Christie Modular Series Product And Assembly Manual

Cabinet single, double and triple
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Single, Double and Triple
Product and Assembly Manual
Product numbers 1506, 1511 and 1519
+61 3 9708 2999
dachristie.com
Modular Series Cabinet
Please read all relevant parts of
this document carefully before
commencing product assembly.
Product and Assembly Manual 6868_00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Modular Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Christie Modular Series

  • Page 1 Modular Series Cabinet Single, Double and Triple Product and Assembly Manual Product numbers 1506, 1511 and 1519 Please read all relevant parts of this document carefully before commencing product assembly. +61 3 9708 2999 dachristie.com Product and Assembly Manual 6868_00...

  • Page 2: Table Of Contents

    Figure 27, 28, 29, 30, 31, 32, 33 OPTIONS AND ACCESSORIES CLEANING AND MAINTENANCE Safety considerations Environmental considerations Cleaning and general maintenance Cleaning waste containers | Figure 34 WARRANTY Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 3: General Information

    General information | Installation and User Manual 6820_00...

  • Page 4: Safety Instructions

    “Should’ and “should not” are advisory instructions The following icon is used throughout the manual Warning or Caution icons warn how to prevent personal injury and product damage Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 5: Manufacturer's Liability

    (2019) Australian and European directives • When disposing of the product, please remove and deliver the metal components to an appropriate recycling facility • Christie appliances are packaged in non-polluting and recyclable materials. Please recycle according to local regulations Installation and User Manual 6820_00...

  • Page 6: Specifications

    | Specifications SPECIFICATIONS Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 7: Siting Guidelines

    The Christie Modular Series barbecue cabinets are constructed from extruded aluminium, compressed fibre cement, and stainless steel for ultimate durability and corrosion resistance. Christie Modular Series cabinets include a range of options. The modular nature of the product allows for the inclusion of various doors, dividers, sinks and cooktop combinations.
  • Page 8 | Single cabinet assembly and installation MODULAR SINGLE CABINET assembly and installation (For Modular Series Double Cabinet installation, see Section 4) Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 9 Single cabinet assembly and installation | 3.1 Single Cabinet - dimensions Dimensions: 1000 mm width x 750 mm depth x 900 mm height Weight: 100 kg (without cooktop) Cooktop cut-out: 495 mm x 495 mm 1000 mm FIG. 1 692 mm FRONT 750 mm 692 mm...

  • Page 10: Single Cabinet - Services And Footings | Figure

    Position the gas or electric services relative to the preferred location and orientation of the cooktop 692 mm FIG. 2 ANCHOR POINTS (8) 60 mm 430 mm 60 mm 550 mm Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 11 Terminate services for standard cabinet configurations in the locations indicated below. These locations will differ, depending on whether gas or electric cooktops are installed. For Christie CC2 Gas Barbecue Cooktop: • The gas inlet is on the right-hand side when facing the front of the cooktop •...

  • Page 12: Single Cabinet - Boxed Contents And Parts Identification | Figure

    11. (2) x Access door keys (supplied attached to access door) – (Not shown) 12. (23) x M4 Self tapping screws (Not shown) 13. Installation and User Manual Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 13 STEP 1 Open the carton and review the boxed contents section relevant to your product model. Check that all listed parts are present. Contact Christie immediately if you notice any discrepancies. STEP 2 Open the benchtop carton and unpack the channel frames by removing all 6 mm retaining nuts (and washers) with a 10 mm spanner.
  • Page 14 Assemble the channel frames and corner posts. Secure the top channel frame using (16) x 10G self tapping screws. Note: Do not fix the bottom channel frame until Step 8. FIG. 5 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 15 Single cabinet assembly and installation | 3.4 Assembly and installation STEP 4 The cabinet frame must be turned over before fixing. Do not locate fixings where the access door is located. The bolt head will prevent the door from seating correctly into the frame. Roll the cabinet frame over so that the fixed channel frame is on the ground.
  • Page 16 Note: Stainless steel panels will have a protective film on the outer surface. Peel back the protective film slightly along each long edge before installing. FIG. 7 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 17 Single cabinet assembly and installation | 3.4 Assembly and installation STEP 6 WARNING: Services must only be connected by a suitably qualified person i.e. electrician or gas fitter. If your installation has 240v Power outlets (GPO’s), install these now. Complete the gas provisioning (if required).
  • Page 18 Replace the top channel frame. Secure the channel frame using (16) x 10G self tapping screws. Note: A rubber mallet may assist in getting the frame to seat correctly FIG. 9 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 19 Single cabinet assembly and installation | 3.4 Assembly and installation STEP 9 Remove the benchtop from the carton and gently lower it onto the cabinet. Ensure that the locating tabs on the underside of the benchtop slide into the corresponding slots in the channel frame.
  • Page 20 Use the silicone provided to seal the gap between the outside of the panels and the frame. This will secure the panels and prevent them from rattling. Installation of your Modular Series Cabinet is now complete. Please consult the relevant installation instructions for any additional items, such as the barbecue cooktop.
  • Page 21 Double cabinet assembly and installation | MODULAR DOUBLE CABINET assembly and installation (For Modular Series Triple Cabinet installation, see Section 5) Installation and User Manual 6820_00...
  • Page 22 Dimensions: 1390 mm width x 750 mm depth x 900 mm height Weight: 146.5 kg (without cooktop) Cooktop cut-out: 495 mm x 495 mm 1390 mm FIG. 12 1334 mm FRONT 750 mm 692 mm SIDE REAR Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 23 Double cabinet assembly and installation | 4.2 Double Cabinet - services and footings WARNING: All work on underground services must be carried out by suitably qualified trades people i.e. electricians or gas fitters. Footings and underground services: • Bring up underground services (electrical conduits, gas and water pipes and waste outlets) in the highlighted areas only •...

  • Page 24: Double Cabinet - Services And Footings | Figure

    The 1m electric cable with plug terminates into the left-hand side when facing the front of the cooktop • Position the 15A electrical socket (GPO) at least 600 mm above ground FIG. 14 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 25: Double Cabinet - Boxed Contents And Parts Identification | Figure

    Double cabinet assembly and installation | 4.3 Double Cabinet - boxed contents and parts identification FIG. 15 Christie Double Modular Cabinets are supplied with the following boxed contents: (1) x Stainless steel benchtop (2) x Channel frames (supplied attached to the benchtop)
  • Page 26 Open the benchtop carton and unpack the channel frames by removing all 6 mm retaining nuts (and washers) with a 10 mm spanner. Keep these aside for use later. Leave the benchtop in the carton. Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 27 Double cabinet assembly and installation | 4.4 Assembly and installation STEP 3 Assemble the bottom channel frames and posts before fixing into the final position. Once the assembly is complete, it will be turned over by 180 degrees. Locate the (2) x channel frames, (2) x vertical posts and (4) x corner posts. Assemble the channel frames and corner posts.
  • Page 28 Important: It is critical to the operation of the appliance that the cabinet is stable and level. Use packers to resolve minor levelling discrepancies or a bed of mortar for larger gaps. FIG. 17 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 29 Double cabinet assembly and installation | 4.4 Assembly and installation STEP 5 Remove the unsecured channel frame from the top of the posts. Identify the location of the access doors. Do not install panels into this space. Install the compressed fibre cement and stainless steel fascia panels together as a pair. With two people, lift the panels and slide them into the channel guides between two posts.
  • Page 30 Locate the keys and place them into the door lock. Lock the door latch into the open position Note: Brushed stainless steel finish doors will have a protective film. Remove the film before installation. FIG. 19 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 31 Double cabinet assembly and installation | 4.4 Assembly and installation STEP 8 Replace the top channel frame. Secure the channel frame using (24) x 10G self tapping screws. Note: A rubber mallet may assist in getting the frame to seat correctly. FIG.
  • Page 32 Secure the benchtop to the frame using the (4) x 6 mm washers and nuts provided (removed in Step 2). Remove the protective film from the benchtop. FIG. 21 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 33 Use the silicone provided to seal the gap between the outside of the panels and the frame. This will secure the panels and prevent them from rattling. Installation of your Modular Series Cabinet is now complete. Please consult the relevant installation instructions for any additional items, such as the barbecue cooktop.
  • Page 34 | Triple cabinet assembly and installation MODULAR TRIPLE CABINET assembly and installation Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 35 Triple cabinet assembly and installation | 5.1 Triple Cabinet - dimensions Dimensions: 2035 mm width x 750 mm depth x 900 mm height Weight: 211.5kg (without cooktop) Cooktop cut-out: 495 mm x 495 mm 2035 mm FIG. 23 FRONT 1976 mm REAR 750 mm SIDE...
  • Page 36 Position the gas or electric services relative to the preferred location and orientation of the cooktop(s) FIG. 24 1976 mm ANCHOR POINTS (16) 430 mm 670 mm 430 mm 60 mm 90 mm 90 mm 60 mm 1830 mm Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 37: Triple Cabinet - Services And Footings | Figure

    Terminate services for standard cabinet configurations in the locations indicated below. These locations will differ, depending on whether gas or electric cooktops are installed. For Christie CC2 Gas Barbecue Cooktop: • The gas inlet is on the right-hand side when facing the front of the cooktop •...

  • Page 38: Triple Cabinet - Boxed Contents And Parts Identification | Figure

    12. (2) x Pairs of access door keys (supplied attached to access door) – (Not shown) 13. (64) x M4 Self tapping screws (Not shown) 14. Installation and User Manual Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 39 STEP 1 Open the carton and review the boxed contents section relevant to your product model. Check that all listed parts are present. Contact Christie immediately if you notice any discrepancies. STEP 2 Open the benchtop carton and unpack the channel frames by removing all 6 mm retaining nuts (and washers) with a 10 mm spanner.
  • Page 40 Note: Do not fix the bottom channel frame until Step 8. If you ordered a Gas Bottle Storage kit, it will include vertical posts with channels attached. FIG. 27 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 41 Triple cabinet assembly and installation | 5.4 Assembly and installation STEP 4 The cabinet frame must be turned over before fixing. Do not locate fixings where the access doors are located. The bolt head will prevent the door from seating correctly into the frame. Roll the cabinet frame over so that the fixed channel frame is on the ground.
  • Page 42 If your cabinet has a Gas Bottle Storage kit, locate the 9mm divider panels and pre-drill any services holes before proceeding. Slide the panel into place between the two facing channels to create a separate compartment for the gas bottles. FIG. 29 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 43 Triple cabinet assembly and installation | 5.4 Assembly and installation STEP 6 WARNING: Services must only be connected by a suitably qualified person i.e. electrician or gas fitter. If your installation has 240v Power outlets (GPO’s), install these now. Complete the gas provisioning (if required).
  • Page 44 Replace the top channel frame. Secure the channel frame using (32) x 10G self tapping screws. Note: A rubber mallet may assist in getting the frame to seat correctly. FIG. 31 Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 45 Triple cabinet assembly and installation | 5.4 Assembly and installation STEP 9 Remove the benchtop from the carton and gently lower it onto the cabinet. Ensure that the locating tabs on the underside of the benchtop slide into the corresponding slots in the channel frame. Secure the benchtop to the frame using the (6) x 6 mm washers and nuts provided (removed in Step 2).
  • Page 46 Use the silicone provided to caulk the gap between the outside of the panels and the frame. This will secure the panels and prevent them from rattling. Installation of your Modular Series Cabinet is now complete. Please consult the relevant installation instructions for any additional items, such as the barbecue cooktop.

  • Page 47: Options And Accessories

    Options and accessories | Installation and User Manual 6820_00...
  • Page 48 STANDARD PANEL COLOURS Check our website at www.dachristie.com for current off-the-shelf finishes, standard powder coating colour options (lead times apply), and custom colours available at extra cost. Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 49: Cleaning And Maintenance

    Cleaning and maintenance | Installation and User Manual 6820_00...

  • Page 50: Safety Considerations

    Staining should occur less frequently after each removal. The most effective way to prevent tea staining is to ensure that any asset maintenance schedule includes washing and rinsing, to remove salt and dirt. Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)

  • Page 51: Cleaning Waste Containers | Figure

    Cleaning and maintenance | 7.4 Cleaning waste containers Waste containers must be emptied on a regular basis. Do not allow the waste container to overflow into the interior of the barbecue cabinet. All fat, grease and oil should be disposed of in accordance with local regulations. Do not dispose of it on the ground, as this will create a health hazard.
  • Page 52 Clean and wash the grease trap with a mild detergent or pH-neutral, biodegradable degreaser, before replacing it inside barbecue surround. A high-pressure cleaner or steam cleaner may also be used. Extra grease traps can be ordered from Christie, to exchange and clean grease traps thoroughly off site...

  • Page 53: Warranty

    Warranty | WARRANTY Installation and User Manual 6820_00...
  • Page 54 Company to do so including, but not restricted to, products tampered with, altered, modified, repaired, not cleaned, or not installed in accordance with the Company’s instructions. Modular Series Cabinet Single, Double and Triple (Product numbers 1506, 1511 and 1519)
  • Page 55 Warranty | This warranty is in addition to and not in substitution for any warranty given by Law. WARRANTY CLAIM PROCEDURE Warranty service may be obtained by contacting the Company Any claim for warranty must be accompanied by appropriate documentation that provides proof of purchase, details of the alleged defect and serial number The freight to the Company will be at the purchaser’s expense but return freight will be at the Company’s expense...
  • Page 56 +61 3 9708 2999 dachristie.com Installation and User Manual 6820_00...
