BULLETIN
SBM01-05
Engine Control Unit (ECU)
CONDITION : This service bulletin addresses two conditions identified individually below. Both conditions concern the
engine management system of affected vehicles.
(1) Field reports of intermittent engine stalling have been attributed to early releases of the MC1000 ECU
operating code. The operating code is something like the operating system in an ordinary personal
computer or PC (example: Windows 95). The operating code should not be confused with the calibration
file; that file contains mapping and vehicle specific calibrations.
.
(2) Field reports indicate hard starting and/or difficult cold starting experiences. These experiences have
been attributed to the cold starting "strategies" programmed in early releases of the calibration files on
affected units. A calibration file is something like the software running on a particular operating system
(example: MS Excel or Word).
SOLUTION :
(1) For condition 1 above, a revised version of the MC1000 operating code has been developed and must
be installed on all affected models. A special MS-DOS program has been developed to install the revised
code file to the vehicle ECU.
(2) A new calibration file has been developed and should be installed into the vehicle ECU after the revised
operating code (Condition (1) above) has been installed.
This service bulletin includes step-by-step instructions to correct both conditions in the same "work proce-
dure."
PARTS :
The kit (P/N 912-5001986) including PC software programs, a data cable, and user manuals is necessary
to perform the instructions of this service bulletin. The kit has been shipped to dealerships. The software
installation is a prerequisite to performing any work. Consult the kit documentation for more details.
If you have any questions about this service bulletin, call toll free 1-800-MOTO-USA.
SBM01_05.fm
© 2001 Cannondale Corporation - All Rights Reserved
SERVICE BULLETIN
ISSUED
MODEL(S) AFFECTED
11/8/01
2001 X440s, 2002 X440s, See list on page 5.,
And, units installed with the MC1000 Update Kit
(P/N 913-5002053)
MC500
SUBJECT(S)
1 - MC1000 operating code
2 - Hard starting and cold start
MC1000
Engine Control Unit (ECU)
5002171
Printed : 11/8/01
Advertisement
Summary of Contents for Cannondale MC1000
- Page 1 (example: MS Excel or Word). SOLUTION : (1) For condition 1 above, a revised version of the MC1000 operating code has been developed and must be installed on all affected models. A special MS-DOS program has been developed to install the revised code file to the vehicle ECU.
- Page 2 In the illustration below, the radiator is shown removed for clarity; the SBM01_05.fm © 2001 Cannondale Corporation - All Rights Reserved connector can be released easily using only your finger tips. strongly...
- Page 3 (accidentally Cannondale Diagnostic Tool). If you don’t have a problem, the next few steps will transfer this information to the ECU following the operation code transfer. But if you do...
- Page 4 ENTER key on your computer - you will see live data transfer information in the MS-DOS window. SBM01_05.fm © 2001 Cannondale Corporation - All Rights Reserved 14. When displays in the lower area of the program window, your assistant can release the engine start button.
- Page 5 MODEL(S) AFFECTED The following is a list of Vehicle Identification Numbers (VIN) of units affected by this service bulletin: 5B6BC11C02B000003 5B6AA11C21B000004 5B6BC11C22B000004 5B6BC11C62B000006 5B6BC11C82B000007 5B6BC11C82B000010 5B6BC11CX2B000011 5B6BC11C32B000013 5B6BC11C52B000014 5B6BC11C72B000015 5B6BC11C92B000016 5B6BC11C02B000017 5B6BC11C22B000018 5B6BC11C42B000019 5B6BC11C22B000021 5B6BC11C42B000022 5B6AA11C61B000023 5B6BC11C62B000023 5B6BC11C82B000024 5B6BC11CX2B000025 5B6BC11C12B000026 5B6BC11C52B000028 5B6AA11C51B000031 5B6BC11C52B000031...
