OWNER'S MANUAL
DVD Home Theater System
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
HLB54S (HLB54S-DP/ SHS54-A)
P/NO : MFL63284227
HLB54S-DP_BGRCLL_ENG_4227.indd 1
HLB54S-DP_BGRCLL_ENG_4227.indd 1
2010-03-16 ¿ÀÈÄ 7:11:50
2010-03-16 ¿ÀÈÄ 7:11:50

Advertisement

Table of Contents
loading

Related Manuals for LG HLB54S

Summary of Contents for LG HLB54S

  • Page 1 OWNER'S MANUAL DVD Home Theater System Please read this manual carefully before operating your set and retain it for future reference. MODEL HLB54S (HLB54S-DP/ SHS54-A) P/NO : MFL63284227 HLB54S-DP_BGRCLL_ENG_4227.indd 1 HLB54S-DP_BGRCLL_ENG_4227.indd 1 2010-03-16 ¿ÀÈÄ 7:11:50 2010-03-16 ¿ÀÈÄ 7:11:50...
  • Page 2 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSO NNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient...
  • Page 3 What is SIMPLINK? Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc.
  • Page 4 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Licenses Java and all Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

  • Page 5: Table Of Contents

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Contents Introduction ........6-9 Remote control .

  • Page 6: Introduction

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Introduction To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference. This manual provides information on the operation and maintenance of your player. Should the unit require service, contact an authorized service location.
  • Page 7 You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live System, you cannot use it on LG player. (Mastered/Live File System : Disc format system for windows Vista)
  • Page 8 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM BD-ROM Disc Features BD-ROM Discs can store 25 GB (single layer) or 50 GB (dual layer) on a single sided disc - about 5 to 10 times the capacity of a DVD. BD-ROM Discs also support the highest quality HD video available in the industry (up to 1920 x 1080) - Large capacity means no compromise on video quality.
  • Page 9 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Regional Code This unit has a regional code printed on the rear of the unit. This unit can play only BD-ROM or DVD discs labeled same as the rear of the unit or “ALL”. AVCHD (Advanced Video Codec High Definition) •...

  • Page 10: Remote Control

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Remote control INPUT (TUNER): Changes the input source POWER (FM, PORTABLE, OPTICAL, HDMI IN 1, HDMI IN 2) POWER: Switches the player ON or OFF. OPEN/CLOSE (Z): Ejects or inserts disc from the slot loader. iPod: Selects REMOTE IPOD or OSD IPOD mode.

  • Page 11: Front Panel

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Front panel a OPEN/CLOSE (Z) Ejects or inserts disc from the slot loader. b i i / X (PLAY / PAUSE) Starts playback. Pause playback temporarily, press again to exit pause mode. c x (STOP) Stops playback.

  • Page 12: Rear Panel

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Rear panel a iPod connector Connect the iPod dock on the rear of the unit. b FM ANTENNA Connector Connect the FM antenna. c OPTICAL IN Connect to digital (optical) audio equipment. d VIDEO OUT Connect to a TV with video inputs.

  • Page 13: Setting Up

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Setting up Install an unit and a sub woofer as shown in the illustration below. (Recommanded) Plug the power cord of the unit and sub woofer into the power source. The TV is not supplied. TV (Not supplied)

  • Page 14: Connections To Your Tv

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Connections to Your TV Make one of the following connections, depending on the capabilities of your existing equipment. Tips: • Depending on your TV and other equipment you wish to connect, there are various ways you could connect the player. Use only one of the connections described below.
  • Page 15 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Additional Information for HDMI • When you connect a HDMI or DVI compatible device make sure of the following: - Try switching off the HDMI/DVI device and this player. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this player.

  • Page 16: Resolution Setting

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Resolution Setting The player provides several output resolutions for HDMI OUT. You can change the resolution using [Setup] menu or pressing the RESOLUTION button in stop mode. Note: Since several factors affect the resolution of video output, see “Available resolution according to the resolution setting”...
  • Page 17 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM HDMI OUT connection • For the 576i resolution setting, real output resolution of HDMI OUT will change to 576p. • If you select a resolution manually and then connect the HDMI jack to TV and your TV does not accept it, the resolution setting is set to [Auto].

  • Page 18: Connecting To Your Home Network

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Connecting to your Home Network This player can be connected to a local area network (LAN) via the LAN port on the rear panel or the internal wireless module. By connecting the unit to a broadband home network, you have access to services such as software updates, My Media, BD-Live interactivity and streaming services.
  • Page 19 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Use v V b B to select the IP mode between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically. Note: If there is no DHCP server on the network and you want to set...
  • Page 20 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Caution: Wired internet connection is strongly recommended. Using the [My Media] features, network update and video streaming services (such as YouTube Videos) with wireless network can be affected by the household devices using radio frequencies. • Adjusting [NETWORK] settings for wireless network For the wireless network connection, the player needs to be set up for network communication.
  • Page 21 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Notes on Network Connection • Many network connection problems during set up can often be fixed by re-setting the router or modem. After connecting the player to the home network, quickly power off and/or disconnect the power cable of the home network router or cable modem.

  • Page 22: Network Update Notification

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Network Software Update Network update notification From time to time, performance improvements and/or additional features or services may be made available to units that are connected to a broadband home network. If there is new software available and the unit is connected to a broadband home network, the player will inform you about the update as follows.
  • Page 23 The Software Update function may not work properly depending on your internet environment. In this case, you can obtain the latest software from the authorized LG Electronics Service Centre then update your player. Refer to “Customer Support” on page 58.

  • Page 24: Setting The Sound Mode

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Setting the sound mode You can select a suitable sound mode. Press SOUND repeatedly until the desired mode appears on the front panel display or the TV screen. The setting the sound mode is not available when [HDMI Audio] is set to [On] (see page 28).

  • Page 25: Using A Usb Device

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Using a USB device This unit can play the movie, music and photo files contained in the USB device. 1. Insert a USB device to the USB port: 2 Displays the [Home Menu]: 3 Select a main option:...

  • Page 26: Using The Home Menu

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Using the Home Menu 1 Displays the [Home Menu]: 2 Selects an option: 3 Displays the selected option menu: 4 Exit the [Home Menu]: [Movie] – Start video media’s playback or displays the [Movie] menu. [Photo] – Display the [Photo] menu. (page 41-42) [Music] –...
  • Page 27 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM [DISPLAY] Menu TV Aspect Ratio [4:3 Letter Box] – Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture. [4:3 Pan Scan] – Select when a standard 4:3 TV is connected.
  • Page 28 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM [LANGUAGE] Menu Display Menu Select a language for the [Setup] menu and on-screen display. Disc Menu / Disc Audio / Disc Subtitle Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu.
  • Page 29 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM [LOCK] Menu (Parental Control) The [LOCK] settings affect only BD and DVD playback. To access the any features in [LOCK] settings, you must enter the 4-digit security code you have created. If you have not entered a password yet, you are prompted to do so. Enter a 4-digit password and press ENTER.
  • Page 30 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM [NETWORK] Menu The [NETWORK] settings are needed to use the software update, BD Live, My Media and YouTube features. Some BD-ROM discs may enable you to access special BD-ROM sites, if you connect the player to the Internet. For example, if a BD-ROM site includes content such as links to future movie trailers, you can watch the downloaded on-line content on the player.
  • Page 31 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM [OTHERS] Menu Skin Changes the background of the initial screen. Initialize You can reset the player to its original factory settings, initialize the BD storage or deactivate the player. [Factory Set] – If you need to, you can reset the player to all its factory settings.

  • Page 32: Play A Disc

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Play a disc 1 Inserts a disc: 2 Adjusts the disc menu settings: A disc menu may not appear on the screen depending on the disc. 3 Starts playback: 4 Stops playback: Notes: • When you turn on the player or replace a disc, the player returns to the initial default setting.
  • Page 33 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Pause a playback During playback, press PAUSE/STEP (X) to pause playback. Press PLAY (N) to continue playback. Tip: During Audio CD or MP3/WMA playback, press X once again to resume playback. Frame-by-Frame playback AVCHD MOVIE MOVIE-N Press PAUSE/STEP (X) repeatedly to play Frame-by-Frame playback.
  • Page 34 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Selecting a subtitle file MOVIE If names of the movie file and subtitle file are same, subtitle file is played automatically when playing the movie file. If the name of the subtitle file is different from movie file name, you need to select the subtitle file on the [Movie] menu before playing the movie.
  • Page 35 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM • If the total length of the title is less than 10 seconds, this function is not available. • This function may not work on some [My media] content depending on the file type and ability of the DLNA server.

  • Page 36: Displaying Disc Information

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Displaying disc information 1 Play the disc loaded on the unit: 2 Displays the playback menu: 3 Selects an item: 4 Adjusts the playback menu settings: 5 Exit the disc playback menu: a Title – Current title number/total number of titles.

  • Page 37: Enjoying Bd-Live

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Enjoying BD-LIVE™ 1 Inserts a BD-ROM disc with BD-LIVE™ features: 2 Check the network connection and settings: BD-Live features need the internet connection. 3 Connect a USB device: A USB device is required to use this function.

  • Page 38: Playing A Movie

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Playing secondary video (picture-in-picture) Secondary video can be played from a disc compatible with the picture-in- picture function. For the playback method, refer to the instructions for the disc. To turn on/off secondary video, press PIP. Secondary video is played.
  • Page 39 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Notice for displaying the DivX subtitle If the subtitle does not display properly, press and hold SUBTITLE for 3 seconds during playback. The language code will appear. Press SUBTITLE repeatedly to select another language code until the subtitle is displayed properly and then press ENTER.

  • Page 40: Listening To Music

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Listening to music The player can play Audio CDs and MP3/WMA files. Before playing MP3/WMA files, read “MP3/WMA audio file requirement” on page 40. 1 Inserts an Audio CD or a disc/USB Flash Drive containing MP3/WMA files.

  • Page 41: Viewing A Photo

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Viewing a photo This unit can play a photo files. Before playing photo files, read “Photo file requirement” on page 1 Inserts a disc/USB device containing photo files. 2 Displays the [Home Menu]: 3 Selects a [Photo] option:...

  • Page 42: Viewing A Photo

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM f Use green or yellow buttons to zoom in or out of the picture. You can move through the zoomed picture using v V b B buttons. Press RETURN to exit the [Zoom] menu and return to the normal picture size.

  • Page 43: Using My Media Features

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Using My Media features The player can browse and play movies, music and photo stored on DLNA Certified media servers connected on your home network. 1 Check the network connection and settings: See pages 18-21. 2 Displays the [Home Menu]:...
  • Page 44 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Click [Nero MediaHome 4 Essentials]. The installation is prepared and the installation wizard appears. Click the [Next] button to display the serial number input screen. Click [Next] to go to the next step. If you accept all conditions, click [I accept the License Conditions] check box and click [Next].
  • Page 45 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Playing back shared contents On the BD player, you can display and play movie, photo and music content stored on your computer or other DLNA media server. Start the server connected to your computer or other device that is connected to your home network.
  • Page 46 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM File requirements Overall File extensions: “.jpg”, “.jpeg”, “.png”, “.avi”, “.divx”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.mp3”, “.wma”, “.pcm” (LPCM) • Available file extensions differ depending on the server. Maximum Files/Folder: Less than 2000 (total number of files and...

  • Page 47: Playing Youtube Videos

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Playing YouTube videos 1 Check the network connection and settings: See pages 18-21. 2 Displays the [Home Menu]: 3 Select the [YouTube] option: 4 Select a desired option on the YouTube menu: 5 Select a video you want to play:...
  • Page 48 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM About YouTube playback screen When you press PLAY (N) or ENTER at the video you want to watch, the playback screen and content detail will appear on the screen. playback screen progress bar while playing And when the playback ends or stops, the stopped playback screen and related videos list appear on the screen.
  • Page 49 HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Searching videos You can search for videos by entering search words of up to 128 characters. Use b B to select [Search] option from the menu and press ENTER to display the keyboard menu. Use v v V V b b B B to select a character then press ENTER to confirm your selection on the keyboard menu.

  • Page 50: Listenning To The Radio

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Listening to the radio Be sure that FM antenna is connected. 1 Select FM: 2 Select a radio station: 3 To save a radio station: A preset number will show on the display. Up to 50 radio stations can be saved.
  • Page 51 • The video quality depends on the video sources on your iPod. • When LG TV’s SIMPLINK is set to On, the audio signals are output to the system speakers only. • If this unit displays an error message, follow the message.

  • Page 52: Listening To Music From Your Portable Audio Player

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Listening to music from your portable audio player You can enjoy the sound of your portable audio player from the speakers of the system. 3.5 mm stereo miniplug cable 1 Connect the headphones (or line out ) jack of the portable audio player into the PORT.

  • Page 53: Using Hdmi In Jack

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Using HDMI IN jacks You can enjoy the pictures and sound of your component with the HDMI OUT jack. To the HDMI OUT jack of your component (set-top box, digital satellite receiver, video game machine, etc.)

  • Page 54: Reference

    Page 54 Setting up the remote to control your TV You can operate your LG/GoldStar TV with the supplied remote control. While holding down TV POWER button, press PR/CH v v or V V . Release the TV POWER button to complete setting.

  • Page 55: Language Codes

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Language Codes Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Afar 6565 Croatian 7282 Afrikaans 6570 Czech 6783 Albanian 8381...

  • Page 56: Troubleshooting

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Troubleshooting Symptom • The power cord is disconnected. No power. • No disc is inserted. The power is on, but the player does not work. • The TV is not set to receive video signal output.

  • Page 57: Troubleshooting

    HLB54S-DP_BGRCLLK_ENG_4227 3/16/10 7:13 PM Troubleshooting Symptom BD-Live feature does not • External USB device is not connected. work. • The connected USB device does not have enough space. • Internet connection is not established. • Your broadband speed is not fast enough to use the BD-Live features.

  • Page 58: Specifications

    You can update the Player using the latest software to enhance the products operation and/or add new features. To obtain the latest software for this player (if updates have been made), please visit http://lgservice.com or contact LG Electronics customer care centre. Design and specifications are subject to change without notice.

  • Page 59: Important Information Relating To Network Services

    UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL THEORY, WHETHER IN CONTRACT, TORT, STRICT LIABILITY OR OTHERWISE, SHALL LG BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, STATUTORY, CONSEQUENTIAL OR OTHER DAMAGES OR ATTORNEY FEES OR...

  • Page 60: Open Source Software Notice

    Public License 1.3 LIBRARY: gsoap LG Electronics offers to provide source code to you on CD-ROM for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling upon e-mail request to LG Electronics at: opensource@lge.com...
  • Page 61 HLB54S-DP_BGRCLL_ENG_4227.indd 2 HLB54S-DP_BGRCLL_ENG_4227.indd 2 2010-03-16 ¿ÀÈÄ 7:11:51 2010-03-16 ¿ÀÈÄ 7:11:51...
