Table of Contents

Quick Links

Warnings and Cautions ........................................................ 2

1.1

Warnings ................................................................. 2

1.2

Cautions .................................................................. 3

Vein Finder Overview ......................................................... 4

2.1

Intended Use ........................................................... 4

2.2

Product Descriptions ............................................... 4

2.3

VS400 Symbol Definitions ..................................... 6

2.4

Displays .................................................................. 7

2.5

Accessories ............................................................. 8

2.6

Product List ............................................................. 8

Product Usage ..................................................................... 9

3.1

Operating Instructions ............................................. 9

3.2

Focus ..................................................................... 11

3.3

Projected Image Description ................................. 11

3.4

Software Version ................................................... 12

Cleaning and Maintenance ................................................ 13

4.1

Cleaning ................................................................ 13

4.2

Maintenance .......................................................... 13

Battery ............................................................................... 14

5.1

Build-in Battery ...................................................... 14

5.2

Charging ................................................................ 15

Storage and Transportation ............................................... 16

Technical Specifications .................................................... 17

7.1

Classification......................................................... 17

7.2

VS400 Description ................................................ 17

Common Faults and Solutions .......................................... 18

Disposal ............................................................................. 19

10. Warranty ............................................................................ 19

10.1

Warranty ................................................................ 19

10.2

Limitation of Liability ........................................... 20

Contents

1 V2.0

Table of Contents

Need help?

Do you have a question about the VS400 and is the answer not in the manual?

Questions and answers

Summary of Contents for MDD VS400

Page 1: Table Of Contents
Warnings ..............2 Cautions ..............3 Vein Finder Overview ............4 Intended Use ............4 Product Descriptions ..........4 VS400 Symbol Definitions ........6 Displays ..............7 Accessories ............. 8 Product List ............. 8 Product Usage ..............9 Operating Instructions ..........9 Focus ..............
Page 2: Warnings And Cautions
 VS400 vein finder only displays superficial veins, and does not provide diagnostic information.  Do not throw VS400 vein finder to fire, in case of battery explosions.  VS400 vein finder don’t include components which the customers can maintain. All components should be purchased from the authorized department.
Page 3: Cautions
1.2 Cautions  VS400 vein finder must be repaired by authorized and qualified staff.  Do not shine vein display light to the eyes for a long time.  Keep the instrument clean and avoid oscillation.  Keep the instrument dry and avoid any liquid flow into the VS400 vein finder or its adapter.
Page 4: Vein Finder Overview
The VS400 vein finder is a portable instrument to help medical professionals to locate certain superficial veins.  The VS400 vein finder should not be used as the sole method for locating veins, and should be used by a qualified medical professional.
Page 5  The VS400 vein finder is internally powered by battery and approved for continuous operation.  The VS400 vein finder is not protected from ingress of water.  No training is required to operate the VS400 vein finder.  The VS400 vein finder requires no routine or preventative maintenance, but needs regular cleaning.
Page 6: Vs400 Symbol Definitions
2.3 VS400 Symbol Definitions Material can be recycled DC power Caution Manufacturer Date of manufacture Can't be abandoned with the life garbage Contact number of manufacturer Refer to operating instructions Serial number Imaging unit interface Charging cradle interface Fragile, please take care...
Page 7: Displays
2.4 Displays Imaging Unit Charging Cradle 7 V2.0...
Page 8: Accessories
2.5 Accessories  VS400 is a portable model of the vein finder. VS400 is lightweight and equipped with high-capacity rechargeable lithium battery. Medical staffs can hold it easily to assess and locate the patient’s vascular.  VS400 is composed by the imaging unit and charging cradle, the imaging unit is used to project vein image.
Page 9: Product Usage
3. Product Usage No installing or setting is required before using the VS400 vein finder. 3.1 Operating Instructions  Main Switch: Switch to “OFF”, the device is power off. Switch to “ON”, press Power button, the device is power on and can achieve functions when you press the appropriate buttons.
Page 10 Off: Press Power button more than 2 seconds, until the instrument "beep" twice, the Power button indicator lights off, the instrument shut down. Standby: When device is power on and the projector is illumed, by short pressing the Power button (less than 0.5 seconds), the device will go to standby mode and the projector will be turned off.
Page 11: Focus
The focus is complete. Note: The displayed vein might be thicker or thinner than the actual vein, because of the distance from the VS400 to skin, the patient physical differences and even the different observation modes.
Page 12: Software Version
3.4 Software Version The software version of the VS400 can be displayed by pressing the Inverse and Color button on the control panel, shown as blow. Press the Power button to withdraw from this projected image. 12 V2.0...
Page 13: Cleaning And Maintenance
4. Cleaning and Maintenance 4.1 Cleaning  Don’t clean VS400 when it is on support. Please take it off before cleaning.  Please unplug power cable and make sure VS400 is off before cleaning.  The lens window needs cleaning for every months. Please use dust-free cloth and concentration of 95% alcohol to wipe it, then dry it naturally or use dust-free cloth to dry it.
Page 14: Battery
Note: If there is abrasion or dirt on the lens window, please don’t use VS400. If the window is damage, please contact the distributor or manufacturer to maintain it. 5. Battery 5.1 Build-in battery...
Page 15: Charging
continually. Short press any button (about 0.5 seconds) can eliminate the sound. If reboot the device, the “beep” sound will be emitted again before the battery charged. 5.2 Charging The battery indicator is on the upper right corner of projection image.
Page 16: Storage And Transportation
When the indicator light  is blue, the battery is not fully charged, need to continue to be charged. When the indicator light  turns green, the battery is fully charged; it is recommended to take away the imaging unit from the charging cradle. When the indicator light ...
Page 17: Technical Specifications
IPX0 or particulate matter By other methods validated and Method(s) of sterilization described by the manufacture Mode of operation Continuous operation 7.2 VS400 Description Parameter Specification Weight(the imaging unit) 480g Dimensions(the imaging 60x60x240mm unit) Lithium-ion Battery, 3.6V, 4.3Ah...
Page 18: Common Faults And Solutions
Valley wavelength of About 530nm visible light Atmospheric Pressure(operating and 700hPa to1060hPa storage) Operating humidity 10-90% (non-condensing) Operating temperature 10°C to 30°C Storage humidity 0-90% (non-condensing) Storage temperature 0°C to 60°C 8. Common Faults and Solutions Symptom Reason Solution battery run out Charge battery Boot no display...
Page 19: Disposal
10. Warranty Warranty 10.1  The VS400 should work in the temperature between 10° C to 30° C. Malfunction would occur out of this range.  When the VS400 is not operating properly, please turn off the device.
Page 20: Limitation Of Liability
 Our company will repair or replace any product free that does not satisfy these warranties within limitation of time. You must obtain a Return of Material Authorization (RMA) number from our company support. The repaired unit has a 90-day warranty from the date when it is received by the customer.
