- Page 1 Models 7907 N.E. St. Johns Rd. Vancouver, WA 98665 Copyright 2009 TANGO...
- Page 2 Install each on to the 4 boxes (x4) Hull Bar Armor and Horizontal Bumpers common on both sides Vertical bumpers (8x) on Port side only Rope tie down and guard (2x) Both sides TANGO-page 1...
- Page 3 Installation of bunks, ammo can trays the starboard bow of the wall deck. and .30 cal on bottom on both sides. and caps are for both sides. The installation of the steps (3x) are for the port side only. TANGO-page 2...
- Page 4 8 rows of 4 = 32 Mine resistant platforms and seats The seats and platforms start at the front of the gunner's platforms, and extend to the back. Upper deck cover TANGO-page 3...
- Page 5 Remove these antenna brackets off both sides Remove these gun stops off both sides Grenade launcher Turret and gun (x3) Gun stops. Port and starboard TANGO-page 4...
- Page 6 TANGO-page 5...
- Page 7 Remove these vertical bars Bar armor shown independently of coxwain station in order to simplify drawing. TANGO-page 6...
- Page 8 Fold the brass cross pieces at the 3, 6 and 9 o'clock positions inward, and the 12 o'clock piece outward. (x2) Tango boat simplified to show new pieces Use bent styrene rod to create the spinning cutters for the mine sweep chain.
- Page 9 This diagram shows all the "in-line" supports along the length of the boat that support the helicopter deck. ( These vertical posts are approx. 1.5" long ) Ladder assembly Handrail templates Starboard side Port side (full scale) Inside rail Outside rail TANGO-page 8...
- Page 10 These vertical supports shown here are not shown in their entirety. See page 8 for detailed instructions. Storage bin Ladder and railing (both sides) Hatches can be open or closed. Use small scale chain as shown here TANGO-page 9...
- Page 11 30 caliber 50 caliber TANGO-page 10...
- Page 12 30 caliber Guns: both sides 50 caliber String (Styrene rod x2) Install tires on both sides Finished TANGO-page 11...
