control HNC-18M

  • Page 1 CENTURY STAR MILLING CNC SYSTEM HNC-18/19M OPERATOR’S MANUAL V2.01 Wuhan Huazhong Numerical Control Co., Ltd.

  • Page 3: Table Of Contents

    CONTENT PRECAUTIONS ................I 1 INTRODUCTION................1 ................1 VERALL LAYOUT ..............2 ACHINE ONTROL ............. 8 LPHA UMERIC EYBOARD ................... 10 ENU TREE 2 SET UP ..................17 ..................18 OWER ON ............19 ESET MERGENCY – ) ........20 OMING EFERENCE POINT...
  • Page 4 NC.............. 77 PLOAD DATA FILE TO NC ............ 80 OWNLOAD DATA FILE FROM 7 SETTING AND DISPLAYING ............. 83 ..........83 OSITION AND OORDINATES HOICE ................84 PTIONS 8 DIAGNOSIS................88 ................ 89 LARM IAGNOSIS I/O C ..................90 HECK ................

  • Page 5: Precautions

    Precautions This section enumerates safety precautions for protecting the user and preventing damage to the machine. Read the contents of this part thoroughly before attempting to use the machine. The working temperature for the Numerical Control (NC) unit and its cable cabinet is 0 to 45°C (32°F to 113°F). No freezing is allowed.
  • Page 6 machine's status. Before using the machine for a production run, make sure that the machine operates correctly by doing a trial run including, for example, a single block with a feedrate override or a machine lock function. Another possibility is to do the trial run without a tool or workpiece mounted.
  • Page 7 the keys on the Manual Data Input (MDI) panel until the position display or alarm screen appears on the NC unit. Since some of the keys on the MDI panel are dedicated to maintenance or other special operations, pressing any of these keys may prevent the NC unit from entering its normal state.

  • Page 9: Introduction

    HNC-18/19T Operator’s Manual 1 Introduction Overall layout The user operates the mill either through the Numerical Control Unit (NCU) or a Hand Pendant (optional). RS232 allows the user to exchange data between the NCU and other computers. A PS/2 connector in the Data Exchange Port lets the user plug in a keyboard.
  • Page 11 HNC-18/19T Operator’s Manual There are four main areas on the front face of NCU: LCD Screen, Soft keys, Alpha numeric keyboard and Machine Control keys. These are shown in detail below. a) LCD Screen The LCD screen in the upper right displays the machine’s status, the tool’s position, the program’s content and other information.
  • Page 13 HNC-18/19T Operator’s Manual Alpha Numerical keys Function keys d) Machine Control keys At the bottom of the front panel are the Machine Control keys. These keys operate the machine directly. e) Other Controls An emergency stop button is on the front panel to deal with abnormal situations.

  • Page 15: Overall Layout

    HNC-18/19T Operator’s Manual A green “Cycle Run” button starts the automatic machining process. A red “Feed Hold” button pauses machining under computer control.

  • Page 16: Machine Control Keys

    1 Introduction Machine Control Keys a) Mode Selection Switches. To the right are shown the five switches that select the operation mode of the machine. Note that the small LED “activation” light on the upper left of each key indicates in which mode the machine is working.
  • Page 17 HNC-18/19T Operator’s Manual b) Multiple Step Keys: Shown on the right are the four multiple step selection keys used during incremental operation. Again, the LED light on the key’s upper-left corner indicates the corresponding multiple selected. First the INC key is pushed to set the Incremental Mode, then the desired number of multiple steps is pressed and finally the desired Axis key is pressed.
  • Page 18 1 Introduction c) Spindle and Auxiliary Operation keys: These nine keys usually function in Manual mode. They control spindle, turret tool selection, coolant and chuck functions. These functions are activated only when no program is running. Details of the keys are shown below: Coolant Switch key: This key opens or closes the coolant flow Lubrication key: Turn on the lubrication system...
  • Page 19 HNC-18/19T Operator’s Manual d) Speed Adjustment keys: By pressing these keys the spindle speed, rapid traverse rate feed rate (machining speed) can be adjusted. The first row controls the spindle speed, the second row controls the rapid traverse speed and the bottom row controls feed rate.
  • Page 20 1 Introduction Axis Operation keys: These five keys select 1) the desired axis and 2) the direction of motion in various modes. These keys only function in Manual Mode, INC Mode and Reference Mode. The LED light in the upper-left corner specifies which axis or direction is selected. DESCRIPTION In INC mode or Manual Mode, the tool moves the X axis in the positive direction while +X is pressed...
  • Page 21 HNC-18/19T Operator’s Manual f) Other keys: The five keys below are other keys that control various machining functions. DESCRIPTION Servo enable key: Press this key to enable or disable the servo. Activating this Block Bypass key: bypasses program blocks that start with a “/” character Activating this key Program Stop key:...

  • Page 22: Alpha Numeric Keyboard

    1 Introduction Alpha Numeric Keyboard The Alpha Numeric keyboard lets the operator input either letters or numbers for programs, parameters or conversational commands. DESCRIPTION Backspace key deletes the Delete keys character in front of the cursor Delete key deletes the character at the cursor There are two kinds of page change keys:...
  • Page 23 HNC-18/19T Operator’s Manual The Shift Up key toggles the status of double-character keys in the Alpha Numeric keyboard. The LED light in the upper-left corner indicates whether the upper character is selected. When Shift Up key the LED light is on, the upper character selected, otherwise lower...

  • Page 24: Menu Tree

    1 Introduction Menu tree For HNC-18/19 CNC system, there are seven function keys below the alpha numeric keyboard that bahave as seven different function keys. They are: DESCRIPTION PROGRAM submenu key: Press this key to do operations related with program such as open, edit or test a part program.
  • Page 25 HNC-18/19T Operator’s Manual There are six soft keys to navigate each of the above key. The functions of the soft keys change according to which function key is active. Each function is corresponding to one submenu. Let’s go through the seven submenus one by one.
  • Page 26 1 Introduction BP, means breakpoint operation, has three submenus, SAVE BP(Save the break point information to a file), LOAD BP(Load the break point information from a file) and BACK(Back to OPEN function menus). DNC, enable the NC to receive program from a computer. F2, corresponding to EDIT, allows the user to do edit operation and some running process control operation.
  • Page 27 HNC-18/19T Operator’s Manual submenus: X RST, resets the X position of RCS’s origin. Y RST, resets the Y position of RCS’s origin. Z RST, resets the Z position of RCS’s origin. F3, corresponding to HPI(Home position input), also has three submenus: X HPI, resets the X position of home point.
  • Page 28 1 Introduction F2, corresponding to DIA Comp, used for the user to input the tool’s diameter compensation value. e) DIAGNOSIS SUBMENU I/O (F1) REG. (F2) MSG(F3) ABT(F5) NEW JOB (F3) RST JOB (F4) JOB NOTE (F6) BACK (F6) The key “DGN” has five submenus. F1, corresponding to IO, displays the status of I/O points.
  • Page 29 HNC-18/19T Operator’s Manual f) POSITION SUBMENU MCS (F1) WCS (F2) (F3) TEXT (F4) GRPH (F5) GRPH PARM (F6) The key “POS” has six submenus. F1, corresponding to MCS, displays machine coordinate system. F2, corresponding to WCS, displays workpiece coordinates system. F3, corresponding to ALL, displays overall information of the axes.
  • Page 30 1 Introduction The key “PAR” has five submenus. F1, corresponding to BACK PARM, makes a backup parameters. F2, corresponding to LOAD PARM, loads a saved parameter file. F3, DNC PARM, used to set the DNC parameters. F4, PASSWORD, inputs the password to access the parameters. F5, corresponding to BACK PLC, backs up the PLC program.

  • Page 31: Set Up

    HNC-18/19T Operator’s Manual 2 Set up Before machining a part, the operator needs to set up the machine coordinates, the work piece coordinates, define tools parameters and other machine preparations. The general setup procedure includes six steps: (1) Power On (2) Reset (3) Reference home (point approach) (4) Define software limits...

  • Page 32: Power On

    2 Set up Power on Sequence: a) Check and make sure the machine is safe to run. b) Press down the Emergency Stop button on the machine’s front control panel. c) Turn on the power supply of the machine (usually located in back of the machine and/or beneath the control panel).

  • Page 33: Reset/ Emergency Stop

    HNC-18/19T Operator’s Manual Reset/ Emergency Stop Reset After Power On, reset the control button unit by twisting the Reset Button on the front face clock-wise, resetting servo and spindle power to enable the machine to run. Pushing the RESET button down generates an Emergency stop event and disables the servo and Turn...

  • Page 34: Homing (Reference-Point Approach)

    2 Set up Homing (Reference–point Approach) In homing (sometimes called reference point approach), there is a reference point for each axis. These reference points are used to set up the machine’s coordinate system. Homing should always be performed each time the machine is powered on. By homing each time the machine is powered on, the axis’...
  • Page 35 HNC-18/19T Operator’s Manual For proper homing, the direction for reference point approach must first be defined for each axis. This setup is done once only.5). The button sequence for homing is as follows. First switch the mode to Home mode by pushing the Home key on the control panel. Next, press “+X”...

  • Page 36: Software Limits Definition

    2 Set up Software limits definition Each axis has a hardware limit and a software limit on each end of the axis. In the figure below, the hardware switches (shown in black) are at the extreme left and right of the axis. Software switches (shown in white) are interior to the hardware switches.
  • Page 37 HNC-18/19T Operator’s Manual If the tool goes beyond the software limit, the hardware limit switch is encountered. This can occur if the software switches are not set properly of if the tool is moving too fast to stop when the software limit is reached.

  • Page 38: Tool Data Setting

    2 Set up Tool data setting There are three kinds of tool data, length compensation value, radious compensation value and life expectancy. To access the tool data, click OFT from the function keys of the alpha numeric keyboard to get to the Offset Data screen: Here, the tool data input windows displayed.
  • Page 39 HNC-18/19T Operator’s Manual Sequence to set tool diameter compensation: a) Press F2 (corresponding to DIA Comp) under OFT function. b) Move the cursor to the tool’s row with ▲or ▼. c) Press “Enter” to make the tool’s diameter editable. d) Enter the tool’s diameter compensation value. e) Press “Enter”...
  • Page 40 2 Set up Sequence to set tool life expectancy: a) Press under OFT function to move the cursor to tool’s life ► column. b) Move the cursor to the tool’s row with ▲or ▼. c) Press “Enter” to make the tool’s life editable. d) Enter the tool’s life expectancy value.

  • Page 41: Origin Offset

    HNC-18/19T Operator’s Manual Origin Offset Usually workpiece coordinates system (WCS) instead machine coordinates system(MCS) are used to simplify programming. User can define 6 workpiece coordinates with G54~G59. To use these 6 workpiece coordinates, user need to define the offset of their origin to machine coordinates’...
  • Page 42 2 Set up c) Press PgUp or PgDw button on the alpha numerical keyboard to browse the six WCS offsets (origin position of G54~G59) and RCS offset. d) Input the offset value on the command row. For example, if the offset of G54 is 100 and 100, type in “X100 Z100”...

  • Page 43: Manual Operation

    HNC-18/19T Operator’s Manual 3 MANUAL OPERATION Manual Operation (MAN) uses various input devices to carry out operations much like those of a manual mill. While the internal computer is actually controlling the machine tool during these operations, they are familiar to an operator that has machined parts on a manual mill.

  • Page 44: Jog Feed

    3 MANUAL OPERATION Jog Feed JOG feed is used to move the cutting tool along a motion axis. The motion continues as long as the axis key is pressed. In JOG, pressing a feed axis with its direction on the machine control panel continuously moves the tool along the selected axis in the selected direction.
  • Page 45 HNC-18/19T Operator’s Manual JOG mode LED indicator light JOG mode key After pressing the JOG mode button, the LED indicator light on that key lights to verify that you are in the JOG mode. Press one of the feed axis keys: +X, -X, +Y, -Y, +Z JOG feedrate: or -Z.
  • Page 46 3 MANUAL OPERATION corner of the 100% key specifies that the feedrate is set to full value (i.e., 1/3 the rapid traverse value for factory default). Note the feedrate icon that tells that the JOG feedrate is being adjusted: LED light shows when feedrate is 100% of full value Feedrate icon...
  • Page 47 HNC-18/19T Operator’s Manual Rapid Traverse feedrate: The icon for the Rapid Traverse key is The Rapid Traverse feedrate moves the cutting tool at the Rapid Traverse rate. As explained above (see Adjusting JOG feedrate above), the Rapid Traverse speed is the maximum feedrate on each axis that the machine can move.
  • Page 48 3 MANUAL OPERATION Adjust Rapid Traverse speed: The rapid jog feedrate can be adjusted with the rapid traverse feedrate override keys. Decrease the Rapid Traverse speed by 2%. Increase the Rapid Traverse speed by 2%. Set the Rapid Traverse speed to its full value—1/3 of the axis’s rapid traverse speed.

  • Page 49: Incremental Feed

    HNC-18/19T Operator’s Manual Incremental Feed INC feed is used to move an axis a fixed increment of travel. Pressing a key in incremental or INC mode, moves the cutting tool one increment in that axis and direction. When in INC mode, the cutting tool moves at the JOG feedrate (See JOG Feed Functions above for adjusting the JOG feedrate).
  • Page 50 3 MANUAL OPERATION INC mode LED indicator light INC mode key For each press of the feed axis keys: +X, -X, +Y, -Y, +Z or -Z, the tool cutter moves a certain distance. To move the cutting tool toward the workpiece use a minus key (-X, -Y, -Z). For moving the cutting tool away from the workpiece use a plus key (+X, +Y, +Z).
  • Page 51 HNC-18/19T Operator’s Manual The distance is the number of minimum steps times the magnifier value. The four keys below select the step length magnification in the INC mode. Pressing any key changes the magnification of the corresponding distance. As before, the LED light associated with the selection lights up indicating which magnification is chosen.
  • Page 52 3 MANUAL OPERATION For example, this key moves the X axis one step in the plus direction (away from the workpiece) This key moves the X axis one step in the minus direction (toward the workpiece)

  • Page 53: Manual Handwheel

    HNC-18/19T Operator’s Manual Manual Handwheel In the handwheel mode, the cutting tool can be moved small amounts by rotating the handwheel on the handwheel unit. During part setup with the handwheel, the operator can adjust the cutting tool from closer to the workpiece than from the front panel. There are two selection switches on the handwheel unit.
  • Page 54 3 MANUAL OPERATION INC mode LED indicator light INC mode key Once in INC mode, the handwheel unit is activated by turning the Axis Selection knob from the OFF position to one of the mill's axes. Axis selection/ OFF knob: The left knob on the Handwheel unit is the Axis Selection/ OFF knob.
  • Page 55 HNC-18/19T Operator’s Manual X1: No magnification; each click of the handwheel moves one minimum step. X10: Each click of the handwheel moves ten minimum steps. X100: Each click of the handwheel moves a hundred minimum steps. X1000: Each click of the handwheel moves a thousand minimum steps.

  • Page 56: Spindle Operations

    3 MANUAL OPERATION Spindle Operations The middle keys of the Manual Control Panel (MCP) area of the front panel manually operate the spindle and other common auxiliary devices. Spindle Control Keys The spindle is the most important of these keys since no cutting takes place unless the spindle is rotating.
  • Page 57 HNC-18/19T Operator’s Manual Spindle keys Requirements: The machine is in JOG mode. If not, switch to JOG mode by pressing the INC mode key in the Machine Control Panel (MCP) key area on the bottom of the front panel. The icon for the JOG mode is JOG mode LED indicator light JOG mode key...
  • Page 58 3 MANUAL OPERATION RUN SPINDLE CW: Rotate the spindle in clockwise direction. The LED is lit if the spindle is running. STOP SPINDLE: Stop the spindle manually. RUN SPINDLE CCW: Rotate the spindle in counter-clockwise direction. The LED is lit if the spindle is running.

  • Page 59: Auxiliary Operations

    HNC-18/19T Operator’s Manual Auxiliary Operations The middle keys of the Manual Control Panel (MCP) area of the front panel manually operate the auxiliary devices: Coolant, Lubrication, Turret and Chuck functions. Auxiliary Function keys Auxiliary keys: Requirements: The machine must be in JOG mode. If not, switch to JOG mode by pressing on the JOG key in the Machine Control Panel (MCP) key area on the bottom of the front panel.
  • Page 60 3 MANUAL OPERATION Auxiliary Operation: The five keys shown below control auxiliary operation. The upper left key turns coolant flow on while the other two upper keys rotate the tool changer clockwise (CW) and counter-clockwise (CCW). The bottom two keys control the chuck: the right key clamps the chuck and the left key selects the chuck.

  • Page 61: Automatic Operation

    HNC-18/19T Operator’s Manual 4 AUTOMATIC OPERATION Automatic (AUTO) operation is used to machine parts under program control. In an NC machine tool, most production machining is done as an AUTO operation. In Automatic mode, you can execute part programs fully automatically. If you are a manual mill operator, it is the AUTO operations that will be most unfamiliar to you.
  • Page 62 HNC-18/19T Operator’s Manual After pressing the physical key, the softkey descriptions will change to bring in functions only available when the physical key is pressed. Requirements: 1. The mill has already been homed. That is, the “Reference Point Approach” procedure has been completed. 2.

  • Page 63: Program Loading

    HNC-18/19T Operator’s Manual Program Loading A program file must be “loaded” into the mill’s memory before it can be “executed” (i.e., cut a part or do some other operation automatically). The program file itself is a series of program lines called blocks that direct the mill through a series of various operations automatically.
  • Page 64 HNC-18/19T Operator’s Manual Now press the F1 physical key, which correspond to OPEN softkey. F1 OPEN softkey 3) On pressing the OPEN softkey, the LCD screen shows a file directory: a list of program files like the ones below. The left column shows the name of the program file, the middle column shows the size of the file and the rightmost file shows the last date the file was changed.

  • Page 65: Program Testing

    HNC-18/19T Operator’s Manual Program Testing A program which has just been created or changed should be tested or tested before it is actually used to cut parts. Program verifying can find errors in the program without actually running the machine and possibly damaging the mill or the workpiece.
  • Page 66 4 AUTOMATIC OPERATION Note that there is no motion of the cutter or any other action that takes place. The TEST process is a simulation of the motion or action that would take place.

  • Page 67: Running Control

    HNC-18/19T Operator’s Manual Running Control Once tested successfully, the program can be confirmed by executing automatically with AUTO mode or by stepping through each block of the program in the SBL mode (Single Block mode) This confirmation is important on new or recently modified programs to be sure the cutting tool does not run into fixtures and that the feeds and speeds are properly set.
  • Page 68 4 AUTOMATIC OPERATION Beside these four softkey functions, there are two hard key functions to control the running process. Totally there are eight different operations to control the running process: Cycle Run: cycles through the program Feed Hold: stopping the motion of the program with a softkey press begin the program operation again after a pause Restart:...
  • Page 69 HNC-18/19T Operator’s Manual This function begins program execution. Cycle Run: Requirements: 1) The program has been successfully tested. 2) The machine is in Single Block (SBL) mode or Automatic (AUTO) mode. Sequence: 1) Press the green Cycle Run button and the program will be executed.
  • Page 70 4 AUTOMATIC OPERATION 2) After the Feedhold button is pressed, you can stop all action by pressing the Emergency Stop button. If you just want to exit the program, cancel it with the PAUSE operation below. If the program has been canceled, it can be restarted Restart: from the program beginning by pressing the REW(REWind) softkey.

  • Page 71: Break Point Operation

    HNC-18/19T Operator’s Manual Break point operation For complex or large parts, more than one day may be required to finish machining. You may need to power off the machine before it’s done. In this case, the mill’s memory should store the current block location and recover from this location to continue machining later.
  • Page 72 4 AUTOMATIC OPERATION User can rename the breakpoint information file here Here we adopt the default name “OTEST1” perhaps naming the part number being machined Press Enter to confirm the operation. The mill will store the current status information to the typed file. B.P.
  • Page 73 HNC-18/19T Operator’s Manual Break point file Date last saved Size in Kilobytes B.P. LOAD softkey 3) After pressing the B.P. LOAD softkey, a table of break point files is displayed. The first column is the name of the file, the second is the size of the file in Kilobytes and the last column is the date on which the break point file was last saved.
  • Page 74 4 AUTOMATIC OPERATION B.P. Recovery If there have been ANY manual operations of the mill or if the mill power has been turned off, you must move the tool back to where it was before the break point in order to run the machine again using the break point file.
  • Page 75 HNC-18/19T Operator’s Manual ALIGN TOOL Another use of break points is when the cutter gets dull and the mill must be stopped to change cutters. To install a new cutter you first stop the mill and B.P. SAVE before you remove the old cutter.

  • Page 76: Mdi Operation

    4 AUTOMATIC OPERATION MDI Operation The Manual Data Input (MDI) mode is used to set mill data values and operations without using a program. G-codes, M-codes and T-codes can all be entered manually through the keyboard. The MDI mode is useful not only for break point recovery as was done above Sequence: 1) From main function keys, press MDI and the mill will...
  • Page 77 HNC-18/19T Operator’s Manual 3) Input one or several commands representing one block of data on the MDI RUN command input line. In this example, the manually input G-code commands will set the mill for linear interpolation (G01), set the X position from zero to 100 (X100), and set the feedrate from 500 to 1000 (F1000).

  • Page 79: Program Operation

    HNC-18/19T Operator’s Manual 5 PROGRAM OPERATION Operator can create new Program and modify existed programs stored in CF. On how to write a new program, please refer to the PROGRAM MANUAL. Besides program file operations such as create, delete and rename a file, editing and testing functions are also grouped as program functions under PRG function.

  • Page 80: Open A Program

    5 PROGRAM OPERATION Open a program Before machining a part, or editing an existed part program, you need to load the program to the memory. This operation is realized by OPEN. Sequence: 1) From PRG’s submenu menu, press F1, which is corresponding to OPEN in the submenu.

  • Page 81: Create A New File

    HNC-18/19T Operator’s Manual Create a new file Usually, the user need to machine a new part. This request the user to write the part program and type the code to the program memory. And the program is different from the existed ones, so the user need to create a new program file to store the new part program.
  • Page 82 5 PROGRAM OPERATION 6) Once finished editing, just Press F4 and Enter to save it.

  • Page 83: Delete An Existed File

    HNC-18/19T Operator’s Manual Delete an existed file Some time it is necessary to delete some useless files on the CF to save some disk space for new program file. In this case, the operator need to delete an existed file from the program list.

  • Page 84: Edit A Program File

    5 PROGRAM OPERATION Edit a program file This part describes how to edit a program in the CNC. Program edit operation involves editing, deleting, finding and replacing characters in a program file. User can either edit an existed program file or create a new one and then edit it.
  • Page 85 HNC-18/19T Operator’s Manual These keys are: Name Explanation Delete a char that behind the cursor, Delete while the cursor holding still and the other chars which behind it left move a char position; Delete a char that before the cursor, while the cursor and the other chars which behind it left move a char position;...

  • Page 86: Program Format

    5 PROGRAM OPERATION Program format A program must have its start symbol and end symbol. The start symbol should be “%” or “O”. Following by a program number. The end symbol should be M02 or M30. Characters after “;” or between “(” and “)” are interpreted as comments.

  • Page 87: Data Exchange Via Rs232

    HNC-18/19T Operator’s Manual 6 DATA EXCHANGE VIA RS232 For simple program, user can edit it with the alpha numerical keyboard on the NCU’s front face. For complex program that may generated from CAM software, RS232 is usually used to upload the program to HNC-18/19 from a desktop computer.

  • Page 88: Configuration

    6 DATA EXCHANGE VIA RS232 Configuration The baudrate and port number must be same between the computer and the NC system to ensure the communication between a computer and the NC system. The sequence to check and set the parameters for RS232 at the NC system is as following: 1 Enter into SETTING submenu Press PAR to enter...
  • Page 89 HNC-18/19T Operator’s Manual Type in port Type in number baudrate here value here 3 Type in the port number and baudrate as the above figure illustrated. And confirm by “ENTER”.

  • Page 90: Set Up The Rs232 Connection

    6 DATA EXCHANGE VIA RS232 Set up the RS232 connection To set up the RS232 connection at the NC system’s end, you need to get into the “PROGRAM” submenu. Press F6 [DNC] Here, Press F3, which is corresponding to DNC” to let the NC system be waiting for a connection message from the computer.

  • Page 91: Upload Data File To Nc

    HNC-18/19T Operator’s Manual Upload data file to NC With RS232, the user can upload data file such as G code program file, PLC program or parameter file from the computer to the NC system. Here is an example on how to upload a G code file to the NC system from a desktop computer.
  • Page 92 6 DATA EXCHANGE VIA RS232 4 Click the button, an “OPEN FILE” dialog will pop 5 Select the G code file you want to send and double click it. The file will be uploaded to the NC system. At the NC system’s end, the interface would looks like this:...
  • Page 93 HNC-18/19T Operator’s Manual While at the computer’s end, the “SEND button would turn gray. The file’s name This button displayed turns gray here Data bytes been sent out 6 Once the uploading process is finished. Words at the NC system would tell you how many bytes have been received and how many files have been accepted.

  • Page 94: Download Data File From Nc

    6 DATA EXCHANGE VIA RS232 Download data file from NC When more than one machine tools of the same model are to equipped with the same kind of controller, it would be convenient to do configuration and calibration only on one machine, and clone the parameters to others.
  • Page 95 HNC-18/19T Operator’s Manual 3 In the pooped up directory dialog, choose the directory where the parameters are to be downloaded in. 4 Double click the selected directory, the transferring process will begin. At the end of NC, the interface will looks like this: The parameter file’s number...
  • Page 96 6 DATA EXCHANGE VIA RS232 5 When the downloading process is finished, the interface at the NC will be ready for next connection. And at the computer’s side, it will prompts that the receiving process has been finished and the file size will be printed out.

  • Page 97: Setting And Displaying

    HNC-18/19T Operator’s Manual 7 SETTING AND DISPLAYING Machine tool’s status is changing dynamically during operation, user can select the certain information to focus or choose his favorite visualization style. There are four kinds of information can be displayed to show the machining progress: graphical figure, numerical figure, overall positions and G code.

  • Page 98: View Options

    7 SETTING AND DISPLAYING View Options Four kinds of information contents are available for choosing to be displayed in the center of LCD screen. They are graphical figure, numerical figure, overall positions and G code. Press F9 to switch among these four options. The default view is numerical figure.
  • Page 99 HNC-18/19T Operator’s Manual Overall positions figure: Press F3[All] to have an overall displaying of the X and Z positions There are four types of positions displayed in the overall option: MCS: position in machine coordinates WCS: Tool’s position in workpiece coordinates RCS: Tool’s position in relative coordinates Left to go: Left distance to go of the current block Sometime it is helpful to know which block is going on during testing...
  • Page 100 7 SETTING AND DISPLAYING Press F4[TEXT] to display G code on the screen When the G code is selected to be displayed, other useful information are also displayed: WCS: Tool’s position in workpiece coordinates Left to go: Left distance to go of the current block M/S/T/F: The M code/S code/T code and the current feedrate.Graphic figure, presents a the toolpath in 2D graphic realtime.
  • Page 101 HNC-18/19T Operator’s Manual To display the graphic figure in right way, workpiece size should be defined. From Setting and displaying menu, press F6 to set the right workpiece size. Press F6[GRAPH] to set graphic parameters There are three parameters to define the offset value of the workpiece display position: X: Offset value on x.

  • Page 102: Diagnosis

    8 DIAGNOSIS 8 DIAGNOSIS Sometime the machine may not work because of some fault, the system provide some tools to do diagnosis. Diagnosis tools are available when “DGN” is pressed. Press DGN to enter into DIAGNOSIS submenu The first three submenus are commonly used for diagnosis. These three are usually used for DIAGONOSIS...

  • Page 103: Alarm Diagnosis

    HNC-18/19T Operator’s Manual Alarm Diagnosis When a fault occurs, the CNC system will give an alarm message. User can read these message to analyze the reason of the fault. When an alarm occurs, the user can use diagnosis function to check what is wrong.

  • Page 104: I/O Check

    8 DIAGNOSIS I/O Check Some of the faults are related with I/O, such as there is no input signal from the machine because of a bad wire connection. The user can check the I/O status, registers status to make out what is wrong. Y: Output X: Input nodes...

  • Page 105: Registers Watch

    HNC-18/19T Operator’s Manual Registers watch Besides “X” and “Y” registers, other five kinds of registers are also used in PLC programming. They are: “G” registers, control word from PLC to CNC, “F” registers, status words of CNC to PLC “R” registers, intermediate registers used in PLC program, “B”...
  • Page 106 8 DIAGNOSIS For each type of the registers, more than one page are needed to display them all. are used to browse all the items of a kind of register. For “X” and “Y” registers, there are two kinds of digital forms to display the register value.

  • Page 107: Parameters

    HNC-18/19T Operator’s Manual 9 PARAMETERS User can check or modify the parameters. Passwords are used to protect the parameters from being changed unauthorized. Different parameters can be accessed With different passwords. Press PAR to access parameters submenu To access parameters, the user need to press PAR function key to enter into the PARAMETER submenus.
  • Page 108 9 PARAMETERS The words at the upper right corner indicates which group of the parameters are displayed at the current interface. The “List” column is the parameter’s index in this group. The “parameter” column is the value. Below the four column’s data is the description of the parameter in focus.

  • Page 109: Parameters Browsing

    HNC-18/19T Operator’s Manual Parameters browsing Parameters are categorized into 11 groups: MAC. PRM, Machine tools parameters Axis PRM axis 0, parameters for X axis Axis PRM axis 1, parameters for Y axis (not used for mill) Axis PRM axis 2, parameters for Z axis S.

  • Page 110: Parameters Operation

    9 PARAMETERS Parameters operation Edit parameters To edit a certain parameter, the user need to input the correct password. If the password is wrong or the privilege is lower, modification of the password is not allowed. Area to type in the password Press F4 [PASSWORD] to input the...
  • Page 111 HNC-18/19T Operator’s Manual Back up parameter file If the user want to make a backup for the current parameters, he can use the “BAK PRM” function if he has given the right password. Area to type in the backup file’s name Press F1 [BACK PARM] to backup parameters Sequence:...
  • Page 112 9 PARAMETERS Load a previous parameters A suggestion before changing parameter is to make a backup file first as illustrated above. Then if the machine does not work after changes, you can reload the previous working parameters. Following is the steps on how to load a previous parameters file. a) Press F2 [LOAD PRM.] to load a previous parameter backup file.

  • Page 113: Parameters Description

    HNC-18/19T Operator’s Manual Parameters description Machine parameters Turret direction(0/1) 0: positive direction of X axes in graphic displaying is downward. 1: positive direction of X axes in graphic displaying is upward. Diameter/Radius at X(1/0) 0: dimension along X axes is given as radius 1: dimension along X axes is given as diameter Metric/Inches(1/0) 0: unit of dimension is thousandth of an inch...
  • Page 114 9 PARAMETERS Part number of the spindle encoder.
  • Page 115 HNC-18/19T Operator’s Manual Axis parameters Pulse/um(um) Movement distance of the axis per revolution of the motor. The unit is um for linear axis, a thousandth of 1° for rotational axis. Pulse/um(pulse) Encode counter per revolution of the motor. Note: this two numbers can be common divided to prime numbers.
  • Page 116 9 PARAMETERS Offset distance after find the encoder’s zero position. Rapid traverse speed for reference approach Speed before touch the reference switch. Slow speed for reference approach(mm/m) Speed used to find the encoder’s zero position after touch the reference switch Deceleration distance for G60 Distance between the deceleration point and the command position while use G60 to do uni-direction...
  • Page 117 HNC-18/19T Operator’s Manual Servo parameters Feedback to NC(45:YES,46:NO) 45: Encoder counter is feedback to NC. This is always true if servo driver is used. 46: No encoder or no position feedback to NC. This is always true if stepper motor is used. Servo part number.
  • Page 118 9 PARAMETERS Tracking error threshold. Alarm will be displayed if the actual tracking supersede this value. Pulse per revolution Pulse counter value the NC get per revolution of the motor.
  • Page 119 HNC-18/19T Operator’s Manual Axis Compensation parameters Backlash(um) This value should be calibrated by measurement instrument. The unit is 0.001mm. It should be set as 0 if bi-directional pitch compensation is used. Pitch err. comp. type(1:uni-dir,2:bi-dir) Pitch error compensation type. 1: Compensate the pitch error in one direction. 2: Compensation the pitch error in two directions.
