PEDEST AL MOUNTS
NOTE: Do not return your CANNON accessory to your
retailer. Your retailer is not authorized to repair or re-
place this unit. You may obtain service by:
• calling CANNON at 1-800-227-6433;
• returning your accessory to the Factory Service Center;
121 Power Drive, Mankato, MN 56001
Please include proof of purchase and purchase date for
warranty service with any of the above options.
4" Fixed Pedestal mount
6" Fixed Pedestal mount
4" Swivel Pedestal mount
6" Swivel Pedestal mount
Owner's Manual
CAUTION:
READ THIS MANUAL CAREFULLY
BEFORE OPERATING YOUR
NEW CANNON ACCESSORY.
RETAIN FOR FUTURE REFERENCE.
1904030
1904031
1904032
1904033
Advertisement
Related Manuals for Cannon 1904030
Summary of Contents for Cannon 1904030
- Page 1 PEDEST AL MOUNTS NOTE: Do not return your CANNON accessory to your retailer. Your retailer is not authorized to repair or re- place this unit. You may obtain service by: • calling CANNON at 1-800-227-6433; • returning your accessory to the Factory Service Center;...
- Page 2 1904031 Fixed Base Downrigger Pedestal 6” Cannon’s fixed base downrigger pedestals can be surface mounted or track mounted for a variety of mounting positions and easy removal. The 3/4” thick aluminum top plate is pre-drilled and tapped for mounting Can- non downriggers as well as most Scotty®, Big Jon®, Penn®, Vector, Proos, Fishlander and Walker downriggers.
- Page 3 Swivel Base Break Away Reset The Cannon Swivel bases feature a unique break away system which allows the top plate to rotate while in the locked position. The break away feature will help prevent damage to the downrigger and boat in the event that the downrigger boom or ball would strike an object.
- Page 4 The Cannon Deck Mount works great for adding stability and easy removal of your pedestal mount. With your Cannon Deck Mount installed on your boat, attach your pedestal mount by removing the thumb screws and fastening the pedestal base to the plate with four 1/4”-20 x 3/8” long flat head screws.
-
Page 5: Replacement Parts
Mounting Your Downrigger to the Pedestal Mount The Cannon Pedestal Mount provides 1/4”-20 tapped mounting holes for attaching most downrigger mounting bases. To attach a mounting base you will need four 1/4”-20 screws length of screws needed, measure the thickness of the downrigger mounting base and add 1/2”. See below for screw lengths for the Cannon Downrigger mounting bases. - Page 6 This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. To download product manuals or purchase Cannon products from an authorized dealer, please visit our web page at WARNING: This product contains chemical(s) known to the state of California to cause cancer and/or reproductive toxicity.
