Summary of Contents for Osotto ES-M13
- Page 1 User Manual - Oscooto Foldable Electric Scooter Model ES-M13...
- Page 2 Important Safety Notice Before using your scooter please read this manual carefully. Riding an electric scooter can be dangerous and can result in injury to the rider and / or others. This can include death. You ride at your own risk, but please use common sense and follow all safety instructions.
-
Page 3: Table Of Contents
Thanks for choosing Oscooto. Have fun with this electric scooter, but please follow the important safety warnings and use it only where allowed by law. Contents: Device & Accessories Functions. Assembling Charging Riding Instructions Safety Recommendations Folding & Transportation Daily Maintenance and Storage Model Specifications End of Life Disposal Warranty... -
Page 4: Device & Accessories
The Device & Accessories Accessories Fitting for wheels swap Screws x 2 Hex Wrench Charging Adapter... -
Page 5: Functions
Functions Indicator Mode SWITCHING ON AND OFF: Switching on: Long press the power button until the display lights up. Switching off: Long press the power button until the display turns off and the system is off. DISPLAY: Battery charge status: shows the current battery capacity remaining (the battery image has 5 bars when full). -
Page 7: Assembling
Assembling the device 1).Affiix the steering rod 2).Set handle bars vertical and and parking bridge 4).Test the power switch after 3).Using the supplied hex assembling . wrench, tighten the screws on the handle bar Power button: Press power button to turn on the scooter. Press and hold the button for 2 seconds to turn on. - Page 8 Charging scooter Open the cover, connect the charger and close the cover Charge Scooter for 8 hours before first use 5.Riding the Scooter: Always wear helmet and knee 1. Power on and check the pads when riding battery led light...
- Page 9 Stand on scooter with one leg, with the other leg on the ground Push away gently. Once the scooter is moving, press the accelerate button (only accelerate when the scooter speed is beyond 5km/h) Release the accelerate button to slow down. Energy recovery systems will deploy to slow down.
- Page 10 Safety Instructions It is not recommended to It is recommended to slightly ride in the rain. Do not use bend knees to better adjust to in icy conditions. a rough road.If you are travelling on rough roads, keep to low speed (5-10km/h) If entering into a room, elevator, etc.
- Page 11 While walking with the scooter, When riding, avoid obstacles in the do not press the speed knob road While riding, keep both feet on the scooter until you stop. Don’t hang backpacks or other heavy objects on the handlebar...
- Page 12 Preventing dangerous driving Check the Highway Code and local by-laws to determine where you are allowed to use Avoid sharp turns your scooter Don’t drive through puddles Never carry passengers. that exceed a depth of 2 cm.
- Page 13 Do not touch the disc brake Do not stand or place objects on the mudguards Always keep both hands on the handlebars Do not ride up or down steps or attempt to jump over obstacles...
- Page 14 Important Safety Recommendations When riding in a public area, the electric scooter brings certian risks for your own safety and the safety of others. You should always ride responsibly, and, follow the instructions outlined in this manual. Please always show consideration to other people.
- Page 15 Folding and Transporting Fold Make sure the power is off. While holding the front pole, loosen the lock lever and lower steering rack. Position steering rack in a horizontal position and secure by inserting a hook through the ring, located on the rear wheel mudguard.
- Page 16 Care and Storage Cleaning and storing Electric Scooter If you find any stains on electric scooter housing, use a soft, damp cloth to wipe the scooter. You can use toothpaste and a toothbrush to clean the scooter from stains, and then wipe clean with a damp cloth. If you find light scratching on plastic parts, use a very fine grade of wet sandpaper or a cutting polish to restore the finish.
- Page 17 After each use of the scooter, charge the battery to prolong its service life. Do not store the scooter battery in conditions that exceed 50℃ or below -20℃. To do so may deteriorate the battery or cause overheating including the risk of fire. If unused, you should charge the scooter every sixty days in order to maintain battery life.
- Page 18 Adjusting disc brake If a brake is too tight: use the M5 hex wrench to loosen the screws on the brake disc tensioner pulley, and slightly shorten the length of the brake cable, then retighten the tensioner pulley. If the brake is too lose, do the same, but make the cable longer.
-
Page 19: Charging
Specifications: Parameters Operating Item parameters Dimensions Length x Width x 102 x 42.5 x 114 Height[1] (cm) Package:Length x 109 x 15 x50 Width x Height(cm) weight 15.2kg Gross weight Conditions Max load 120 kg Recommended ages 16-50 years old 120-200 Height(cm) Main Parameters... - Page 20 Rated power(Wh) Stress,insufficent Smart battery voltage,short circuit,auto management system sleep/wake up, overheating, protection, control of battery usage Motor Parameters Rated power(W) Peak power(W) Power Rated power(W) adaptor Rated input 100-240V parameters voltage(V/AC) Rated output voltage(VDC) Rated current(A) Certificate 3-5h Charging time(h)
-
Page 21: End Of Life Disposal
End of life disposal: At end of life, please dispose of your scooter responsibly. In accordance with European Directive 2006/66/EC, the battery must be removed from the scooter and taken to a battery disposal centre. This can be done by a competent person. The battery is located inside the main body of the scooter. -
Page 22: Warranty
Please keep the packaging for safe transport of the scooter in the event of a warranty claim. Imported by: Osotto Ltd 5 High Street Pontypridd CF37 1QJ www.osotto.co.uk...
