Typical calibration frequencies for most applications are between 3 and 6 months, but can be required more often or less often based on your usage. 65-2496RK/65-2499RK CO Detector GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 3
Product Warranty RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials, workmanship, and performance for a period of one year from date of shipment from RKI Instruments, Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of charge.
The 65-2499RK CO detector includes the 65-2496K CO detector and a junction box. This manual may also be used for the 65-2496RK CO detector which does not include a junction box and is normally mounted in one of a controller’s conduit hubs. If you are using a 65-2496RK CO detector, disregard all references to the junction box and junction box terminal strip.
This section describes the components of the 65-2496RK and 65-2499RK detectors. The 65- 2499RK includes the 65-2496RK CO detector and a junction box. A two point terminal strip is provided inside the junction box for detector connections. The 65-2496RK does not include a junction box.
A terminal block within the junction box facilitates the wiring connections. A cover on the front of the junction box allows access to the interior of the junction box. 65-2496RK/65-2499RK CO Detector • 3 GlobalTestSupply www.
Mounting the CO Detector NOTE: If you are installing a 65-2496RK, it does not include a junction box and is usually factory installed in one of a controller’s conduit hubs or may be field installed using the 3/4”...
Connect the wires to the applicable controller terminal strip. See the controller operator’s manual and the controller’s detector head specification sheet for the 65- 2499RK detector. 65-2496RK/65-2499RK CO Detector • 5 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
Page 10
Figure 4: Wiring the CO Detector to a Controller 10. If using shielded cable, connect the cable’s drain wire to an available chassis ground at the controller. RKI controllers typically have a ground stud that is a convenient grounding location. 6 • 65-2496RK/65-2499RK CO Detector GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
If the display reading is 0 ppm, start up is complete. The CO detector is in normal operation. If the display reading is not 0 ppm, continue with step 3. Perform a zero (fresh air) adjustment operation at the controller. See the controller operator’s manual for instructions. 65-2496RK/65-2499RK CO Detector • 7 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
NOTE: If the reading is not within ± 20% of the correct response reading, calibrate the detector as described in “Calibration” on page 13. Turn the regulator’s on/off knob clockwise to close the regulator. Unscrew the regulator from the calibration cylinder. 8 • 65-2496RK/65-2499RK CO Detector GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
• If the fail condition continues, replace the plug-in sensor as described later in this section. • If the fail condition continues, contact RKI Instruments, Inc. for further instruction. Slow or No Response/Difficult or Unable to Calibrate Symptoms • The detector responds slowly or does not respond during the monthly response test.
If the difficulties continue, replace the charcoal filter as described later in this section. If the difficulties continue, replace the plug-in sensor as described later in this section. If the difficulties continue, contact RKI Instruments, Inc. for further instruction. Replacing Components of the CO Detector...
Page 15
10. Make sure the cap gasket is in place and screw the detector housing cap back onto the detector housing body. 11. Turn on power to the controller. 65-2496RK/65-2499RK CO Detector • 11 GlobalTestSupply www. .com Find Quality Products Online at:...
Page 16
See Figure 4 on page 6 for wiring to a generic controller. See the controller operator’s manual and the controller’s detector head specification sheet for the 65-2496RK detector for wiring specific to your controller. If the detector is installed remotely from a controller in a junction box, connect the detector leads to the terminal block the same way the old detector was wired (see Figure 4 on page 6).
Although there is no particular calibration frequency that is correct for all applications, a calibration frequency of every 3 months is adequate for most CO detector applications. Unless experience in a particular application dictates otherwise, RKI Instruments, Inc. recommends a calibration frequency of every 3 months for the CO detector.
NOTE: If you do not allow the gas reading to decrease below the alarm points, then unwanted alarms may occur. Verify that the controller display reading decreases and stabilizes at 0 ppm. Store the components of the calibration kit in a safe and convenient place. 14 • 65-2496RK/65-2499RK CO Detector GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
