rba Raffaello 90 LH RBA4601-171 Installation, Operation And Maintenance Instructions

INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
10. Ensure snug fi t. 11. Ensure rail is level
13. Position fl ange cover so
14. Rotate the fl ange cover
the hole is over the screw
so the hole is positioned over
fi xing point. Secure the fi rst
a new screw fi xing point.
screw.
16. Place screw into screw
cover before securing rail
bracket
SYDNEY | MELBOURNE | BRISBANE | PERTH | AUCKLAND
4
Australia 1300 788 778 www.rba.com.au
12. Mark location to install.
15. Push fl ange cover over
wall plate and insert fl ange
button.
New Zealand 0800 722 111 www.rbagroup.co.nz
|
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
RBA Modular Rails
RBA4601-171 Raffaello 90° LH Accessible Grab Rail | White
RBA4601-178 Raffaello 90° LH Accessible Grab Rail | Matte Black
RBA4601-179 Raffaello 90° LH Accessible Grab Rail | Chrome
RBA4601-181 Raffaello 90° RH Accessible Grab Rail | White
RBA4601-188 Raffaello 90° RH Accessible Grab Rail | Matte Black
RBA4601-189 Raffaello 90° RH Accessible Grab Rail | Chrome
Sourced/ Supplied under QMS
SYDNEY | MELBOURNE | BRISBANE | PERTH | AUCKLAND
1
Australia 1300 788 778 www.rba.com.au
Model
RBA Modular Rails
Date
27/10/20
ii/rba4601-17&18
Series/1020
Supercedes all previous
New Zealand 0800 722 111 www.rbagroup.co.nz
|
