Sequoia Professional
Exeter 6' Garden Bench
Assembly Guide
SUPPORT BAR
B
LEG SUPPORT
1) Attach (1) Support Bar to
Leg Support using
(2) "B" Bolts as shown.
ARM ASSEMBLY
B
SUPPORT BAR
LEG ASSEMBLY
2) Attach (1) Support Bar to
Arm Assembly and Leg Assembly
using (4) "B" Bolts as shown.
SEQUOIA
PROFESSIONAL
A
ASSEMBLED SUPPORT BAR
ARM ASSEMBLY
B
3) Attach the Assembled Support Bar
to the Arm Assembly and Leg Assembly
using (2) "A" Bolts and (2) "B" Bolts as shown.
For information on Care and Cleaning or to register
your
SEQUOIA PROFESSIONAL
www.sequioaprofurniture.com
A
1/4"-20 X 1-1/2"
B
1/4"-20 X 1-3/4"
C
D
1/4"-20 X 3"
LEG ASSEMBLY
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
Retain these instructions for future reference
B
product, please visit
HARDWARE
x2
x12
x10
1/4"-20 X 2"
VERY IMPORTANT!
go back & tighten all the bolts.
INCLUDED TOOLS
5/32" HEX KEY
CM-BENSQ62
PAGE 1 OF 2
x9
07.16.19
Advertisement
Summary of Contents for Sequoia Professional Exeter
- Page 1 Sequoia Professional HARDWARE Exeter 6' Garden Bench 1/4"-20 X 1-1/2" Assembly Guide 1/4"-20 X 1-3/4" SUPPORT BAR LEG SUPPORT 1/4"-20 X 2" 1) Attach (1) Support Bar to Leg Support using (2) "B" Bolts as shown. 1/4"-20 X 3" ARM ASSEMBLY...
- Page 2 5) Attach Back Assembly to 4) Attach (1) Seat Assembly to Back Supports using (3) "D" Bolts as shown Arm Assemblies and Leg Assembly using (4) "B" Bolts and (4) "C" Bolts as shown BACK ASSEMBLY ARM ASSEMBLY ARM ASSEMBLY SEAT ASSEMBLY BACK SUPPORT BACK SUPPORT...
